REV-ERBα mediates complement expression and diurnal regulation of microglial synaptic phagocytosis

  1. Percy Griffin
  2. Patrick W Sheehan
  3. Julie M Dimitry
  4. Chun Guo
  5. Michael F Kanan
  6. Jiyeon Lee
  7. Jinsong Zhang
  8. Erik S Musiek  Is a corresponding author
  1. Department of Neurology, Washington University School of Medicine in St. Louis, United States
  2. Department of Pharmacological and Physiological Science, Saint Louis University School of Medicine, United States
  3. Hope Center for Neurological Disorders, Washington University School of Medicine in St. Louis, United States
Research Article
  • Cited 1
  • Views 1,052
  • Annotations
Cite this article as: eLife 2020;9:e58765 doi: 10.7554/eLife.58765

Abstract

The circadian clock regulates various aspects of brain health including microglial and astrocyte activation. Here, we report that deletion of the master clock protein BMAL1 in mice robustly increases expression of complement genes, including C4b and C3, in the hippocampus. BMAL1 regulates expression of the transcriptional repressor REV-ERBα, and deletion of REV-ERBα causes increased expression of C4b transcript in neurons and astrocytes as well as C3 protein primarily in astrocytes. REV-ERBα deletion increased microglial phagocytosis of synapses and synapse loss in the CA3 region of the hippocampus. Finally, we observed diurnal variation in the degree of microglial synaptic phagocytosis which was antiphase to REV-ERBα expression. This daily variation in microglial synaptic phagocytosis was abrogated by global REV-ERBα deletion, which caused persistently elevated synaptic phagocytosis. This work uncovers the BMAL1-REV-ERBα axis as a regulator of complement expression and synaptic phagocytosis in the brain, linking circadian proteins to synaptic regulation.

Introduction

The circadian clock orchestrates 24 hr rhythms in various cellular processes through transcriptional-translational feedback loops in most cells of the body (Takahashi, 2017). At the core of the clock’s positive limb is the bHLH-PAS transcription factor BMAL1, which heterodimerizes with CLOCK or NPAS2 to drive the transcription of large sets of clock-controlled genes (Mohawk et al., 2012). BMAL1 transcriptional targets include the negative limb feedback regulator CRY and PER proteins, as well as REV-ERBα and β, nuclear receptors which can also inhibit the actions of the positive limb (Preitner et al., 2002; Retnakaran et al., 1994). Disruption of this circadian machinery is associated with various pathophysiological states including cancer, diabetes, and neurodegeneration (Everett and Lazar, 2014; Musiek and Holtzman, 2016; Sulli et al., 2018). Deletion of BMAL1 abrogates circadian clock function and leads to an ~80% decrease in REV-ERBα expression in the brain (Musiek et al., 2013). REV-ERBα functions as a transcriptional repressor in many tissues and has been implicated in regulation of metabolism and inflammation (Everett and Lazar, 2014). Previous work from our group shows that deletion of BMAL1 or its downstream target REV-ERBα causes neuroinflammation and impaired brain functional connectivity (Griffin et al., 2019; Musiek et al., 2013). Diminished BMAL1 and REV-ERBα expression have also been described in mouse models of Alzheimer’s disease (AD)(Lee et al., 2020; Stevanovic et al., 2017). In AD, memory-associated, synapse-rich regions such as the hippocampus are affected early in the disease course (Braak et al., 2006). Synaptic loss also precedes neuronal death in neurodegeneration (Selkoe, 2002). Circadian dysfunction is also a well-described symptom of AD and other neurodegenerative diseases (Musiek and Holtzman, 2016; Videnovic et al., 2014). Therefore, elucidating the how clock proteins regulate synaptic health is an important step in understanding the connection between circadian dysfunction and neurodegeneration.

A wealth of recent studies have emphasized the critical role of the complement system of the brain in regulating neuroinflammation and synaptic integrity. Synapses labeled with the opsonins C1q and C3 (Stevens et al., 2007) were first described to be pruned by microglia during development (Schafer et al., 2012). C4 protein, encoded by the mouse C4b gene, also contributes to synaptic pruning by microglia in vivo (Sekar et al., 2016Comer et al., 2020). Complement-dependent microglial synaptic pruning has also been implicated in the pathogenesis of neurodegenerative and neuropsychiatric diseases (Hong et al., 2016; Litvinchuk et al., 2018; Sekar et al., 2016; Werneburg et al., 2020). Microglial activation is subject to circadian regulation (Fonken et al., 2015; Hayashi et al., 2013), and we have previously described that deletion of BMAL1 or REV-ERBα can induce microglial activation (Griffin et al., 2019; Musiek et al., 2013). Given the roles of the clock in neurodegeneration and microglial activation, we explored a potential role of the core clock in regulating synaptic health. Herein, we establish a link between the BMAL1-REV-ERBα axis, complement expression, and microglial synaptic pruning in the hippocampus.

Results

Disruption of the BMAL1-REV-ERBα axis induces complement upregulation in multiple brain cell types

While analyzing our previously published transcriptomic dataset from global Bmal1 knockout (BMKO) hippocampal tissue, we observed a striking upregulation of several complement transcripts, in particular C4b and C3 (Griffin et al., 2019), two genes which are critical for synaptic phagocytosis (Figure 1A). Other complement-related transcripts including C1qc, C1qb, C1qa, and C1ra were also increased in BMKO hippocampus (Figure 1A). Analysis of second published microarray dataset from our group which was derived from cerebral cortex samples from brain-specific Bmal1 KO mice (Nestin-Cre;Bmal1f/f) mice (Lananna et al., 2018) also revealed specific upregulation of C4b, but less so for other complement factors (Figure 1A). C4b was similarly increased in cerebral cortex samples from 4mo tamoxifen-inducible global BMAL1 KO mice (CAG-CreERT2;Bmal1f/f) in which Bmal1 was deleted at 2mo, demonstrating that this is not a developmental phenomenon (Figure 1—figure supplement 1).

Figure 1 with 2 supplements see all
REV-ERBα regulates complement expression in multiple cell types downstream of BMAL1.

(A) Relative expression of complement-related transcripts taken from microarray analysis performed on hippocampus from 5mo REV-ERBα KO (RKO) and littermate WT mice (N = 3/genotype), global BMAL1 KO mice (BKO, N = 2), or 12mo Nestin-Cre;Bmal1f/f mice (NCre+), and littermate Cre- controls (NCre-, N = 3/group). Colors indicate fold change versus control. (B) qPCR analysis of 11 month old control (Cre-) and neuron-specific Bmal1 KO mice (Camk2a-iCre+;Bmal1fl/fl) for complement genes (N = 3–4/group). (C) qPCR analysis of control (Cre-) and astrocyte-specific Bmal1 KO mice (Aldh1l1-CreERT2+;Bmal1fl/fl) for complement genes (N = 5 mice/group). (D) qPCR analysis of control (Cre-) and microglia-specific Bmal1 KO mice (Cx3cr1- CreERT2+;Bmal1fl/fl) for complement genes (N = 4–8/group). For C and D, all mice (Cre- or +) were treated with tamoxifen at 2mo and harvested at 4mo, mixed sexes, Cre- littermates were used as controls. (E) qPCR analysis of mRNA from primary cortical neurons isolated from Bmal1fl/fl mice, treated with AAV8-GFP (control) or AAV8-Cre (n = 4–5 wells/group). (F) qPCR analysis of WT or RKO mouse hippocampal tissue for complement genes (N = 5–10 mice/group). (G) Representative 40X maximum intensity projections of GFAP and C3 staining as well as the merged channel in the hippocampus of 5mo WT or RKO mice and the associated normalized volumes for C3-GFAP staining (n = 8 mice, N = 4/group). (H) Representative 40X maximum intensity projections of Iba1 and C3 staining as well as the merged channel in the hippocampus of 5mo WT or RKO mice. Scale bar = 100 µm. *p<0.05 **p<0.01 ***p<0.001, ns = not significant, by two-tailed T-test with Welch’s correction.

