Role of distinct fibroblast lineages and immune cells in dermal repair following UV radiation-induced tissue damage

  1. Emanuel Rognoni  Is a corresponding author
  2. Georgina Goss
  3. Toru Hiratsuka
  4. Kalle H Sipilä
  5. Thomas Kirk
  6. Katharina I Kober
  7. Prudence PokWai Lui
  8. Victoria SK Tsang
  9. Nathan J Hawkshaw
  10. Suzanne M Pilkington
  11. Inchul Cho
  12. Niwa Ali
  13. Lesley E Rhodes
  14. Fiona M Watt  Is a corresponding author
  1. Centre for Stem Cells and Regenerative Medicine, King's College London, Guy's Hospital, United Kingdom
  2. Centre for Endocrinology, William Harvey Research Institute, Barts and The London School of Medicine, Queen Mary University of London, United Kingdom
  3. Research Center for Dynamic Living Systems, Graduate School of Biostudies, Kyoto University, Japan
  4. Division of Signaling and Functional Genomics, German Cancer Research Center (DKFZ), Germany
  5. Department of Cell and Molecular Biology, Medical Faculty Mannheim, Heidelberg University, Germany
  6. Division of Musculoskeletal and Dermatological Sciences, Faculty of Biology, Medicine and Health, School of Biological Sciences, Manchester Academic Health Science Centre, The University of Manchester and Salford Royal NHS Foundation Trust, United Kingdom
  7. The Francis Crick Institute, United Kingdom
https://doi.org/10.7554/eLife.71052
Share this article
Cite this article
  1. Emanuel Rognoni
  2. Georgina Goss
  3. Toru Hiratsuka
  4. Kalle H Sipilä
  5. Thomas Kirk
  6. Katharina I Kober
  7. Prudence PokWai Lui
  8. Victoria SK Tsang
  9. Nathan J Hawkshaw
  10. Suzanne M Pilkington
  11. Inchul Cho
  12. Niwa Ali
  13. Lesley E Rhodes
  14. Fiona M Watt
(2021)
Role of distinct fibroblast lineages and immune cells in dermal repair following UV radiation-induced tissue damage
eLife 10:e71052.
https://doi.org/10.7554/eLife.71052
  2. Download BibTeX
  3. Download .RIS

Abstract

Solar ultraviolet radiation (UVR) is a major source of skin damage, resulting in inflammation, premature ageing, and cancer. While several UVR-induced changes, including extracellular matrix reorganisation and epidermal DNA damage, have been documented, the role of different fibroblast lineages and their communication with immune cells has not been explored. We show that acute and chronic UVR exposure led to selective loss of fibroblasts from the upper dermis in human and mouse skin. Lineage tracing and in vivo live imaging revealed that repair following acute UVR is predominantly mediated by papillary fibroblast proliferation and fibroblast reorganisation occurs with minimal migration. In contrast, chronic UVR exposure led to a permanent loss of papillary fibroblasts, with expansion of fibroblast membrane protrusions partially compensating for the reduction in cell number. Although UVR strongly activated Wnt signalling in skin, stimulation of fibroblast proliferation by epidermal β-catenin stabilisation did not enhance papillary dermis repair. Acute UVR triggered an infiltrate of neutrophils and T cell subpopulations and increased pro-inflammatory prostaglandin signalling in skin. Depletion of CD4- and CD8-positive cells resulted in increased papillary fibroblast depletion, which correlated with an increase in DNA damage, pro-inflammatory prostaglandins, and reduction in fibroblast proliferation. Conversely, topical COX-2 inhibition prevented fibroblast depletion and neutrophil infiltration after UVR. We conclude that loss of papillary fibroblasts is primarily induced by a deregulated inflammatory response, with infiltrating T cells supporting fibroblast survival upon UVR-induced environmental stress.

Editor's evaluation

Your study adds important and novel information regarding how the skin responds to UV radiation and the subsequent repair and regenerative response.

https://doi.org/10.7554/eLife.71052.sa0

Introduction

Ultraviolet radiation (UVR) from the sun penetrates the skin and has both positive and negative impacts on human health (Hart et al., 2019). While UVR is essential for vitamin D synthesis, prolonged (chronic) UVR exposure contributes to the development of skin cancer (photo-carcinogenesis) and accelerates ageing (photoageing) (Debacq-Chainiaux et al., 2012; Bernard et al., 2019). UVR is a small component of solar radiation and comprises high-energy UVC (wavelength 100–280 nm), lower-energy UVB (280–315 nm), and UVA (315–400 nm) wavebands. UVC is absorbed by stratospheric ozone while UVA and UVB penetrate the skin. Chronic UVR damages the DNA, lipids, and proteins of skin cells directly (photochemical reactions) or indirectly via inflammation, reactive oxygen species (ROS) production, and matrix metalloproteinase (MMP) secretion (Bernard et al., 2019; Naylor et al., 2011; Watson et al., 2014; Shih et al., 2018).

The connective tissue of the skin, the dermis, comprises distinct layers known as the papillary, reticular, and dermal white adipose tissue (DWAT) layers (Driskell et al., 2013; Rinkevich et al., 2015). During mouse skin development, multipotent fibroblasts differentiate into distinct subpopulations (lineages) that form the different layers. These fibroblast lineages differ in location and function, and their cell identity and composition change with age (Rognoni et al., 2016; Rognoni and Watt, 2018). While papillary fibroblasts beneath the basement membrane have an active Wnt signalling signature and are required for hair follicle formation, fibroblasts in the reticular dermal layer express high levels of genes associated with extracellular matrix (ECM) and immune signalling and mediate the initial phase of wound repair (Driskell et al., 2013; Rognoni et al., 2016; Philippeos et al., 2018). During mouse skin development, dermal maturation is governed by a tight balance between fibroblast proliferation, quiescence, and ECM deposition. Within the first week of postnatal life, there is a coordinated switch in fibroblast behaviour from proliferative to quiescent, which is governed by ECM deposition/remodelling (Rognoni et al., 2018). While this quiescent state characterises postnatal skin, upon wounding different fibroblast lineages are stimulated to proliferate and migrate into the wound site (Eming et al., 2014). Besides depositing/remodelling ECM in the wound bed, fibroblasts are able to acquire a dermal papilla or adipocyte fate in response to distinct signals and thereby promote hair follicle and DWAT regeneration, respectively (Gay et al., 2013; Lim et al., 2018; Plikus et al., 2017). After tissue repair, the quiescent state of fibroblasts is restored.

UVA and UVB induce different types of photo-damage in skin. UVB penetrates the epidermis and papillary dermis, while UVA affects the full thickness of the dermis, including the subcutaneous fat (Watson et al., 2014; Barnes et al., 2010). Photoaged dermis is characterised by a loss of fibroblast density and changes in ECM organisation, including depletion of fibrillin-rich microfibers in the papillary dermis and accumulation of elastin-rich elastic fibres in the reticular dermis, which are mediated, at least in part, by MMP activity (Naylor et al., 2011; Watson et al., 2014; Wlaschek et al., 2001; Scharffetter-Kochanek et al., 2000). In addition, UVR is a potent local and systemic immune modulator, able to modify the innate and adaptive immune response (Bernard et al., 2019). Collectively, the activated signalling pathways and recruitment of distinct immune subsets lead to an immunosuppressive environment which supports inflammation resolution of a sunburn reaction and tissue repair but can also contribute to skin cancer.