To determine the cell type(s) in which BMAL1 deletion induces complement gene expression, we examined cerebral cortex tissue from pan-neuronal-(CamK2a-iCre;Bmal1fl/fl) (Izumo et al., 2014), astrocyte- (Aldh1l1-CreERT2;Bmal1fl/fl) (Lananna et al., 2018), and microglia-specific (Cx3cr1-CreERT2;Bmal1fl/fl) (Parkhurst et al., 2013) BMAL1 knockout mice. Both astrocyte- and microglia-specific Bmal1 KO mice were treated with tamoxifen at 2mo and harvested 2 months later. Notably, C4b mRNA was strongly induced in the neuron-specific Bmal1 KO mice, while C3 was not (Figure 1B). C4b was also induced to a lesser degree in astrocyte-specific Bmal1 KO mice, although C3 was not (Figure 1C). Under basal conditions, neither C4b nor C3 was induced in microglia specific Bmal1 KO mice (Figure 1D). Deletion of Bmal1 in primary Bmal1fl/fl neuron cultures via infection with an AAV8-Cre viral vector (versus AAV8-eGFP control) suppressed the BMAL1 transcriptional target Nr1d1 (which encodes REV-ERBα) by 85% and induced C4b expression but caused no increase in C3 (Figure 1E). Bmal1 deletion also increased expression of Fabp7 (Figure 1E), a known target of REV-ERBα-mediated transcriptional repression (Schnell et al., 2014). As REV-ERBα mRNA (Nr1d1) is also suppressed by ~80% in the brain following brain-specific Bmal1 deletion (Figure 1—figure supplement 1), our data suggested that the upregulation of C4b gene expression observed with loss of BMAL1 could be mediated by transcriptional de-repression as consequence of downstream REV-ERBα loss. Accordingly, global deletion of REV-ERBα caused striking increases in C4b, C3, and other complement transcripts in the hippocampus as assessed by microarray analysis (Figure 1A) and confirmed in separate samples by qPCR (Figure 1F). Increased C3 protein expression was observed in activated astrocytes (Figure 1G, Figure 1—figure supplement 2) in the hippocampus of 5mo REV-ERBα KO (RKO) mice. There was less overlap of C3 expression and the microglial marker Iba1 (Figure 1H), although microglial C3 expression did increase in RKO brain (Figure 1—figure supplement 2). The finding that Bmal1 deletion in neurons (and to a less degree astrocytes) induces C4b mRNA but that C3 only increases in global BMKO and RKO mice suggests that REV-ERBα directly represses C4b expression in neurons and astrocytes, but the induction of C3 in both BMKO and RKO brain is likely secondary to a multicellular inflammatory glial activation which occurs over time.

REV-ERBα regulates microglial synaptic engulfment

We previously demonstrated that global REV-ERBα deletion induced microglial activation in vivo (Griffin et al., 2019). Given those results and the observation of increased C4b and C3 expression in RKO brains, we examined the possibility that these changes would enhance synaptic phagocytosis in 4–6mo RKO mice. We primarily focused on the mossy fiber synapses in the CA2/3 region of the hippocampus, as these large synapses (thorny excrescences) can easily be stained and imaged using standard confocal microscopy. Triple-labeling of tissue sections was performed with antibodies against synaptophysin (a marker of presynaptic neuronal terminals – Figure 2A), CD68 (a microglial lysosome marker – Figure 2B) and Iba1 (to define microglial cell bodies and processes – Figure 2C). CD68 was used to ensure that the colocalized synaptic material was actually within the microglia phagosome. 3D reconstructions were made and total volumes of engulfed synaptic material were calculated (Figure 2D, Figure 2—figure supplement 1). In the RKO microglia, we observed synaptic material in the microglial process and cell body (Figure 2Eii, Eiii), whereas WT microglia only had engulfed synaptic material in the cell body (Figure 2Ei). In all, we noted a 13.6-fold increase in engulfed synaptic material in the hippocampus of RKO mice compared to their WT littermates (Figure 2F).

Figure 2 with 1 supplement see all
REV-ERBα deletion increases synaptic phagocytosis in the CA3 region of the hippocampus.

(A-C) Image of synaptophysin (A), colocalized synaptophysin/CD68 (B), and colocalized synaptophysin/CD68/Iba1 (C) within microglia in the CA3 region of 4–6mo WT or RKO mice sacrificed at 11AM. D. Representative 3D surface rendering of microglia showing engulfed presynaptic material in lysosomes. (E) Magnified inset from WT (Ei) and RKO (Eii, iiii) microglia showing synaptophysin within CD68+ phagosomes. (F) Quantification of the normalized Iba1-CD68-Synaptophysin volumes from microglia in the CA3 region of the hippocampus of 4–6mo WT and RKO mice. Each point is the average of 3 sections from one mouse, N = 15 WT and 12 RKO mice. (G-H) Annotated, representative scanning electron micrographs of microglia in the CA3 of WT (G, pseudocolored Cyan) or RKO (H, pseudocolored Royal blue) mice sacrificed at 11AM with magnified inset pictures of engulfed presynaptic terminals (pseudocolored orange) in Hi and presynaptic terminals in contact with microglia (pseudocolored green) in Hii, Hiii, and Hiv. (I) Quantification of presynaptic terminals in contact with or engulfed by microglia in the CA3 of WT or RKO mice. Each point represents averaged data from a single mouse, N = 4 mice/genotype. In I, 3–15 microglia were counted per mouse. Scale bar for A–D = 5 µm. **p<0.01,***p<0.001 by two-tailed T-test with Welch’s correction.

To corroborate these results, we also performed large area scanning electron microscopy (SEM) experiments of the CA3 region of 4–6mo WT and RKO mice. Using this method, we visually confirmed an increased number of presynaptic terminals within or in contact with microglia in the hippocampus of RKO mice compared to WT (Figure 2G and H, 2H(i-v), 2I). We also noted downregulation in the expression of the Sirpa gene in our RKO mice which codes for the protein SIRPα (Figure 1A). SIRPα was recently described as a surface receptor on microglia that serves as a receptor for a ‘do-not-eat-me’ signal (Lehrman et al., 2018). Notably, Sirpa was not downregulated in Nestin-Cre-Bmal1 KO mice (Figure 1A), which have normal microglial BMAL1 and REV-ERBα expression, suggesting a possible cell-autonomous effect of REV-ERBα on microglial Sirpa expression. Taken together, our results suggest that REV-ERBα deletion induces synaptic engulfment.

CA3 synapses are reduced by REV-ERBα deletion

Following our observations of increased synaptic phagocytosis in the RKO mice, we investigated the status of the synapses in the CA3 region of the hippocampus. Synapses were double labeled by using the presynaptic marker synaptophysin and the postsynaptic marker homer1, followed by confocal imaging. In RKO mice, we observed a significant decrease in the synaptic volume in the CA3 region of the hippocampus by synaptophysin staining (Figure 3A), homer1 staining (Figure 3B), and their colocalization (Figure 3C) compared to their WT littermates. To further confirm these results, we counted synapses in large area SEM images from the stratum lucidum of WT or RKO mice. Again, we noted a decrease in the number of synapses in the RKO mouse CA3 by SEM, as compared to their WT littermates (Figure 3D).

Figure 3 with 3 supplements see all
REV-ERBα deletion induces synapse loss in the CA3 region.

(A) 60X representative maximum intensity projections showing synaptophysin staining in the CA3 of 4–6mo WT and RKO mice harvested at 11AM with the associated normalized volume quantification (N = 15 WT and 12 RKO mice). (B) 60X representative maximum intensity projections showing homer1 staining in CA3 of 4–6mo WT and RKO mice with the associated normalized volume quantification. (C) 60X representative maximum intensity projections showing colocalized synaptophysin and homer1 staining in CA3 of 4–6mo WT and RKO mice with the associated normalized volume quantification. (D) Representative scanning electron micrographs of synapses (presynaptic terminal pseudocolored in red, postsynaptic terminal in green), as well as the associated synapse counts for 4–6mo WT and RKO mice. N = 4 mice/genotype, with each point representing the average of 32–56 images counted per mouse. (E) 60X representative maximum intensity projections showing synaptoporin staining in the CA3 of 4–6mo WT and RKO mice. Colocalization with nuclei (DAPI) shown in lower images. (F) High-magnification images of synaptoporin staining of CA3 synapses from WT and RKO mice to show detail. (G). Normalized volume quantification of CA3 synaptoporin signal (N = 6 mice/genotype). *p<0.05, **p<0.01, ****p<0.0001 by two-tailed T-test with Welch’s correction. In all panels, each point represent the average of three sections from a single mouse. Scale bar = 50 µm in all panels except D.