While the consequences of UVR exposure for the epidermis, ECM, and skin-resident immune network have been widely characterised (Debacq-Chainiaux et al., 2012; Bernard et al., 2019; Watson et al., 2014), its short- and long-term impact on different dermal fibroblast subpopulations (lineages) is unknown. In this study, we have examined how dermal fibroblast lineages respond to acute and chronic UVB irradiation. Uncovering the UVR-induced early pathogenic processes leading to premature skin ageing and a cancer-permissive environment will pave the way for new treatment strategies that target aberrant fibroblast behaviour (Sahai et al., 2020). There is growing interest in the specific impact of UVB radiation on human health as ambient UVB will increase with destruction of the ozone layer (United Nations EEAP 2019 report: Environmental Effects and Interactions of Stratospheric Ozone Depletion, UV Radiation, and Climate Change, https://ozone.unep.org/science/assessment/eeap).

Results

Acute UVR exposure results in a transient loss of fibroblasts in the papillary dermis

We began by determining the effect of acute UVB exposure on human dermal fibroblasts (Hawkshaw et al., 2020). For this study, six healthy volunteers (two males, four females; mean age 44 ± 12 years) were recruited. Their buttock skin was exposed to three times their individual minimal erythema dose (MED), sufficient to induce a moderate sunburn reaction characterised by histone H2AX phosphorylation (yH2AX), a central component of the DNA damage response and repair system, and cyclobutane pyrimidine dimer (CPD) accumulation in papillary fibroblasts (Barnes et al., 2010). Skin biopsies were collected from irradiated skin at time points up to 14 days post-UVR and subjected to double immunofluorescence labelling for CD39 (papillary fibroblast marker) and vimentin (VM, a pan-fibroblast marker) (Philippeos et al., 2018; Figure 1A). Quantifying and plotting fibroblast density changes over time in skin sections of individual healthy volunteers revealed a loss of CD39/VM double-positive cells in the upper dermis, which was followed by a transient increase in the repair phase before returning to pre-UVR treatment level within 2 weeks.

Figure 1 with 2 supplements see all
Download asset Open asset
Acute UVB exposure depletes fibroblasts in the papillary dermis.

(A) Immunostaining of human skin for CD39 (green) and vimentin (VM) (red) and quantification of double-positive cells per field of view relative to control skin at indicated time points after acute ultraviolet radiation (acUVR) exposure (n = 6 biological replicates). (B) Experimental design of mouse acUVR model (top panel), representative images of skin erythema (middle panel), and H&E skin section (bottom panel), showing epidermal hyperplasia and increased dermal cell density 1 day after acUVR. (C, D) Representative PDGFRαH2BEGFP sections (green) stained for yH2AX (C), and cCasp3 (D) (red) of control and treated skin and quantification of double-positive cells at indicated time points post-acUVR. Note that the epidermis and upper dermis show pronounced DNA damage (yH2AX+) with clusters of apoptotic cells (cCasp3+) 24 hr post-acUVB. (E) Immunostaining of PDGFRαH2BEGFP back skin (green) for all lymphocytes (CD45; red) and quantification of the CD45 mean fluorescence intensity at indicated time points post-UVR. (F, G) Quantification of dermal fibroblast density (PDGFRαH2BEGFP+) (F) and total dermal density (DAPI+) (G) 24 hr after acUVB in the upper and lower dermis. (H) Representative PDGFRαH2BEGFP sections (green) stained for Ki67 (red) of control and treated skin and quantification of double-positive cells at indicated time points post-acUVR. Note that the epidermis and upper dermis show increased proliferation 4 days after acUVB.Nuclei labelled with DAPI and dashed white line delineates upper and lower dermis. Scale bars, 50 μm. Data are mean ± SD. *p<0.05, **p<0.01, ***p<0.001. Source data of shown quantifications are summarised in Figure 1—source data 1.

Figure 1—source data 1

Source data of quantifications represented as graphs in Figure 1.

https://cdn.elifesciences.org/articles/71052/elife-71052-fig1-data1-v2.xlsx

To uncover how different dermal fibroblast subpopulations are affected by UVB irradiation, we established an acute (ac)UVR mouse model consisting of two consecutive UVB exposures (800 J/m2) separated by 2 days, which induced moderate skin erythema – equivalent to a mild sunburn reaction in humans (Figure 1B; Shih et al., 2018; Thieden et al., 2005; Gyöngyösi et al., 2016). Histology revealed epidermal hyperplasia, UVB-induced angiogenesis, increased dermal immune cell infiltration, and temporary swelling of the papillary and reticular dermis at 1 day after UVB exposure (Figure 1B, Figure 1—figure supplement 1A and B). To study the effect of UVB on fibroblasts, we used the PDGFRαH2BEGFP transgenic mouse line, in which all dermal fibroblasts express nuclear GFP (Hamilton et al., 2003; Collins et al., 2011; Figure 1C, D, E and H). Quantification of PDGFRαH2BEGFP-positive cells showed a significant loss of upper dermal fibroblasts 1, 4, and 8 days after the second UVB exposure followed by a repair phase (Figure 1F), recapitulating the human in vivo findings (Figure 1A). The decrease in upper dermal fibroblasts correlated with an increase in DNA damage, measured by the phosphorylation of histone H2AX (yH2AX+) (Figure 1C), and apoptosis (cCasp3+) in dermal fibroblasts, particularly in the papillary dermis, 1 and 4 days post-UVB (Figure 1D). The number of immune cells (CD45+) increased markedly 1 day after irradiation and remained elevated for several days (Figure 1E, Figure 1—figure supplement 1C), accounting for the increase in total dermal cell density (DAPI+) during tissue repair (Figure 1G). Fibroblast proliferation increased at days 4 and 8, particularly in papillary fibroblasts, returning to normal thereafter (Figure 1H). No αSma+ dermal fibroblasts were present, indicating that UVB did not stimulate differentiation into myofibroblasts (Figure 1—figure supplement 1D). We also noted that acUVB did not induce changes in the ECM that were detectable by collagen hybridising peptide (CHP) labelling, a molecular probe that recognises the triple helix structure of immature, damaged, and remodelling interstitial collagen fibres (Figure 1—figure supplement 1E; Hwang et al., 2017).

To elucidate if distinct fibroblast subpopulations respond differently to UVR and cell stress, we reanalysed a published single-cell RNA-seq dataset of neonatal (P2) and adult (P21) mouse back skin (Phan et al., 2020; Figure 1—figure supplement 2A–D). As previously shown, neonatal fibroblasts clustered into papillary, reticular, preadipocytes, adipocytes, and other fibroblast subpopulations (Figure 1—figure supplement 2A), and adult fibroblasts could be divided into five major clusters. Gene Ontology (GO) analysis of differentially expressed genes between neonatal fibroblast subpopulations revealed that selected GO terms related to DNA damage, DNA repair, apoptosis, and cell stress were predominantly enriched in papillary fibroblasts, whereas expression of genes associated with GO term ‘response to UV’ or ‘cellular response to UV’ was not significantly increased in any fibroblast subpopulation at both time points (Figure 1—figure supplement 2B and D). Indeed, the enrichment of selected GO terms in papillary fibroblasts is due to their highly proliferative state in neonatal skin (Rognoni et al., 2018; Phan et al., 2020), rather than indicating a different susceptibility/response to UV damage. The overall enrichment of selected GO terms was much less pronounced in adult mouse skin (Figure 1—figure supplement 2D). Similarly, transcriptomic analysis of human sun-exposed eyelid skin (Zou et al., 2021) and microdissected breast skin (Philippeos et al., 2018) revealed that no significant GO term enrichment was associated with response to UVR or cell stress in identified fibroblast subpopulations or in the upper and lower dermis (Figure 1—figure supplement 2E–G).

We conclude that in mouse and human skin acute UVB exposure results in a transient loss of papillary fibroblasts, which is associated with dermal thickening, recruitment of immune cells, and an increase in yH2AX and cCasp3-positive fibroblasts in the early acute UVB response and is followed by dermal fibroblast proliferation 4 days after UVB treatment. Our transcriptomic and GO term analysis suggests that between different fibroblast subpopulations there are only minimal intrinsic differences in UV response, DNA damage/repair, and response to cell stress.

Chronic UVR induces long-term depletion of papillary fibroblasts and ECM changes

To test the impact of chronic UVR exposure on dermal fibroblasts, we established a chronic (ch)UVR model consisting of 800 J/m2 UVB exposure twice a week for 8 weeks. This chronic UVB treatment regime in C57BL/6 mice is rather mild compared to other recent studies (Bald et al., 2014; Dai et al., 2007; Ohkumo et al., 2006; Han et al., 2017; Meeran et al., 2009; Kunisada et al., 2005) and induces a prominent tanning response (melanin deposition) in UVR-exposed back skin without disrupting the epidermal barrier (Figure 2A). The moderate thickening of the epidermis correlated with an increase in Ki67-positive keratinocytes (Figure 2B). When the skin was examined 3 days after the final UVB treatment, there was no significant difference between control and chUVB-exposed dermis in terms of proliferation (Ki67+ fibroblasts) or apoptosis (cCasp3+ fibroblasts) (Figure 2B and C) and no αSma-positive interfollicular fibroblasts were detected (Figure 2—figure supplement 1A). However, there was an increased abundance of CD45-positive cells in the upper and lower dermis and an increase in blood vessels (Figure 2D, Figure 2—figure supplement 1B). As observed in photoaged skin (Watson et al., 2014), the ECM in chronically UVB-exposed skin was highly remodelled (Figure 2E and F). Herovici staining revealed accumulation of light blue-stained immature collagen, particularly beneath the basement membrane following UVR; in contrast, mature collagen in control skin stained pink/purple (Figure 2E). In addition, chUVR-treated skin showed significantly increased CHP staining, indicating that collagen fibres were damaged or actively remodelled (Figure 2F; Hwang et al., 2017). chUVR induced significant DNA damage in the epidermis and dermal fibroblasts, which was observed 1 day after the final UVB exposure. The damage was progressively repaired post-UVR exposure, as measured by staining for yH2AX+ cells (Figure 2G). Quantification of fibroblasts (PDGFRαH2BEGFP+) in the upper and lower dermis showed that cell density was significantly decreased in the upper dermis after the final dose of UVR and was not restored to control levels even after 30 days (Figure 2H). In contrast, chUVR did not affect the density of fibroblasts in the lower dermis. Total dermal cell density (DAPI+) transiently increased at 3 days post-UVR, probably due to infiltrating immune cells (Figure 2D and I).

Figure 2 with 1 supplement see all
Download asset Open asset
Chronic UVB irradiation leads to a permanent loss of papillary fibroblast in the upper dermis and changes in the extracellular matrix (ECM) environment.

(A) Experimental design (top panel), representative skin tanning (middle panel), and H&E section (bottom panel), showing epidermal hyperplasia, ECM changes, and increased dermal cell density after chronic UVB (chUVB). (B–D) Representative PDGFRαH2BEGFP sections (green) stained for Ki67 (B), cCasp3 (C), and CD45 (D) (red) of control and treated skin and quantification of either double-positive cells (Ki67 and cCasp3) or mean fluorescence intensity (CD45). While lymphocytes (CD45+ cells) are increased in the dermis, pronounced proliferation (Ki67+) and apoptosis (cCasp3+) are only observed in the epidermis after chUVB. (E) Herovici staining of control and chUVB-exposed skin sections. Note that pink/purple staining indicates mature collagen, whereas light blue-stained collagen in chUVB skin below the basement membrane is immature and actively remodelled. (F) Immunofluorescence staining of control and chUVB PDGFRαH2BEGFP skin (green) for CD45 (white) and collagen (red) using the collagen hybridising peptide (CHP)-biotin probe. Mean CHP fluorescence signal was quantified, and increased CHP signal in chUVB skin indicates a more fibrillar, open, and/or damaged collagen structure. White asterisks indicate unspecific CHP staining in sebaceous glands. (G) Immunostaining of control and chUVR-exposed PDGFRαH2BEGFP back skin (green) for yH2AX (red) and quantification of double-positive cells at indicated time points. Note that the epidermis and dermis show pronounced DNA damage (yH2AX+) at 24 hr after ultraviolet radiation (UVR) which is repaired over time. (H, I) Quantification of dermal fibroblast (PDGFRαH2BEGFP+) (H) and total dermal cell density (DAPI+) (I) after chUVB. (J) Comparison of acute UVR (acUVR) and chUVR fibroblast tissue damage repair response. While acUVR induced a transient fibroblast depletion caused by DNA damage, fibroblast apoptosis, and following proliferation, chUVR led to a persistent loss of fibroblasts in the papillary dermis. Nuclei were labelled with DAPI (blue), and dashed white line delineates upper and lower dermis. Scale bars, 50 μm. Data are mean ± SD. *p<0.05, **p<0.01, ***p<0.001. Source data of shown quantifications are summarised in Figure 2—source data 1.

Figure 2—source data 1

Source data of quantifications represented as graphs in Figure 2.

https://cdn.elifesciences.org/articles/71052/elife-71052-fig2-data1-v2.xlsx

We conclude that whereas acUVR leads to transient depletion of papillary fibroblasts, the effect is sustained after chronic treatment, correlating with more substantial ECM reorganisation. In contrast to acute UVR, there was minimal proliferation and apoptosis of dermal fibroblasts following chronic UVR (Figure 2J).

Only fibroblasts in the papillary dermis contribute to repair of UVR damage

To understand how different fibroblast subpopulations contribute to regeneration of the papillary layer after acUVR exposure, we performed lineage tracing (Figure 3A). Papillary fibroblasts can be specifically labelled with Lrig1-CreER, while Dlk1-CreER marks fibroblasts in the lower dermis when Cre-mediated recombination is induced at postnatal day 0 (P0) (Driskell et al., 2013; Rognoni et al., 2016). acUVR exposure of labelled transgenics confirmed the loss of papillary fibroblasts in the upper dermis, whereas Dlk1-CreER-labelled cells in the lower dermis were not affected (Figure 3B). At 4 days post-UVR, papillary lineage dermal cells started to repopulate the upper dermis. However, the density of cells was significantly reduced compared to control dermis (Figure 3B). There were no detectable changes in the arrector pili muscle, dermal sheath, and dermal papilla fibroblasts of hair follicles upon acUVR treatment (Figure 3B, Figure 1—figure supplement 1D), suggesting that these fibroblasts did not contribute to the repair of the damaged dermis (Rognoni et al., 2016; Kaushal et al., 2015).

Figure 3 with 1 supplement see all
Download asset Open asset
Only fibroblast lineages of the papillary dermis contribute to ultraviolet radiation (UVR)-induced tissue repair and fibroblasts in chronic UVR-exposed skin are more elongated.