To ensure that our observations were not due purely to changes in synaptophysin protein expression in the presynaptic terminal, synapses were also stained with a second presynaptic marker, synaptoporin, and quantified. Synaptoporin was used because it is enriched in the mossy fiber synapses of the hippocampus (Singec et al., 2002). Again, we observed a similar decrease in synaptic volume in CA3 of RKO mice compared to their WT littermates using synaptoporin staining (Figure 3E). Interestingly, we did not observe significant differences in synaptic volumes between WT and RKO mice in the CA1 region of the hippocampus (Figure 2—figure supplement 1), suggesting that some terminals may be more susceptible to loss than others. To determine whether the loss in synapses was due to a loss of neuronal cell bodies, we quantified the volume and width of neuronal nuclei of the dentate gyrus, which project to CA3, via NeuN staining. We found no significant difference between the neuronal nuclear width or volumes of the dentate gyrus between the WT and RKO mice (Figure 3—figure supplement 2). Moreover, we did not observe any change in 3-nitrotyrosine staining in the dentate gyrus, suggesting there is no increase in neuronal nitrosative stress in RKO mice (Figure 3—figure supplement 3). Taken together, our data suggest that deletion of REV-ERBα results in robust synaptic loss in the CA3 region without obvious neuronal loss.

Time-of-day variation in microglial phagocytosis is regulated by REV-ERBα

In mouse cerebral cortex and ventral midbrain, REV-ERBα displays daily oscillation in mRNA level with its peak around zeitgeber time (ZT) eight and its trough around ZT20 (Chung et al., 2014). We have also previously described oscillations in microglial activation, with low activation at ZT5 and high activation at ZT17 (Griffin et al., 2019). Consequently, we investigated microglial synaptic engulfment at these times of day. WT (C57BL/6) and RKO mice were sacrificed ZT17 (11PM), and hippocampal sections were triple labeled with Iba1, CD68, and synaptophysin, and compared to those sacrificed at ZT5 (11AM, shown in Figure 2). Microglia from the CA3 region of the hippocampus in WT mice sacrificed at ZT17 showed significantly more engulfed presynaptic protein than those at ZT5 (Figure 4A–C). When compared to the WT mice, RKO mice harvested at ZT5 and 17 showed a persistently increased level of synaptic engulfment in microglia, but with no time-of-day variation (Figure 4C), suggesting that daily oscillations in REV-ERBα may mediate rhythms in microglial synaptic phagocytosis. To further establish these findings, we used large area SEM to count the number of presynaptic terminals in contact with or within microglia at ZT17, and compared to mice harvested at ZT5 (shown in Figure 2G–H). In that experiment, we also noted a higher number of presynaptic terminals in contact with and within the microglia at ZT17 (Figure 4D–F). As a final confirmation of this finding, we injected Cx3cr1GFP mice, which express GFP in microglia (Jung et al., 2000), with an AAV-Camk2a-mCherry viral vector in the retrospenial cortex, to express mCherry in neurons. 4 weeks later, we collected brain samples at ZT5 and 17, and calculated the volume of mCherry+ material in individual GFP+ microglia. We observed that microglia at 11PM (ZT17) showed a qualitative increase in mCherry engulfment as compared to those at 11AM (ZT5) (Figure 4—figure supplement 1). Overall, our data establish a REV-ERBα-dependent rhythm for the engulfment of neuronal materials by microglia in the brain.

Figure 4 with 2 supplements see all
Time-of-day oscillation in microglial phagocytosis.

Representative 3D surface rendering of Iba1, CD68 and synaptophysin in Iba1+ microglia from 6mo WT mice sacrificed at (A) 11AM or (B) 11PM with inset. Scale bar = 5 µm. (C) The normalized volume quantification of Iba1-CD68-Synaptophysin showing microglial phagocytosis of synapses in WT and RKO mice harvested at 11AM or 11PM (N = 4–12 mice/group). Note that the data from the WT AM and RKO AM groups was shown in Figure 2F. (D-F) Representative scanning electron micrographs of microglia in the CA3 of WT mice sacrificed at 11AM (D) or 11PM (E) as well as a high-magnification inset of presynaptic terminals within the microglia (Ei). (F) Quantification of presynaptic terminals in contact with or engulfed by microglia in WT mice sacrificed at 11AM or 11PM. N = 4 mice/timepoint, 4–10 fields of view each. Note that the WT AM group was shown in Figure 2I. *p<0.05, ***p<0.001 by two-tailed T-test with Welch’s correction.

Discussion

The current study shows that loss of the circadian protein BMAL1 causes upregulation of complement gene C4b in neurons and astrocytes, as well as increase astrocytic C3 expression, changes which are recapitulated by loss of downstream REV-ERBα-mediated transcriptional repression. Deletion of REV-ERBα leads to microglial activation, increased C4b and C3 mRNA expression, increased astrocyte C3 protein expression, and increased microglial synaptic phagocytosis in CA3 region of the hippocampus. Finally, we demonstrate a time-of-day variation in synaptic phagocytosis in the hippocampus of WT mice which is antiphase to REV-ERBα levels and lost after REV-ERBα deletion. Our findings suggest that the BMAL1-REV-ERBα axis regulates daily rhythms in synaptic phagocytosis, and that loss of REV-ERBα de-represses complement gene expression and locks the brain in a pro-phagocytic state.

The mechanisms by which BMAL1 deletion leads to increased C4b expression are complex and multicellular but likely depend on REV-ERBα, although contributions of other pathways cannot be excluded. REV-ERBα expression is decreased by ~85% following BMAL1 deletion, and REV-ERBα deletion phenocopies the complement gene expression increases seen in Bmal1 KO brain. Indeed, it is well established that REV-ERBα functions as a transcriptional repressor (Harding and Lazar, 1995). Loss of REV-ERBα-mediated repression is a general mechanism governing increased transcript expression following BMAL1 deletion - as evidenced by strong upregulation of the REV-ERBα repression target Fabp7 following BMAL1 deletion (Schnell et al., 2014). Notably, we queried an existing REV-ERBα ChIP-seq database from brain tissue (Zhang et al., 2015), and did not find any peaks corresponding to C4b. However, REV-ERBα is known to regulate transcription not only by direct binding to RORE and RevDR2 sites but also by regulating enhancer function and eRNA expression to alter gene expression in trans (Lam et al., 2013), and by altering chromatin looping (Kim et al., 2018). Thus, it is likely that REV-ERBα regulates C4b expression in one of these alternative ways which is not apparent by typical ChIP-seq. Tissue-specific deletion of BMAL1 shows that this BMAL1-REV-ERBα axis controls C4b expression in neurons and astrocytes, but not in microglia. Recent single-nucleus RNAseq data suggests that C4b is prominently expressed in oligodendrocytes (Zhou et al., 2020). However, we have not yet evaluated the effect of BMAL1 or REV-ERBα deletion on C4b in this cell type. Presumably, C4b expression is low in neurons and astrocytes under normal conditions but is increased by BMAL1 or REV-ERBα deletion. Work from the Stevens and McCarroll labs identified C4b expression in neurons which then tagged synapses and facilitated synaptic pruning, and showed that deletion of C4b prevents accumulation of C3 protein at synapses, as C4 protein in upstream of C3 activation in the classical complement pathway (Sekar et al., 2016). Moreover, neuronal overexpression of mouse C4 can drive microglial synaptic phagocytosis and cause functional connectivity deficits in mice (Comer et al., 2020), two phenotypes observed by us in RKO mice.