(A, B) In vivo lineage tracing of distinct dermal fibroblast populations during tissue damage repair after acute UVB (acUVB). (A) Experimental design shows breeding strategy and skin isolation time points to follow fibroblast lineages during tissue repair. (B) Representative immunofluorescence image and quantification of Lrig1-CreER × tdTomato (top panels) and Dlk1-CreER × tdTomato (lower panels) back skin of control and acUVB-exposed skin after 1 and 4 days. Quantification shows labelled cells in the upper and lower dermis at indicated time points. (C, D) In vivo lineage tracing of distinct dermal fibroblast populations during chUVR. (C) Experimental design shows breeding and lineage-tracing strategy for chronic UVB (chUVB)-exposed skin. (D) Immunofluorescence image and quantification of Lrig1-CreER × tdTomato (top panels) and Dlk1-CreER × tdTomato (lower panels) back skin of control and chUVB-exposed skin 3 days after last UVR exposure. Quantification shows labelled tdTomato+ cells in the upper and lower dermis. (E, F) Closeup of Lrig1-CreER × tdTomato lineage-traced skin section showing cytoplasmic tdTomato signal (black) (E) and quantification of papillary fibroblast elongation in control and chUVB-exposed skin (F) (n = 300 cells from four biological replicates). Boxed areas in (E) indicate magnified fibroblasts shown below. Note that although fibroblast density in chUVB skin is reduced (D), fibroblast membrane protrusions are increased. (G) Summary of UVR-induced tissue damage and skin regeneration after acute and prolonged (chronic) UVB exposure. In healthy skin, papillary (green) and reticular (violet) fibroblasts are quiescent. After acUVR exposure, papillary fibroblasts are depleted and epidermal and dermal cells start proliferating (red nucleus) during the tissue repair response. While fibroblast density and skin homeostasis are restored after acUVB tissue damage, repeated UVB exposure leads to a permanent loss and elongation of papillary fibroblasts and changes in the extracellular matrix (ECM) structure characteristic of aged skin. Nuclei were labelled with DAPI (blue), and dashed white line delineates upper and lower dermis. Scale bars, 50 μm. Data are mean ± SD. *p<0.05, **p<0.01, ***p<0.001. Source data of shown quantifications are summarised in Figure 3—source data 1.

Figure 3—source data 1

Source data of quantifications represented as graphs in Figure 3.

https://cdn.elifesciences.org/articles/71052/elife-71052-fig3-data1-v2.xlsx

Next, we investigated how chUVR exposure impacted the papillary (Lrig1-CreER) and reticular (Dlk1-CreER) fibroblast lineages (Figure 3C). As in the case of acUVR exposure, Dlk1-CreER-labelled cells of the reticular dermis did not expand or contribute to tissue repair (Figure 3D). Lrig1-CreER-labelled cells were significantly reduced in the upper and lower dermis and showed a patchy distribution. Closer examination of papillary fibroblasts in chUVR skin revealed that, in contrast to acUVR exposure, their shapes were significantly elongated, suggesting that increased membrane protrusions may compensate for the fibroblast loss, as previously observed in aged skin (Marsh et al., 2018; Figure 3E and F, Figure 3—figure supplement 1).

We conclude that upon acUVR the upper dermis was replenished by papillary fibroblasts. In contrast, papillary fibroblasts in chUVR-treated skin were not replenished and instead changed shape, increasing their cell membrane protrusions (Figure 3G). The lower dermal lineage was unaffected by acute or chronic UVR.

Minimal movement of fibroblasts during the UVR tissue damage response

The number of fibroblasts in the papillary dermis was significantly lower in 1, 4, and 8 days post-acUVR skin than control (non-irradiated) skin (Figure 1F). To explore whether the papillary dermis was depleted and repopulated via cell migration, we performed live imaging of anaesthetised PDGFRαH2BEGFP mice 1 day and 4 days after acUVR exposure (Figure 4A). In each case, we recorded the movement of fibroblasts within defined fields up to 100 µm into the dermis, covering the papillary and upper reticular dermis, for 80 min. In agreement with previous measurements (Rognoni et al., 2018; Marsh et al., 2018), most fibroblasts in untreated adult skin maintained positional stability and showed minimal displacement over time (observed in three out of three imaged biological replicates) (Figure 4—figure supplement 1A, Figure 4—video 1).

Figure 4 with 4 supplements see all
Download asset Open asset
Fibroblasts in the papillary dermis become more motile during the ultraviolet radiation (UVR) tissue repair response.

(A) Experimental design for live imaging of adult PDGFRαH2BEGFP back skin during acute UVB (acUVB)-induced tissue damage repair. (B) Representative time-lapse images of adult PDGFRαH2BEGFP (green) dermis 1 day (upper panel, relates to Figure 4—video 2) and 4 days (lower panel, relates to Figure 4—video 3) post-acUVB with collagen shown as second harmonic generation (SHG) in blue at indicated imaging time points. Line indicates orthogonal closeup to follow vertical cell displacement, and box shows fibroblast movement in the horizontal plane. Arrowheads in closeups indicate cells migrating, and dashed line is for orientation. (C) Scatter plots of the displacement along the indicated axis (z-, red; x-, green; y-axis, blue) of individual control and acUVB-treated cells in their relative z-location (distance from epidermis). (D) Average mean cell displacement speed of imaged control and acUVB-exposed back skin after 1 and 4 days. (E) Scatter plots of mean velocity of individual cells in their relative z-location from representative control and acUVB-treated animals after 1 and 4 days post-UVB. Scale bars, 50 μm. *p<0.05. Source data of quantifications are summarised in Figure 4—source data 1.

Figure 4—source data 1

Source data of quantifications represented as graphs in Figure 4.

https://cdn.elifesciences.org/articles/71052/elife-71052-fig4-data1-v2.xlsx

Overall, we observed very little cell migration after acUVB exposure. At 1 day post-acUVB, for example, we could only find single papillary fibroblasts moving into the deeper dermis or within the horizontal plane (Figure 4B, top panel, Figure 4—video 2). Quantification of cell displacement in the horizontal and vertical directions indicated that fibroblasts were slightly more motile along the (z) axis 1 day post-irradiation compared to control skin (Figure 4C, Figure 4—figure supplement 1B). However, most fibroblasts displayed minimal displacement and the direction of the observed movement appeared heterogenous (Figure 4C, Figure 4—figure supplement 1B). At 4 days after UVR exposure, more fibroblasts showed increased random cell displacement within the horizontal and vertical dermal plane across the imaged dermis (Figure 4B and C, Figure 4—figure supplement 1B, Figure 4—video 3). Consistent with this, the average mean displacement speed of fibroblasts was more heterogenous at 1 day post-UVR compared to control skin and increased significantly at 4 days post-UVR (Figure 4D). Plotting the individual cell mean speed across the upper dermis revealed that fibroblasts with increased motility were present throughout the upper dermis at 4 days after UVR (Figure 4E).

We conclude that fibroblast depletion in the papillary layer in the early UVR response is not associated with cell migration, whereas at 4 days post-acUVR fibroblasts become more motile, which correlates with ECM remodelling and fibroblast redistribution (Figure 3B and G). The lack of directional migration indicates that fibroblast replenishment of the papillary dermis after UVR damage is a stochastic process similar to the fibroblast redistribution observed during dermal maturation and ageing (Rognoni et al., 2018).

Activation of epidermal Wnt signalling does not enhance dermal recovery after UVR exposure

Epidermal Wnt signalling is a potent regulator of fibroblast behaviour during skin development and wound healing (Driskell et al., 2013; Collins et al., 2011; Lichtenberger et al., 2016). To explore how Wnt/β-catenin signalling is regulated by UVR, we subjected TOPEGFP reporter mice to acUVR. In these mice, H2BeGFP is expressed under the control of multiple Lef1/TCF binding sites, allowing nuclear GFP expression to be used as a readout of Wnt/β-catenin signalling activity (Ferrer-Vaquer et al., 2010). Wnt/β-catenin activity was highly induced in epidermal and dermal cells at 1 and 4 days post-acUVR (Figure 5A), which coincided with fibroblast DNA damage repair and proliferation (Figure 1C and H). During tissue repair and fibrosis, Wnt signalling has been shown to cooperate with YAP/TAZ signalling at multiple levels (Piersma et al., 2015; Rognoni and Walko, 2019). Consistent with this, dermal fibroblasts of the papillary dermis and IFE keratinocytes displayed increased nuclear YAP localisation in acute and chronic UVR-exposed skin (Figure 5B, Figure 5—figure supplement 1).

Figure 5 with 1 supplement see all
Download asset Open asset
Induction of fibroblast proliferation is not sufficient to restore dermal homeostasis after ultraviolet radiation (UVR) exposure.

(A) Representative Wnt signalling reporter (TOPEGFP) sections of control and treated skin stained for Itga6 (red). H2BEGFP (green) is expressed under the control of multiple Lef1/TCF binding sites reporting active Wnt/β-catenin signalling (Ferrer-Vaquer et al., 2010).Quantification of TOPEGFP-positive dermal cells in control and UVR-treated skin is shown. Note that Wnt/β-catenin signalling is increased in the epidermis as well as in the dermis. (B) Representative PDGFRαH2BEGFP back skin sections (green) stained for YAP (red) 1 day after acute UVB (acUVB) exposure. Quantification of PDGFRαH2BEGFP-positive cells with nuclear YAP in the upper and lower dermis is shown. Nuclear YAP is increased in the papillary dermis and IFE after acUVB exposure. (C) Experimental strategy for increasing fibroblast proliferation during acUVB damage tissue repair by stabilising epidermal β-catenin (Krt14ΔNβ-cat transgenic). (D) Representative PDGFRαH2BEGFP back skin sections (green) of indicated transgenics stained for Ki67 (red) 8 days post-UVR. Dashed box indicates closeup area shown in the lower panel. (E, F) Quantification of dermal fibroblast density (PDGFRαH2BEGFP+) (E) and proliferation (Ki67+ PDGFRαH2BEGFP cells) (F) in the indicated treatment conditions. Nuclei were labelled with DAPI (blue), and dashed white line delineates upper and lower dermis. Scale bars, 50 μm. Data are mean ± SD. *p<0.05, **p<0.01, ***p<0.001. Source data of quantifications shown are summarised in Figure 5—source data 1.

Figure 5—source data 1

Source data of quantifications represented as graphs in Figure 5.

https://cdn.elifesciences.org/articles/71052/elife-71052-fig5-data1-v2.xlsx

To test whether induction of fibroblast proliferation by epidermal Wnt signalling modified the response to UVR, we crossed PDGFRαH2BEGFP mice with Krt14ΔNβ-cat mice, which express stabilised β-catenin under the control of the Krt14 promoter upon tamoxifen application (Figure 5C). Analysing fibroblast distribution 8 days post-UVR and epidermal β-catenin stabilisation in PDGFRαH2BEGFP × Krt14ΔNβ-cat transgenics revealed that fibroblasts predominantly proliferated and expanded around existing and ectopic hair follicles in the lower dermis (Figure 5D–F). However, this increased abundance of fibroblasts failed to efficiently repopulate the interfollicular dermis beneath the basement membrane and failed to restore fibroblast homeostasis and organisation in the papillary dermis.

In conclusion, although Wnt signalling is activated by UVR in the upper and lower dermis, increasing fibroblast proliferation by genetically stabilising epidermal β-catenin was not sufficient to improve fibroblast regeneration of the papillary dermis.

Dermal fibroblast survival is supported by cutaneous T cells that become activated and expand throughout the dermis after UVR exposure

The inflammatory response to UVR is well documented; however, the impact on different fibroblast subpopulations is unclear. Neutrophils are the first immune cell type to infiltrate into the dermal region after UVB exposure (Savage et al., 1993; Katiyar et al., 1999), and this is followed by an influx of different T cell populations (Bernard et al., 2019). In our acUVR model, we observed an increase in CD45+ cells that persisted even after 14 days (Figure 1E, Figure 1—figure supplement 1C). The number of neutrophils increased in skin 1 day post-UVR (Figure 6—figure supplement 1A and B). This was followed by an increase in the abundance, proliferation, and activation of different T cell populations, specifically CD8+ cytotoxic T cells and FoxP3+ regulatory T cells (Tregs) at 5 days post-UVR. Immunofluorescence analysis and quantification of CD3, CD8, and FoxP3 labelling revealed that CD3+ T cells were depleted in the epidermis and increased in the dermis (Figure 6A, Figure 6—figure supplement 1C). Cytotoxic T cells (CD8+) that are enriched in the lower dermis in control skin were significantly increased in the upper dermis after UVR exposure (Figure 6B). Similarly, Tregs (FoxP3+) that are closely associated with hair follicles in homeostasis (Ali et al., 2017) significantly increased and expanded throughout the dermis at 3 days after acUVB exposure (Figure 6C). This is consistent with the observed immune cell behaviour in human skin upon UVB exposure where neutrophil infiltration is followed by an increase in accumulation, activation, and proliferation of different T cell populations (Hawkshaw et al., 2020; Rijken et al., 2006; Rhodes et al., 2009).

Figure 6 with 1 supplement see all
Download asset Open asset
Cutaneous T cells redistribute in response to acute UVB (acUVB) exposure and influence dermal fibroblast survival.

(A–C) Immunostaining of CD3 (CD3+ T cells) (A), CD8 (cytotoxic T cells) (B), and FoxP3+ (Tregs) (C), in red. Note the pronounced depletion of CD3+ T cells in the epidermis and redistribution of activated Tregs (white arrow heads) and cytotoxic T cells in the interfollicular dermis 3 days after acute ultraviolet radiation (acUVR). (D–I) CD4- and CD8-positive cell depletion increased fibroblast loss in the upper dermis after acUVB. (D) Experimental strategy for antibody-based immune cell depletion during acUVB (blue arrow, antibody injection; red arrow, UVB; green arrow, skin isolation) (top panel). Antibody depletion was assessed by FACS analysis of cutaneous CD4- and CD8-positive cells. Absolute number quantifications are for 6 cm2 (bottom panels). (E) Representative immunostaining of PDGFRαH2BEGFP back skin (green) for Ki67 (red) and αSma (white). (F–I) Quantification of dermal fibroblast density (PDGFRαH2BEGFP+) (F), DNA damage (yH2AX + PDGFRαH2BEGFP cells) (G), apoptosis (cCasp3 + PDGFRαH2BEGFP cells) (H), and proliferation (Ki67+ PDGFRαH2BEGFP cells) (I) after acUVB and indicated treatment conditions. Nuclei were labelled with DAPI (blue), and dashed white line delineates upper and lower dermis. Scale bar, 50 μm. IP, intraperitoneal injection. Data are mean ± SD. *p<0.05, **p<0.01, ***p<0.001. Source data of quantifications are summarised in Figure 6—source data 1.

Figure 6—source data 1

Source data of quantifications represented as graphs in Figure 6.

https://cdn.elifesciences.org/articles/71052/elife-71052-fig6-data1-v2.xlsx

To explore the functional consequences of the increase in different T cell populations after UVR, we depleted CD4+ and CD8+ cells with specific blocking antibodies before and during acUVB exposure (Figure 6D; Ali et al., 2017; Grcević et al., 2000; Hatton et al., 2007). Back skin from control and UVR-treated mice was isolated 24 hr after the last treatment, and flow cytometric analysis of skin and lymph nodes confirmed successful immune cell depletion (Figure 6D, Figure 6—figure supplement 1D and E). Depletion of either CD8+ or CD4+ cells significantly increased the loss of upper (papillary) fibroblasts (Figure 6E and F) and was associated with a significant increase in DNA damage (yH2AX + fibroblasts) and apoptosis (cCasp3+ fibroblasts) (Figure 6G and H) as well as a reduction in fibroblast proliferation (Ki67+) in the upper dermis but not in epidermal keratinocytes (Figure 6I, Figure 6—figure supplement 1F). Although total dermal cells (DAPI+) in the lower dermis were significantly increased, PDGFRαH2BEGFP-positive cells were unchanged in the reticular dermal layer (Figure 6F, Figure 6—figure supplement 1G). In contrast, αCD4 or αCD8 antibody treatment had no effect on fibroblasts in non-UVB-exposed skin and injections of antibodies against IgG did not change the acute UVR skin response (Figure 6—figure supplement 1H–K).