Bmal1 KO and RKO mice at 5–6mo also show an increase in C3 transcript and C3 protein in astrocytes. However, tissue-specific Bmal1 deletion in neurons or astrocytes causes pronounced C4b increases but no C3 increases, suggesting that C3 expression in astrocytes and microglia is a secondary response to increased neuroinflammation in aged global Bmal1 KO or RKO mouse brain. Global inducible Bmal1 KO mice also do not show C3 induction at 2mo post-tamoxifen (despite high C4b expression), as these mice have not developed a full neuroinflammatory response at that age. Our data suggest that full induction of C3 in BMKO and RKO brain requires a multicellular, time-dependent inflammatory response involving microglia, as Nestin-Cre-Bmal1 KO mice, which have Bmal1 deletion in neurons and astrocytes but not microglia, have increased C4b expression but normal C3 and Sirpa levels. We have previously shown that REV-ERBα deletion increases microglial activation, Traf2 expression, and increased NFκB signaling (Griffin et al., 2019). Thus, REV-ERBα loss in microglia may be necessary, but not sufficient, to induce astrocyte C3 expression. Indeed, activated microglia can readily induce astrocyte C3 in response to LPS (Liddelow et al., 2017). NFκB signaling has also been shown to increase C3 expression and release from astrocytes (Lian et al., 2015). Functionally, C4 loss is associated with less synaptic tagging with C3 and thus less synaptic pruning (Sekar et al., 2016), suggesting that C4 expression can drive C3-dependent synapse pruning. Additionally, we noted that REV-ERBα regulated the microglial ‘do-not-eat-me’ signal Sirpa (encoding SIRPα) in our microarray data. Loss of inhibitory signaling from SIRPα makes microglia more likely to prune synapses, since SIRPα is primarily expressed on microglia in the CNS (Lehrman et al., 2018; Zhang et al., 2014). Therefore, our data suggest that de-repression of C4b in neurons and Traf2 in astrocytes and microglia, as well as diminished Sirpa expression in microglia, lead to a ‘perfect storm’ of complement expression and microglial activation that promotes synaptic phagocytosis (Figure 4—figure supplement 2). Detailed future studies using combinations of tissue-specific REV-ERBα mutants will be needed to elucidate this complex interaction.

We focused on the CA2/3 mossy fiber synaptic boutons because they are large and easily labeled with synaptic vesicle markers – in this case synaptoporin and synaptophysin (Grosse et al., 1998). However, we did not observe synapse loss in the CA1 region, which may represent a regional variability in BMAL1-REV-ERBα mediated synaptic pruning. Certainly, it is possible that certain synapses are more susceptible to pruning than others, and this should be addressed in the future. We cannot exclude the possibility that REV-ERBα deletion causes neuronal damage, which elicits microglial phagocytosis of dysfunctional synapses. Indeed, neuronal C4b upregulation could be a damage signal, although this has not been established. However, the absence of neuronal cell body loss or increased 3-nitrotyrosine in the dentate gyrus of RKO mice shows that there is no overt neurodegenerative response. These dentate gyrus granule cells give rise to the mossy fiber boutons in the CA3 (Scharfman and Myers, 2012), which are clearly decreased in RKO mice. Thus, the effect of REV-ERBα appears to be specific to the synapses.

Herein, we establish REV-ERBα as a regulator of microglial synaptic phagocytosis. However, we have previously reported that time-of-day changes in microglial morphology were abrogated by REV-ERBα deletion (Griffin et al., 2019). Herein, we observed that microglia engulfed more CA3 synapses at 11PM (ZT17) than at 11AM (ZT5). This was evident by both immunofluorescence and by electron microscopy. REV-ERBα deletion abrogated this time-of-day variation in synaptic protein phagocytosis, as RKO mice had high levels of phagocytosis at both timepoints. This data parallels our previous findings with microglial morphologic changes and suggests that REV-ERBα mediates daily changes in the degree of microglial synaptic engulfment, with both microglial activation and synaptic phagocytosis increasing when REV-ERBα levels are low. Accordingly, REV-ERBα deletion appears to lock the system in one of the extremes of this naturally occurring diurnal variation.

Several studies have illustrated the complexity of the interplay between cellular rhythms and sleep in regulating synapses in the brain (Bellesi et al., 2017; Brüning et al., 2019; Noya et al., 2019). RKO have subtle alterations in sleep but show grossly normal circadian rhythms in activity and are not sleep deprived (Mang et al., 2016), suggesting that sleep alteration is a possible but less likely contributor to the synaptic phenotypes in RKO mice. A previous study in the rat prefrontal cortex found that synaptic elimination was highest at ZT0 (Choudhury et al., 2020). While we did not examine ZT0, it is worth noting that these studies were done in the prefrontal cortex suggesting potential brain region-specific pruning patterns by time of day. Heterogeneity in synaptic pruning has already been described, with areas such as the cerebellum exhibiting greater microglial phagocytic capacity (Ayata et al., 2018). Future work will have to explore the patterns in microglial phagocytosis across more brain regions.

This work has clear implications for neurodegenerative and neuropsychiatric diseases, which have been linked to circadian disruption as well as complement dysregulation and synapse loss. Since REV-ERBα is a nuclear receptor with available small-molecule ligands (Solt et al., 2012), our findings suggest that it could be a therapeutic target for neurological and psychiatric disease. In previous studies in the brain, activation of REV-ERBs appears to suppress microglial cytokine production (Griffin et al., 2019) while inhibition of REV-ERBs can induce microglial amyloid-beta uptake and decrease plaque burden in mice (Lee et al., 2020). Effects on synaptic engulfment should be considered as REV-ERB-based therapeutics are developed.

Materials and methods

Key resources table
Reagent type
(species) or resource
DesignationSource or referenceIdentifiersAdditional information
AntibodyGfap (Rabbit polyclonal)Dako/AgilentCat# Z0334
RRID:AB_10013382
IF (1:2500)
AntibodyC3 (Rat monoclonal)NovusCat# NB200-540
RRID:AB_10003444
IF (1:500)
AntibodyIba1 (Goat polyclonal)AbcamCat# ab5076
RRID:AB_2224402
IF (1:500)
AntibodySynaptophysin (Mouse monoclonal)AbcamCat# 8049
RRID:AB_2198854
IF (1:100)
AntibodyHomer1 (Rabbit polyclonal)Synaptic SystemsCat# 160 003
RRID:AB_887730
IF (1:500)
AntibodyCD68 (Rat monoclonal)BioRadCat# MCA1957
RRID:AB_322219
IF (1:250)
AntibodyNeuN (Mouse monoclonal)EMD/MilliporeCat# MAB377
RRID:AB_2298772
IF (1:1000)
Antibody3-Nitrotyrosine (Rabbit polyclonal)Millipore/
Sigma
Cat# AB5411
RRID:AB_177459
IF (1:1000)
Genetic reagent (mouse)Bmal1 (Arntl)-/- miceJackson LabsCat# 009100 - B6.129-Arntltm1Bra/J
RRID:IMSR_JAX:009100
Genetic reagent (mouse)Bmal1(flox/flox) miceJackson LabsCat# 007668-B6.129S4(Cg)Arntltm1Weit/J
RRID:IMSR_JAX:007668
Genetic reagent (mouse)Nr1d1-/- mouseJackson LabsCat# 018447- B6.Cg-Nr1d1tm1Ven/LazJ
RRID:IMSR_JAX:018447
Rev-Erbα KO mouse line
Genetic reagent (mouse)Nestin-Cre miceJackson LabsCat# 003771- B6.Cg-Tg(Nes-cre)1Kln/J
RRID:IMSR_JAX:003771
Nestin-Cre line crossed to Bmal1f/f
Genetic reagent (mouse)Aldh1l1-CreERT2 miceJackson LabsCat# 031008- B6N.FVB-Tg(Aldh1l1-cre/ERT2)1Khakh/J
RRID:IMSR_JAX:031008
Aldh1l1-CreER line crossed to Bmal1f/f
Genetic reagent (mouse)Cx3cr1-CreERT2 miceJackson LabsCat# 021160- B6.129P2(Cg)Cx3cr1tm2.1(cre/ERT2)Litt/WganJ
RRID:IMSR_JAX:021160
Cx3cr1-CreER line crossed to Bmal1f/f
Genetic reagent (mouse)CAG- CreERT2 miceJackson LabsCat# 004682-B6.Cg-Tg(CAG-cre/Esr1*)5Amc/J
RRID:IMSR_JAX: 004682
CAG-CreER line crossed to Bmal1f/f
Genetic reagent (mouse)Camk2a-iCre BAC TG miceObtained from Dr. J. Takahashi. Created by Dr. Gunther SchutzMGI symbol: Tg(Camk2a-cre)2Gsc
RRID:MGI:4457404
BAC Tg Camk2a-iCre mouse
Sequence-based reagentActb (mouse)Thermo-Fisher/Life TechnologiesTaqman qPCR primer
Cat#: Mm02619580_g1
Sequence-based reagentNr1d1 (mouse)Thermo-Fisher/Life TechnologiesTaqman qPCR primer
Cat#: Mm00520708_m1
Sequence-based reagentC4b (mouse)Thermo-Fisher/Life TechnologiesTaqman qPCR primer
Cat#: Mm00437893_g1
Sequence-based reagentC3 (mouse)Thermo-Fisher/Life TechnologiesTaqman qPCR primer
Cat#: Mm01232779_m1
Sequence-based reagentFabp7 (mouse)Thermo-Fisher/Life TechnologiesTaqman qPCR primer
Cat#: Mm00437838_m1
Software, algorithmImarisBitplane, South Windsor, CTRRID:SCR_007370Version 9, used for image analysis.
Software, algorithmPrizmGraphPad Software, LLC.RRID:SCR_002798Version 8.3.0