In summary, we observe that acUVB exposure leads to an infiltration of neutrophils that is followed by an increase and redistribution of different T cell subpopulations in the dermis. Depletion of CD4- and CD8-positive cells significantly impairs fibroblast survival and regeneration in the upper dermis after acUVB exposure by increasing DNA damage, apoptosis, and reducing fibroblast proliferation.

COX-2 inhibition prevents dermal fibroblast loss by controlling the inflammatory response to UVR exposure

Previous reports have suggested that CD4+ T cell depletion significantly increases and prolongs the acute UVB-induced cutaneous inflammatory response (Hatton et al., 2007). Acute UVR exposure induced the release of pro-inflammatory prostaglandins, including prostaglandin E2 (PGE-2) in the skin, which was further increased after CD4+ and CD8+ cell depletion (Figure 7A and B). Cyclooxygenase-2 (COX-2) is a key enzyme for prostaglandin synthesis and can be induced in multiple cell types in response to pro-inflammatory stimuli (Williams et al., 1999). Immunofluorescence analysis and quantification revealed that COX-2 expression was significantly increased in the epidermis and dermis, including fibroblasts, at 1 day post-acUVB before returning to baseline 4 days after UVR exposure (Figure 7C). Inhibition of COX-2 following UVB irradiation has been shown to inhibit several parameters of UVR-induced acute inflammation, including vascular permeability, infiltration of neutrophils, PGE-2 production, as well as acute oxidative damage (Wilgus et al., 2003; Wilgus et al., 2000). To test whether fibroblast depletion was mainly caused by an UVR-induced inflammatory response, we treated back skin topically with the COX-2 inhibitor celecoxib immediately after UVR exposure (Figure 7D). Notably, COX-2 inhibition significantly inhibited fibroblast depletion in the upper dermis and neutrophil infiltration (Ly6G+) after UVR treatment (Figure 7E–G). Furthermore, DNA damage in dermal fibroblasts (yH2AX+) was reduced (Figure 7H). In contrast, celecoxib treatment did not affect fibroblast proliferation (Ki67+) and total dermal cell density (DAPI+) after acute UVR exposure (Figure 7I and J).

Figure 7
Download asset Open asset
Inhibition of ultraviolet radiation (UVR)-induced inflammation increases fibroblast survival in the skin.

(A, B) Prostaglandin E2 (PGE-2) skin concentration 24 hr after acute UVB (acUVB) exposure (A) and in combination with CD4+ and CD8+ cell depletion (B). Note that antibody depletion of CD4+ and CD8+ cells further increases the PGE-2 concentration in acUVB-treated skin. (C) Representative PDGFRαH2BEGFP sections (green) stained for COX-2 (red) of control and treated skin and quantification of double-positive cells at the indicated time points post-acUVR. Note that the epidermis and dermis show pronounced increase in COX-2 expression 24 hr after acUVB exposure. (D–J) COX-2 inhibition decreased fibroblast loss. (D) Experimental design for topical treatment with celecoxib (COX-2 inhibition) immediately after acUVB exposure. (E) Representative immunostaining of PDGFRαH2BEGFP back skin (green) for Ki67 (red) and αSma (white) under the indicated treatment conditions. (F–J) Quantification of dermal fibroblast density (PDGFRαH2BEGFP+) (F), neutrophil infiltration (Ly6G+) (G), DNA damage (yH2AX+ PDGFRαH2BEGFP cells) (H), fibroblast proliferation (Ki67+ PDGFRαH2BEGFP) (I), and total dermal cells (DAPI+) (J) under the indicated experimental conditions. (K) Representative PDGFRαH2BEGFP sections (green) stained for EP4 (red) and quantification of the EP4 mean fluorescence intensity at the indicated time points post-UVR. (L) Immunostaining of human skin for EP4 receptor and quantification of EP4 in the epidermal and dermal areas per field of view at the indicated time points after acUVB exposure (n = 13 biological replicates). (M) Model of PGE-2-EP4 signalling in dermal fibroblasts after UVR exposure showing the influence on tissue damage response and survival in concert with T cells. Data are mean ± SD except (L), is ± SEM. *p<0.05, **p<0.01, ***p<0.001. Nuclei were labelled with DAPI (blue), and dashed white line delineates upper and lower dermis. Scale bars, 50 μm. Source data of quantifications are summarised in Figure 7—source data 1.

Figure 7—source data 1

Source data of quantifications represented as graphs in Figure 7.

https://cdn.elifesciences.org/articles/71052/elife-71052-fig7-data1-v2.xlsx

Besides inhibiting fibroblast proliferation, collagen synthesis, migration, and differentiation into myofibroblasts, PGE-2 has been recently shown to increase fibroblast apoptosis through E prostanoid (EP)2 and EP4 receptor signalling, resulting in activation of phosphatase and tensin homologue on chromosome 10 (PTEN) and downstream inhibition of protein kinase B /AKT, an important pro-survival signal (Huang et al., 2009). EP4 is the major EP receptor in skin (Regard et al., 2008) and is expressed by dermal fibroblasts (Joost et al., 2020; Sennett et al., 2015). Immunofluorescence analysis and quantification of EP4 showed that EP4 was strongly increased in the epidermis and dermis and remained elevated in the upper dermis up to 14 days post-UVR (Figure 7K). In line with this, immunostaining skin sections for EP4 in the UVB-treated human skin time course revealed that EP4 expression was significantly increased in the epidermis and dermis at 1 and 4 days after acUVB exposure before returning to lower levels after 7 days in both skin compartments (Figure 7L). These findings suggest that the UVB-induced increase in PGE-2 level and EP4 expression influences the dermal fibroblast UVB damage response and survival (Figure 7M).

In summary, we have shown that the loss of fibroblasts in the upper dermis is primarily induced by an UVR-induced inflammatory response involving PGE-2 and EP4 signalling that can be supressed by COX-2 inhibition. Our data suggest that infiltrating/activated T cells support fibroblast survival and regeneration following UVR-induced environmental stress by controlling the inflammatory response to UVR exposure (Figure 7M).

Discussion

In this study, we have elucidated the short- and long-term impacts of UVR exposure on different fibroblast lineages in the skin. We reveal that physiological doses of UVR are sufficient to severely deplete papillary fibroblasts in human and mouse skin, and that fibroblast survival is influenced by cutaneous T cells and PGE-2/EP4 receptor signalling. Our immunofluorescence, lineage tracing, and in vivo live imaging results showed that the loss of papillary fibroblasts is primarily due to apoptosis rather than movement of papillary fibroblasts into the deeper dermis. After acute UVR fibroblasts start proliferating, increase motility and restore tissue density. In contrast, prolonged exposure to UVR prevented repopulation of fibroblasts in the upper dermis even after 30 days post-UVR (Figure 2H). These observations are in line with previous studies of chronic UVB irradiation that reported a reduced cell density in the papillary dermis even 200 days after final UVB exposure (Dai et al., 2007). Loss of the papillary lineage is associated with premature skin ageing, reduced regeneration, and a profibrotic environment (Driskell et al., 2013; Rognoni et al., 2016; Phan et al., 2020; Lichtenberger et al., 2016).

We and others have recently shown how different fibroblast lineages contribute to dermal architecture and have explored their tissue-scale behaviour in development and skin regeneration (Rognoni et al., 2018; Marsh et al., 2018; Jiang et al., 2018). Deregulation of these complex processes is associated with several skin pathologies, including fibrosis, chronic wounds, and cancer. Comparison of the fibroblast lineage response during repair of full thickness wounds and UVR-induced tissue damage reveals several differences. While both forms of tissue damage induce a pronounced inflammatory response and activation of Wnt/β-catenin and YAP/TAZ signalling in the epidermis and dermis, UVR-induced tissue damage is repaired with minimal fibroblast proliferation, migration, and myofibroblast differentiation. We recently showed that ECM is a potent regulator of fibroblast behaviour and inhibits proliferation during skin development and regeneration (Rognoni et al., 2018). The inhibitory signal of the ECM can be partly overcome by overexpression of epidermal β-catenin, which induces the expression of several fibroblast growth factors (Lichtenberger et al., 2016). However, the induction of proliferation especially in the lower dermis was not sufficient to restore fibroblast organisation in UVR-damaged skin, which could be due to a lack of directional migration. Consistent with this, our lineage-tracing and in vivo live imaging experiments revealed that only fibroblasts in the upper dermis contribute to tissue repair (Figure 3G). While in the early UVR response (1 day post-UVR) fibroblast migration is limited to single cells, papillary fibroblasts become more motile at 4 days post-UVR, which could be due to ECM remodelling. In support of this concept, during skin homeostasis most dermal fibroblasts are stationary, yet active random fibroblast migration has been observed close to growing hair follicles where the surrounding ECM is extensively remodelled (Marsh et al., 2018). In contrast, upon full-thickness wounding, we and others have shown that fibroblasts start migrating towards the wound where they randomly distribute and expand during the early wound repair phase (Rognoni et al., 2018; Jiang et al., 2020). During wound healing, chemoattractants such as platelet-derived growth factor (PDGF) are key regulators of fibroblast chemotaxis (Melvin et al., 2011); however, the intrinsic and extrinsic signals controlling fibroblast migration after UVR exposure remain unclear.

Recent laser or genetic ablation experiments have revealed that loss of dermal fibroblasts is repaired through a mixture of proliferation/migration and reorganisation of the plasma membrane network (Marsh et al., 2018). Our data indicate that a similar mechanism may apply during repair of UVR-induced tissue damage. In contrast to acUVR tissue damage, in chUVR skin the decreased fibroblast density persisted in the papillary dermis and surviving fibroblasts were significantly elongated; in addition, fibroblast loss was compensated by an increased membrane network of surrounding fibroblasts. This is in line with the observation of Marsh et al. that the progressive loss of fibroblasts during skin ageing is balanced by increasing membrane protrusions rather than fibroblast proliferation or migration (Marsh et al., 2018). Our data indicate that repeated UVB tissue damage accelerates this process (photoageing).

Resident immune cells are not only essential for skin barrier function, pathogen defence, and wound healing but also provide essential signals for hair follicle growth and skin regeneration (Gay et al., 2013; Ali et al., 2017; Nosbaum et al., 2016). Here we identify an additional function, that of promoting the survival of dermal fibroblasts during environmental stress. In line with previously published reports, we found that upon UVR exposure neutrophils were first recruited to the UV-exposed site (Hawkshaw et al., 2020; Bald et al., 2014; Wilgus et al., 2000). Neutrophil-derived reactive oxidants are potent mediators of UVB-induced tissue damage and tumorigenesis because of their cytotoxicity and immunosuppression (Savage et al., 1993; Katiyar et al., 1999). This was followed by infiltration of different types of T cells; in particular, Tregs became highly activated and proliferative (Figure 6, Figure 6—figure supplement 1), which is suggested to inhibit the UVR-induced inflammatory response (Bernard et al., 2019). While in homeostatic conditions Tregs are predominantly located around hair follicles (Ali et al., 2017), their expansion throughout the interfollicular dermis was evident upon UVR exposure, and this could potentially promote an immunosuppressive environment. Whether there is also direct cross-talk between T cells and dermal fibroblasts during the UVR tissue damage response is currently unclear. A recent study in human skin has identified CD4+ GATA3+ and CD8+ GATA3+ T cells as the predominant T cell populations in UVR-induced inflammation, and these are therefore likely to contribute to tissue resolution via dermal communication (Hawkshaw et al., 2020).

Production of multiple pro-inflammatory prostaglandins, including PGE-2, is promoted following UVR as a result of arachidonic acid release by phospholipases and by induction of COX-2 expression in various skin cells (Rhodes et al., 2009; Fuller, 2019; Athar et al., 2001). Here we show that PGE-2 and COX-2 are both significantly elevated immediately after UVR exposure and PGE-2 levels are further increased after T cell depletion. In line with our mouse data, it has been reported that following acUVB exposure of human skin pro-inflammatory prostaglandins including PGE-2 peak at 24 hr before normalising after 4 days (Hawkshaw et al., 2020; Rhodes et al., 2009). PGE-2 governs diverse biological functions that are mediated by signalling through four distinct E-type prostanoid (EP) receptors, EP1–4 (Konya et al., 2013). The major EP receptor in skin is EP4, which is a Gs-coupled receptor regulating cAMP/PKA, MEK/ERK1/2, NF-ƙB, and PI3K/ERK/Akt signalling; these pathways are important for cell survival, proliferation, migration, differentiation, angiogenesis, and inflammation. In fibroblasts, PGE-2 binding to EP4 has been shown to increase PTEN activity and Fas expression and decrease survivin expression, thereby promoting apoptosis (Huang et al., 2009). In line with these observations, the increased PGE-2 levels and EP4 expression in the dermis in the early UVR response coincide with the observed fibroblast depletion at 1 and 4 days after UVB exposure (Figure 7M).

In support of the concept that prostaglandin signalling influences fibroblast survival, specific inhibition of COX-2 immediately after UVB exposure significantly reduced fibroblast depletion and neutrophil recruitment. This is consistent with the observation that the COX enzyme inhibitor aspirin (acetylsalicylic acid) efficiently protects keratinocytes and melanocytes from acute UVB-induced DNA damage by decreasing cutaneous inflammation and PGE-2 levels in skin (Rahman et al., 2021). Based on our findings, aspirin may also enhance dermal fibroblast survival and regeneration upon UVR-induced environmental stress. Whether the anti-inflammatory activities of aspirin could help prevent fibroblast-associated changes in photoaged skin warrants investigation in the future.

In summary, we have shown that papillary fibroblasts repair the dermis following UVR with minimal migration and that their survival is influenced by tissue resident T cells controlling UVR-induced inflammation. Specific inhibition of COX-2 reduces dermal fibroblast loss which may have therapeutic applications in the treatment of UVR-induced skin damages and photoageing. Our findings could also be relevant to stromal changes in skin cancer, in which fibroblast senescence is linked to age-associated cancer risk (Lewis et al., 2010; Procopio et al., 2015).