Mice

Nr1d1+/-mice on C57bl/6 background were obtained from The Jackson Laboratory (Bar Harbor, ME) and bred at at Washington University. Heterozygous mice were bred together to generate Nr1d1+/+ (wt) and Nr1d1-/- (referred to as REV-ERBα KO or RKO) littermates which were used for experiments. For all experiments, a mix of male and female mice was used. No obvious difference between sexes was noted, though experiments were not powered to detect sex differences. WT mice were C57Bl/6J mice from Jackson Labs. Constitutive Bmal1-/- (BMKO), CAG-CreERT2, Aldh1L1-CreERT2, Cx3cr1-CreERT2, and Bmal1fl/fl mice were obtained from the Jackson Laboratory, and bred so that mice were heterozygous for Cre and homozygous for the floxed Bmal1 allele. In these experiments, Cre-;Bmal1f/f littermates were used as controls. All inducible knockout lines were were treated with tamoxifen (Sigma) dissolved in corn oil via oral gavage, 2.5 mg/day for 5 days, at 2mo. Camk2a-iCre+;Bmal1fl/fl mice were bred at University of Texas- Southwestern Medical Center. Cx3cr1GFP mice were obtained from The Jackson Laboratory. Mice were housed on a 12/12 light/dark cycle and fed ad libitum. All procedures performed on the mice were approved by the Washington University IACUC.

Immunohistochemistry

Request a detailed protocol

The following primary antibodies were used (with dilution): Gfap (Rabbit polyclonal, 1:2500, Dako/Agilent Cat# Z0334), C3 (Rat monoclonal, 1:500, Novus Biologicals Cat# NB200-540), Iba1 (Goat polyclonal, 1:500, Abcam Cat# ab5076), Synaptophysin (Mouse monoclonal, 1:100, Abcam Cat# ab8049), CD68 (Rat monoclonal, 1:250, BioRad, Cat# MCA1957), Homer1 (Rabbit polyclonal, 1:500, Synaptic Systems Cat# 160 003), Synaptoporin (Rabbit polyclonal, 1:1000, Synaptic Systems Cat# 102 002), NeuN (Mouse monoclonal, 1:1000, EMD/Millipore Cat# 14-5698-82). Specificity of all antibodies was confirmed via staining without primary antibody, and in the case of the anti-C3 antibody, was tested in C3 KO mouse tissue.

Mice were anesthetized with intraperitoneal (i.p.) injection of pentobarbital (150 mg/kg), followed by pump perfusion for three mins with ice cold Dulbecco’s modified Phosphate Buffered Saline (DPBS) containing 3 g/l heparin sulfate. One hemisphere was drop fixed in 4% paraformaldehyde (PFA) for 24 hr at 4°C, then cryoprotected with 30% sucrose in PBS also at 4°C for at least 48 hr. Brains were embedded in OCT and frozen in acetone with dry ice. Twelve μm serial coronal sections were cut on a cryostat and mounted directly onto the glass slides for synaptic pruning analysis or synaptic quantification. Sections were washed three times in Tris buffered saline (TBS), blocked for 45 min in TBS containing 20% goat (or donkey) serum, 2% Mouse-on-mouse (M.O.M) blocking reagent and 0.4% Triton X-100 (Sigma-Aldrich, St. Louis, MO). Sections were then incubated in TBS containing 10% goat (or donkey) serum, 8% M.O.M protein concentrate and 0.4% Triton X-100 with primary antibody overnight at 4°C. Sections were then washed three times and incubated for 4 hr at room temperature with 1:1000 fluorescent secondary antibody in a solution of TBS containing 10% goat (or donkey) serum, 8% M.O.M protein concentrate and 0.4% Triton X-100. For other non-synaptic staining, 50 μm serial coronal sections were cut on a freezing sliding microtome and stored in cryoprotectant (30% ethylene glycol, 15% sucrose, 15% phosphate buffer in ddH2O). Sections were washed three times in Tris buffered saline (TBS), blocked for 30 min in TBS containing 3% goat serum and 0.25% Triton X-100 (Sigma-Aldrich, St. Louis, MO) then incubated in TBS containing 1% goat serum and 0.25% Triton X-100 with primary antibody overnight at 4°C. Sections were then washed three times and incubated for 1 hr at room temperature with 1:1000 fluorescent secondary antibody and mounted on slides. Confocal images were taken on the Nikon Elements software on the Nikon A1Rsi scanning confocal microscope. Z-stacks were taken at a step size of 0.5–1 µm from dark to dark through the tissue.

Microarray analysis

Request a detailed protocol

Previously-published transcriptomic datasets were analyzed for expression of complement transcripts. Both datasets were from Agilent 4 × 44 k mouse microarrays. One dataset was derived from 5- to 6-month-old Bmal1 and REV-ERBα KO mice with WT littermate controls, and used hippocampal tissue. This dataset was previously published (Griffin et al., 2019) and is freely available on the Array Express Server: https://www.ebi.ac.uk/arrayexpress/experiments/E-MTAB-7590. The second dataset was derived from Nestin-Cre;Bmal1f/f mice (and Cre- controls) aged to 12 months, and used cerebral cortex tissue. This dataset was also previously published (Lananna et al., 2018) and is also available on Array Express Server: https://www.ebi.ac.uk/arrayexpress/experiments/E-MTAB-7151. For this dataset, the samples harvested at 6pm are shown.

Quantitative PCR

Request a detailed protocol

Flash-frozen brain tissue was homogenized with a mechanical handheld homogenizer for 20 seconds in RNA kit lysis buffer (PureLink RNA Mini Kit, Life Technologies, Carlsbad, CA) plus 1% β-mercaptoethanol. RNA was then purified using the kit protocol. Cells well collected and lysed in Trizol (Life Technologies). The aqueous layer was collected following chloroform extraction (added at 1:5 then spun at 13,000xg for 15 min) with RNA isolation protocol. RNA concentrations were then measured using the Nanodrop spectrophotometer and cDNA was made using a high-capacity RNA-cDNA reverse transcription kit (Applied Biosystems/LifeTechnologies) with 1 μg RNA used per 20 μL reaction. Real-time quantitative PCR was performed with Taqman primers and PCR Master Mix buffer (Life Technologies) on the ABI StepOnePlus 12 k Real-Time PCR thermocyclers. β-actin (Actb) mRNA levels were used for normalization during analysis. The following primers were used (all from Life Technologies, assay number is listed): Actb: Mm02619580_g1, Nr1d1: Mm00520708_m1, C4b: Mm00437893_g1, C3: Mm01232779_m1, Fabp7: Mm00437838_m1.

Electron microscopy

Request a detailed protocol

Animals were perfused with a fixative mix consisting of 2.5% glutaraldehyde + 2% paraformaldehyde (fresh, EM grade) in 0.15 M cacodylate buffer with 2 mM CaCl2 (final concentrations). Brains were extracted, blocked, and 100 µm coronal sections were made using a Leica 1200S vibratome. Tissues were then washed 3 × 10 min in cold cacodylate buffer containing 2 mM calcium chloride, and then incubated in a solution of 1% OsO4 containing 3% potassium ferrocyanide in 0.3M cacodylate buffer with 4 mM calcium chloride for 1 hr in the dark. Following incubation, tissues were incubated for 20 min in a 1% thiocarbohydrazide (TCH) solution, rinsed 3 × 10 min in ddH2O at room temperature and thereafter placed in 2% osmium tetroxide (NOT osmium ferrocyanide) in ddH20 for 30 min, at room temperature. Tissues were washed 3 × 10 min at room temperature in ddH2O then placed in 1% uranyl acetate (aqueous) and incubated at 4° overnight. Tissues were incubated in a lead aspartate solution at 60°C oven for 30 min, washed 5 × 3 min in ddH2O, and returned to the lead aspartate solution at 60°C for 30 min. Tissues were washed 3 × 10 min in room temperature ddH2O and dehydrated in 50%, 70%, 90%, 100%, 100% acetone (anhydrous), 10 min each. Samples were embedded in Durcupan ACM resin and polymerized 60°C oven for 48 hr. Seventy nm slices were made using a Leica UC7 ultramicrotome, and sections were picked up on a Si wafer (Ted Pella, Redding, CA). Images were acquired on a Zeiss Merlin FE-SEM using a solid state backscatter detector (8kV, 900 pA) at 7 nm resolution with 5 µs pixel dwell times and 4x line averaging. Large area scans of ~150 µm x 150 µm field of view were acquired and stitched using Atlas 5.0 (Fibics, Ottawa, Canada).

Stereotactic surgery and intracortical viral injections

Request a detailed protocol

Stereotactic viral vector injections were performed on Cx3cr1GFP mice. Briefly, mice were anesthetized with inhaled isoflurane, the head was shaved and the skull exposed and cleaned with iodine, and the head supported in ear bars. A hole was drilled through the skull. The coordinates used for the retrospenial cortex were 0.3 mm mediolateral (M/L), −2 mm anterior-posterior(A/P) and −1 mm dorso-ventral(D/V) with bregma as a reference. The needle was placed in the target location and then allowed to rest for 2 min before infusion. The AAV2-Camk2a-mCherry virus was obtained from the UNC viral vector core and infused at a rate of 0.2 µL/min. In total, the mice were injected with 2 μL in the retrospenial cortex. After the infusion, we waited 5 min for the virus to diffuse in the parenchyma and then the needle was slowly removed. The skin over the skull was then stitched up and antibiotic was applied to the area. The mice were then allowed to recover in an empty cage on a heating pad. After the surgery the mice were checked twice daily, 4 hr apart to ensure survival for 3 days. The mice were then allowed to age for 1 month before being sacrificed for sectioning and imaging.

Synaptic volume and engulfment analysis/3D reconstructions

Request a detailed protocol

Imaris visualization and analysis software (Version 9, Bitplane, South Windsor, CT, USA) was used at the Washington University Center for Cellular Imaging. For all analyses, Z-stacks were saved in the. nd2 file format and loaded into the software. 3-D surfaces had a surface detail ranging from 0.1 to 0.3 μm. To quantify the volume of the synapses, we generated 3-D surfaces from each of the synaptic markers (Synaptophysin, Synaptoporin and Homer1). We used the Batch colocalization function to colocalize the Synaptophysin and Homer1 volumes. The total volume for each Z-stack was summed. For the synaptic engulfment analyses, we first generated volumes from synaptophysin, CD68 and Iba1 staining. We then colocalized the synaptophysin volume with the CD68 volume. The resulting volume was then colocalized with the Iba1 volume to produce a final microglial synaptic engulfment volume. All values were normalized to the average values for the control group in each experiment.

Primary neuronal cultures

Request a detailed protocol

Neuronal cultures were made from age E18 Bmal1f/f mouse pups. Cortices plus hippocampi were dissected and stripped of meninges in ice-cold DMEM (Life Technologies) and then incubated in 0.05% Trypsin-EDTA at 37°C for 15 min. Tissue was gently triturated in 37°C DMEM plus 10% FBS (Gibco). Triturated cells were transferred to a second tube to remove debris, then diluted in Neurobasal (Life Technologies) plus B27 (Life Technologies) prior to plating on a PDL-coated plates. Cells were treated with 1 uM cytosine arabinoside for 24 hr, after which media was replaced. On DIV 4, Bmal1f/f neuron-enriched cultures were treated with either AAV8-CMV-GFP or AAV8-CMV-Cre for 4 days. Media was then again changed, and cells were harvested for in Trizol reagent at DIV 10.

Statistical analysis

Request a detailed protocol

Statistical analyses were performed using GraphPad Prism 8. We performed t-tests with Welch’s correction for multiple comparisons.

Data availability

The microarray data used in Fig. 1 is available on ArrayExpress E-MTAB-7590 and E-MTAB-7151. We have also uploaded all of the raw data from all of the figures in the paper as Source Files and to Dryad, which is available at: https://doi.org/10.5061/dryad.nzs7h44p1. This includes all of the image quantification data. Raw image files were not uploaded, as there are several hundred and they exceed 20GB.

The following data sets were generated
    1. Musiek ES
    2. Griffin P
    3. Sheehan PW
    4. Dimitry JM
    5. Guo C
    6. Kanan MF
    7. Lee J
    8. Zhang J
    (2020) Dryad Digital Repository
    REV-ERBα mediates complement expression and circadian regulation of microglial synaptic phagocytosis.
    https://doi.org/10.5061/dryad.nzs7h44p1
The following previously published data sets were used
    1. Musiek ES
    (2014) ArrayExpress
    ID E-MTAB-7151. Microarray analysis of mouse cerebral cortex from brain-specific Bmal1 knockout and Per1;Per2 double mutant mice at 2 timepoints.
    1. Musiek ES
    (2018) ArrayExpress
    ID E-MTAB-7590. Microarray of hippocampus from 5mo wt, Bmal1 KO and Nr1d1 (Rev-Erb-alpha) KO mice at a single timepoint.

References

Decision letter

  1. Louis J Ptáček
    Reviewing Editor; University of California, San Francisco, United States
  2. Huda Y Zoghbi
    Senior Editor; Texas Children's Hospital, United States
  3. Laura Fonken
    Reviewer

In the interests of transparency, eLife publishes the most substantive revision requests and the accompanying author responses.

Acceptance summary:

While a connection between circadian regulation and immune system function is well appreciated, characterizing details of this interaction is an exciting step forward.

Decision letter after peer review:

Thank you for submitting your article "REV-ERBα mediates complement expression and circadian regulation of microglial synaptic phagocytosis" for consideration by eLife. Your article has been reviewed by two peer reviewers, and the evaluation has been overseen by Louis Ptacek as Reviewing Editor and Huda Zoghbi as the Senior Editor. The following individual involved in review of your submission has agreed to reveal their identity: Laura Fonken (Reviewer #1).

The reviewers have discussed the reviews with one another and the Reviewing Editor has drafted this decision to help you prepare a revised submission.

We would like to draw your attention to changes in our revision policy that we have made in response to COVID-19 (https://elifesciences.org/articles/57162). Specifically, when editors judge that a submitted work as a whole belongs in eLife but that some conclusions require a modest amount of additional new data, as they do with your paper, we are asking that the manuscript be revised to either limit claims to those supported by data in hand, or to explicitly state that the relevant conclusions require additional supporting data.

Our expectation is that the authors will eventually carry out the additional experiments and report on how they affect the relevant conclusions either in a preprint on bioRxiv or medRxiv, or if appropriate, as a Research Advance in eLife, either of which would be linked to the original paper.

Summary:

Griffin et al. submit "REV-ERBα mediates complement expression and circadian regulation of microglial synaptic phagocytosis" for publication in eLife. Using global and targeted gene deletion of BMAL1 and REV-ERBα, the authors provide evidence for the role of REV-ERBα as an integral component in targeted synaptopathy of the CA3 region via indirect complement activation and suggest REV-ERBα's role as a repressor of complement activation. This work and further understanding of the BMAL1-REV-ERBα axis provide a new target for therapeutic intervention in neurodegenerative disease. While the data have pivotal implications and are important to the field, the paper lacks clarity in some of the claims made. We have the following suggestions for improvement:

Essential revisions:

1) One statistical issue that should be addressed throughout the paper is related to power of studies and analyses. For example:

a) In Figure 1A: n = 2 for BMAL1 KO mice. For these microarray data, and n=3 would be more suitable.

b) In Figures 2I, 3D, 4F, I, data should be analyzed on a per mouse basis with at least n = 3 mice. As is, n = 2 mice/genotype and statistics are performed on data points such as number of microglia or synapses (i.e. n=50 microglia counted/mouse, n=2 mice). These data should be analyzed as the average of those 50 microglia per mouse and compared to the average of other mice with an n=3 mice/genotype at minimum. All data should be displayed as an average of the sections analyzed from a single mouse. Representing the data any other way would be inappropriate.

2) Please note the sex of the mice. This should at minimum be mentioned in the Materials and methods (animals section). If females were included, it would be interesting to add sex as a covariate in analyses as there a sex differences in a number of neurodegenerative and neuropsychiatric disorders. If females were not included, this should be justified per NIH guidelines.

3) The figures would benefit from additional representative images. For example, in Figure 1, the separate channels should be shown in addition to the merged analysis. It was unclear from image 1G whether there was some bleed through of the channels. It would also be beneficial to show higher magnification images in 1G and H in order to better visualize the cell morphology. It was hard to see the microglia morphology with the Iba1 staining in 1H – although the microglia 3D reconstruction looked great in subsequent figures. Also, high levels of co-localization are reported in 1H but it was not apparent in the representative image. Perhaps add arrows?

4) In image 3E, it is hard to identify if these pictures are taken in the same region. It might be helpful to include a lower magnification image with a box identifying where you are zooming in to higher magnification.

5) "In the brain, REV-ERBα displays daily oscillations on the mRNA level – with its peak at zeitgeber time (ZT) 8 (2pm) and its trough at ZT20 (2am) (Chung et al., 2014)." – REV-ERBα, like other clock genes, likely displays distinct peak timing in different brain regions (for example, see PMID 26271538). Please adjust this sentence accordingly. Also, it is not necessary to include am and pm time in this sentence.

6) A few of the conclusions were overstated. For example, the first sentence of the Discussion states: "The current study shows that loss of the circadian protein BMAL1 causes upregulation of complement gene C4b in neurons and astrocytes, as well as increase astrocytic C3 expression, all via loss of downstream REV-ERBα mediated transcription repression." These experiments do not prove that BMAL1 causes upregulation of complement via REV-ERB (data is only correlative). In order to prove this occurs via REV-ERB, REV-ERB would need to be "rescued" in BMAL1 KO mice. This could potentially be tested with SR9009. Either this sentence should be adjusted or additional experiments performed. Also, the first sentence to the second paragraph should be changed (for the same reason).

7) The discussion on sleep, while interesting, seemed tangential to the results presented in this manuscript. Please remove.

https://doi.org/10.7554/eLife.58765.sa1

Author response

Essential revisions:

1) One statistical issue that should be addressed throughout the paper is related to power of studies and analyses. For example:

a) In Figure 1A: n = 2 for BMAL1 KO mice. For these microarray data, and n=3 would be more suitable.

b) In Figures 2I, 3D, 4F, I, data should be analyzed on a per mouse basis with at least n = 3 mice. As is, n = 2 mice/genotype and statistics are performed on data points such as number of microglia or synapses (i.e. n=50 microglia counted/mouse, n=2 mice). These data should be analyzed as the average of those 50 microglia per mouse and compared to the average of other mice with an n=3 mice/genotype at minimum. All data should be displayed as an average of the sections analyzed from a single mouse. Representing the data any other way would be inappropriate.

Regarding the array data in Figure 1A, we had originally included these two Bmal1 KO samples just for comparison to the Rev-Erbα KO samples, and we agree that at least 1 more is needed. Rather than rerun the array, we have now included data from a previous array on Bmal1 KO brain tissue that we have previously published (see revised Figure 1A). We examined the same complement transcripts in this other microarray dataset (published in Lananna et al., 2018), which is derived from brain-specific Bmal1 KO mice (Nestin-Cre;Bmal1(f/f) aged to 12mo). This second dataset also shows a strong upregulation of C4b, though not other complement components. Notably, Nestin-Cre;Bmal1(f/f) have Bmal1 expression preserved in microglia, suggesting that deletion of microglial Bmal1 may play a role in regulating some of the complement expression in the brain (such as C3). We have also altered the heatmap in Figure 1A to show each biological replicate, so it is clear that only 2 BMKO mice are present.

To address the issue of N vs. n in the EM experiments, we have repeated the experiments and added data from additional mice to bring the N to 4 for all experiments. We have altered the graphs such that the average from each mouse is shown, and statistics are now based on that.

For former Figure 4G-I, the time constraints needed to obtain more mice and virus, inject, and wait the appropriate time to repeat the experiment were prohibitive. Figure 4G-I is really just a third way of confirming the data that we present in Figure 4C and F. Thus, we have moved Figure 4G-I to the supplement, removed the statistical analysis, and clearly noted that it is a qualitative analysis meant as an adjunct to the data in Figure 4. If the reviewer is still concerned with this treatment, we can remove it entirely, though we feel that it still adds to the paper, even if the N is low.

2) Please note the sex of the mice. This should at minimum be mentioned in the Materials and methods (animals section). If females were included, it would be interesting to add sex as a covariate in analyses as there a sex differences in a number of neurodegenerative and neuropsychiatric disorders. If females were not included, this should be justified per NIH guidelines.

We used a mix of both male and female mice, and have now mentioned this in the Materials and methods. We attempted to mix them equally between experimental groups. We re-examined the data in Figure 2F by sex, as half of the mice were male, half female, and did not see a significant difference related to sex, though the experiment was generally not powered to detect sex differences.

3) The figures would benefit from additional representative images. For example, in Figure 1, the separate channels should be shown in addition to the merged analysis. It was unclear from image 1G whether there was some bleed through of the channels. It would also be beneficial to show higher magnification images in 1G and H in order to better visualize the cell morphology. It was hard to see the microglia morphology with the Iba1 staining in 1H – although the microglia 3D reconstruction looked great in subsequent figures. Also, high levels of co-localization are reported in 1H but it was not apparent in the representative image. Perhaps add arrows?

We appreciate this concern and have added additional images to make things more clear. We have now added each channel individually for Figure 1G and H, and have added a high-magnification inset image in both Figure 1G and H.

4) In Figure 3E, it is hard to identify if these pictures are taken in the same region. It might be helpful to include a lower magnification image with a box identifying where you are zooming in to higher magnification.

We agree that the representative images are a bit difficult to localize. In both cases, the images are taken of the CA3 mossy fiber region. We have now added lower-magnification images along with DAPI images to aid in localization (Figure 3E).

5) "In the brain, REV-ERBα displays daily oscillations on the mRNA level – with its peak at zeitgeber time (ZT) 8 (2pm) and its trough at ZT20 (2am) (Chung et al., 2014)." – REV-ERBα, like other clock genes, likely displays distinct peak timing in different brain regions (for example, see PMID 26271538). Please adjust this sentence accordingly. Also, it is not necessary to include am and pm time in this sentence.

Indeed, this is a good point, and we have not examined Rev-Erb phase across brain regions. We have previously shown Nr1d1 mRNA data from cerebral cortex, and Chung et al. showed Nr1d1 mRNA data from ventral midbrain, with similar peak/trough timing. Thus, we adjusted this sentence to read “In the mouse cerebral cortex and ventral midbrain, REV-ERBα displays daily oscillation on the mRNA level with its peak at zeitgeber time (ZT) 8 and its trough at ZT20”, and have removed the 2pm and 2am notes.

6) A few of the conclusions were overstated. For example, the first sentence of the Discussion states: "The current study shows that loss of the circadian protein BMAL1 causes upregulation of complement gene C4b in neurons and astrocytes, as well as increase astrocytic C3 expression, all via loss of downstream REV-ERBα mediated transcription repression." – These experiments do not prove that BMAL1 causes upregulation of complement via REV-ERB (data is only correlative). In order to prove this occurs via REV-ERB, REV-ERB would need to be "rescued" in BMAL1 KO mice. This could potentially be tested with SR9009. Either this sentence should be adjusted or additional experiments performed. Also, the first sentence to the second paragraph should be changed (for the same reason).

We appreciate this point, as a rescue experiment would be needed to definitively say that loss of Rev-Erbα mediates increases in C4b in Bmal1 KO mice. Bmal1 deletion results in functional near-deletion of Rev-Erbα (~80% decrease in mRNA, see Figure 1—figure supplement 2), so it is likely that the increase in C4b (which occurs in both BMKO and RKO brains) is due to loss of Rev-Erb. However, some Rev-Erb-independent effect may contribute in BMKO mice. We have adjusted the statements to reflect the realities of the data: “The mechanisms by which Bmal1 deletion leads to increased complement gene expression are complex and multicellular and likely depend on REV-ERBα, though contributions of other pathways cannot be excluded.”

Our concern with overexpression of Rev-Erbα in the BMKO brain is that titrating the amount of Rev-Erb expression such that it returns to basal levels (as opposed to gross overexpression) would be very difficult, and supra-physiological overexpression of Rev-Erb will suppress C4b expression artificially without necessarily excluding other pathways activated by Bmal1 KO. However, we can undertake this experiment if the reviewers think it is critical to the paper. Unfortunately, because Bmal1 deletion causes ~80% loss of Rev-Erbα/β expression, SR9009 generally does not work in general Bmal1 KO mice in our hands (as there is very little REV-ERB protein to activate).

7) The discussion on sleep, while interesting, seemed tangential to the results presented in this manuscript. Please remove.

We have removed some of the discussion of sleep, but have left some to address concerns raised by reviewer 2.

https://doi.org/10.7554/eLife.58765.sa2

Article and author information

Author details

  1. Percy Griffin

    Department of Neurology, Washington University School of Medicine in St. Louis, St. Louis, United States
    Contribution
    Conceptualization, Data curation, Formal analysis, Investigation, Methodology, Writing - original draft, Writing - review and editing
    Competing interests
    No competing interests declared
  2. Patrick W Sheehan

    Department of Neurology, Washington University School of Medicine in St. Louis, St. Louis, United States
    Contribution
    Formal analysis
    Competing interests
    No competing interests declared
  3. Julie M Dimitry

    Department of Neurology, Washington University School of Medicine in St. Louis, St. Louis, United States
    Contribution
    Data curation, Investigation
    Competing interests
    No competing interests declared
  4. Chun Guo

    Department of Pharmacological and Physiological Science, Saint Louis University School of Medicine, St. Louis, United States
    Contribution
    Investigation, Methodology
    Competing interests
    No competing interests declared
  5. Michael F Kanan

    Department of Neurology, Washington University School of Medicine in St. Louis, St. Louis, United States
    Contribution
    Investigation
    Competing interests
    No competing interests declared
  6. Jiyeon Lee

    Department of Neurology, Washington University School of Medicine in St. Louis, St. Louis, United States
    Contribution
    Investigation
    Competing interests
    No competing interests declared
  7. Jinsong Zhang

    Department of Pharmacological and Physiological Science, Saint Louis University School of Medicine, St. Louis, United States
    Contribution
    Investigation
    Competing interests
    No competing interests declared
  8. Erik S Musiek

    1. Department of Neurology, Washington University School of Medicine in St. Louis, St. Louis, United States
    2. Hope Center for Neurological Disorders, Washington University School of Medicine in St. Louis, St. Louis, United States
    Contribution
    Conceptualization, Supervision, Funding acquisition, Methodology, Writing - original draft, Project administration, Writing - review and editing
    For correspondence
    musieke@wustl.edu
    Competing interests
    No competing interests declared
    ORCID icon "This ORCID iD identifies the author of this article:" 0000-0002-8873-0360

Funding

National Institute on Aging (R01AG054517)

  • Erik S Musiek

National Institute on Aging (R01AG063743)

  • Erik S Musiek

Cure Alzheimer's Fund (Investigator award)

  • Erik S Musiek

Coins for Alzheimer's Research Trust (Investigator award)

  • Erik S Musiek

National Science Foundation (DGE- 1745038)

  • Percy Griffin

The funders had no role in study design, data collection and interpretation, or the decision to submit the work for publication.

Acknowledgements

This work was supported by awards from the Cure Alzheimer’s Fund (ESM), Coins for Alzheimer’s Research Trust (ESM), and NIH grants R01AG054517 and R01AG063743 (ESM). PG was supported by National Science Foundation Grant DGE-1745038. Imaging was performed with support from the Washington University Center for Cellular Imaging (WUCCI), which is funded by Washington University, Children’s Discovery Institute (CDI-CORE-2015–505), and the Foundation for Barnes-Jewish Hospital (3770). The authors thank Drs. Mariko Izumo and Joseph Takahashi (UT Southwestern Medical School) for providing brain tissue samples from Camk2a-iCre;Bmal1(f/f) mice.

Ethics

Animal experimentation: All experiments were conducted in accordance with recommendations in the Guide for the Care and Use of Laboratory Animals of the National Institutes of Health, and were approved by the institutional animal care and use committee (IACUC) at Washington University under protocol 2017-0124 (E. Musiek, PI).

Senior Editor

  1. Huda Y Zoghbi, Texas Children's Hospital, United States

Reviewing Editor

  1. Louis J Ptáček, University of California, San Francisco, United States

Reviewer

  1. Laura Fonken

Publication history

  1. Received: May 10, 2020
  2. Accepted: November 27, 2020
  3. Accepted Manuscript published: December 1, 2020 (version 1)
  4. Version of Record published: December 10, 2020 (version 2)

Copyright

© 2020, Griffin et al.

This article is distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use and redistribution provided that the original author and source are credited.

Metrics

  • 1,052
    Page views
  • 191
    Downloads
  • 1
    Citations

Article citation count generated by polling the highest count across the following sources: Crossref, PubMed Central, Scopus.

Download links

A two-part list of links to download the article, or parts of the article, in various formats.

Downloads (link to download the article as PDF)

Download citations (links to download the citations from this article in formats compatible with various reference manager tools)

Open citations (links to open the citations from this article in various online reference manager services)

Further reading

    1. Neuroscience
    Kristen Lee, Chris Q Doe
    Research Advance Updated

    Individual neurons can undergo drastic structural changes, known as neuronal remodeling or structural plasticity. One example of this is in response to hormones, such as during puberty in mammals or metamorphosis in insects. However, in each of these examples, it remains unclear whether the remodeled neuron resumes prior patterns of connectivity, and if so, whether the persistent circuits drive similar behaviors. Here, we utilize a well-characterized neural circuit in the Drosophila larva: the moonwalker descending neuron (MDN) circuit. We previously showed that larval MDN induces backward crawling, and synapses onto the Pair1 interneuron to inhibit forward crawling (Carreira-Rosario et al., 2018). MDN is remodeled during metamorphosis and regulates backward walking in the adult fly. We investigated whether Pair1 is remodeled during metamorphosis and functions within the MDN circuit during adulthood. We assayed morphology and molecular markers to demonstrate that Pair1 is remodeled during metamorphosis and persists in the adult fly. MDN-Pair1 connectivity is lost during early pupal stages, when both neurons are severely pruned back, but connectivity is re-established at mid-pupal stages and persist into the adult. In the adult, optogenetic activation of Pair1 resulted in arrest of forward locomotion, similar to what is observed in larvae. Thus, the MDN-Pair1 neurons are an interneuronal circuit – a pair of synaptically connected interneurons – that is re-established during metamorphosis, yet generates similar locomotor behavior at both larval and adult stages.

    1. Neuroscience
    Philipp Schlegel et al.
    Research Article Updated

    The hemibrain connectome provides large-scale connectivity and morphology information for the majority of the central brain of Drosophila melanogaster. Using this data set, we provide a complete description of the Drosophila olfactory system, covering all first, second and lateral horn-associated third-order neurons. We develop a generally applicable strategy to extract information flow and layered organisation from connectome graphs, mapping olfactory input to descending interneurons. This identifies a range of motifs including highly lateralised circuits in the antennal lobe and patterns of convergence downstream of the mushroom body and lateral horn. Leveraging a second data set we provide a first quantitative assessment of inter- versus intra-individual stereotypy. Comparing neurons across two brains (three hemispheres) reveals striking similarity in neuronal morphology across brains. Connectivity correlates with morphology and neurons of the same morphological type show similar connection variability within the same brain as across two brains.