Materials and methods

Human volunteer and UVR time-course analysis

Request a detailed protocol

Ethical approval was granted by the Greater Manchester North NHS research ethics committee (ref: 11/NW/0567) for the studies presented in Figures 1 and 7. Details of the time-course analysis of UVR-challenged human skin have been reported previously (Hawkshaw et al., 2020). Briefly, this study was conducted at the Photobiology Unit, Salford Royal NHS Foundation Trust, Greater Manchester, UK, and involved healthy volunteers aged between 18 and 60 years. All were white Caucasian, of skin phototypes I–III according to the Fitzpatrick skin phototyping scale. In each case, photo-protected upper buttock skin received a single dose of three times the MED using a UVB lamp (Waldmann 236B, peak 313 nm, 280–400 nm) to separate sites on five different days. This allowed collection of skin samples at 1, 4, 7, 10, and 14 days post-UVR, in addition to unirradiated skin. Erythema measurements and 5 mm skin punch biopsies were taken at the end of the time-course experiment, as described (Hawkshaw et al., 2020). Skin biopsies were bisected, with half snap frozen in optimal cutting medium and half formalin fixed and paraffin embedded. All volunteers provided written informed consent in accordance with the Declaration of Helsinki principles.

Transgenic mice

Request a detailed protocol

All animal experiments were subject to local ethical approval and performed under the terms of a UK government Home Office licence (PPL 70/8474 or PP0313918). All mice were outbred on a C57BL/6 background, and male and female mice were used in experiments that included PDGFRαH2BEGFP (Hamilton et al., 2003), Lrig1-CreERt2-IRES-GFP (Lrig1-CreER) (Page et al., 2013), Dlk1-CreERt2 (Dlk1-CreER) (Driskell et al., 2013), Krt14ΔNβ-cateninER (Krt14ΔNβ-cat) (Lo Celso et al., 2004), ROSAfl-stopfl-tdTomato (Jackson Laboratories, 007905), and TCF/Lef:H2B-GFP (TOPEGFP) (Ferrer-Vaquer et al., 2010) mice. Animals were sacrificed by CO2 asphyxiation or cervical dislocation. All efforts were made to minimise suffering for mice. For lineage tracing, transgenic reporter mice were crossed with the indicated CreER line and ER was induced by injection with 10 µl tamoxifen (50 µg/g body weight; Sigma-Aldrich) intraperitoneally in newborn mice (P0), when Dlk1 and Lrig1 are highly expressed in dermal fibroblasts (Driskell et al., 2013; Rognoni et al., 2016). Tamoxifen for injection was dissolved in corn oil (5 mg/ml) by intermittent sonication at 37°C for 30 min. For epidermal β-catenin stabilisation acUVR experiments, central back skin of Krt14ΔNβ-cat × PDGFRαH2BEGFP transgenics was clipped and treated topically with 100 µl 4-hydroxytamoxifen (4OHT) (2 mg/ml dissolved in acetone; Sigma-Aldrich) every second or third day for a total of six applications before and after sham or acUVB exposure (see experimental design in Figure 5C). Tissue was collected at the indicated time points, briefly fixed with 4% paraformaldehyde/PBS (10 min at room temperature), and embedded into optimal cutting temperature (OCT) compound or fixed in 4% paraformaldehyde/PBS overnight at 4°C for paraffin embedding as previously described (Kober et al., 2018).

UVR acute and chronic mouse models including COX-2 inhibition and immune cell depletion

Request a detailed protocol

For the in vivo UVR treatments, a UVR system (Tyler Research UV-2) was used which has a cascade-phosphor UV generator lamp (TL 20 W/12 RS SLV, Philips) with a sharp 310 nm peak output (65% of UVR falls within 20 nm half bandwidth). Thus the generated UVR is highly enriched for UVB which penetrates the epidermis and upper dermis (Watson et al., 2014). Comparison of different mouse strains has revealed that the C57BL/6 background most closely mimics human skin UVB response (Gyöngyösi et al., 2016; Sharma et al., 2011). For UVR exposure, mice were restrained in a custom-made mouse restrainers which only exposed a defined (2 cm × 3 cm) central back skin area to UVR. The UVB dose used for the acute (two consecutive exposures separated by 2 days and isolation at the indicated time points after second treatment) and chronic (twice a week for 8 weeks and isolation at the indicated time points after last exposure) models (800 J/m2) has been shown to correspond closely to the clinically relevant UVB dose in C57BL/6 mice that induces a detectable skin reaction (erythema/oedema) (Gyöngyösi et al., 2016).

For immune cell depletion, in vivo anti-CD4 (clone GK1.5, 400 µg per injection in 100 µl PBS), anti-CD8 (clone 2.43, 400 µg per injection in 100 µl PBS) and anti-IgG control (clone LTF-2, 400 μg per injection in 100 μl PBS), all purchased from BioXCell (West Lebanon, NH), were administered intraperitoneally three times before and during acUVR exposure (see experimental design in Figure 6D). Back skin and lymph nodes were collected 24 hr after the last treatment and analysed by flow cytometry and immunofluorescence.

For COX-2 inhibition during acUVR, mice were divided into control and UVR-treated groups which were either treated topically with vehicle (200 µl acetone) or 500 µg of celecoxib (Selleckchem, S1261) dissolved in acetone (200 µl) immediately after sham or UVR exposure (800 J/m2) (see experimental design in Figure 7D). Mice were killed 24 hr after the second UVB treatment, and back skin was analysed as described above.

In all UVR experiments, 10- to 20-week-old male and female mice were randomised in the different experimental groups and the hair of the central back skin was clipped 24 hr prior to sham or UVR exposure. Back skin with hair follicles not in telogen (hair growth resting phase) at the beginning of the experiment was excluded. During the UVR procedures, mice were housed in small groups (≤3) to minimise the risk of fighting, and skin with signs of scratching was not included in the analysis.

Tissue digestion and flow cytometry analysis

Request a detailed protocol

Preparation of single-cell suspensions for flow cytometry was performed as previously described (Ali et al., 2017). Briefly, isolation of cells from skin draining lymph nodes (axillary, brachial, and inguinal lymph nodes) for flow cytometry was performed by mashing tissue over 70 µm sterile filters. For isolation of skin cells, mouse dorsal skin was minced finely, resuspended in 3 ml of digestion mix (composed of 2 mg/ml collagenase XI [Sigma-Aldrich, C7657], 0.5 mg/ml hyaluronidase [Sigma-Aldrich, H4272], and 0.1 mg/ml DNase [Sigma-Aldrich, DN-25] in 10% foetal bovine serum, 1% Pen/Strep, 1 mM Na-pyruvate, 1% HEPES, 1% non-essential amino acid, 0.5% 2-mercaptoethanol in RPMI-1640 [+L glut] medium), and digested for 45 min at 37°C 255 rpm. The digestion mix was then resuspended in 20 ml of RPMI/HEPES/P-S/FCS media and passed through a 100 µm and 40 µm cell strainer before centrifugation at 1800 rpm for 4 min at 4°C. Cell pellets were resuspended in 1 ml of FACS buffer (2% foetal calf serum, 1 mM EDTA in PBS) for cell counting with an automated cell counter (NucleoCounter NC-200, Chemometec) to calculate absolute cell numbers. Following isolation from the tissue, cells were stained with surface antibodies and a live dead marker (Ghost Dye Violet 510) (see Supplementary file 1) for 20 min on ice. All samples were run on Fortessa 2 (BD Biosciences) at the KCL BRC Flow Cytometry Core, which was standardised using SPHERO Rainbow calibration particle, 8 peaks (BD Biosciences, 559123). For compensation, UltraComp eBeads (Thermo Fisher, 01-2222-42) were stained for each surface and intracellular antibody following the same procedure as cell staining. ArC Amine Reactive Compensation Bead Kit (Thermo Fisher, A10346) were used for Ghost Dye Live/Dead stain. All gating and data analysis were performed using FlowJo v10, while statistics were calculated using GraphPad Prism 9.

Histochemical and immunostaining

Request a detailed protocol

H&E and Herovici staining of 8-μm-thick paraffin mouse skin sections was processed as previously described (Kober et al., 2018), and sections were mounted in DPX mounting medium (Sigma-Aldrich).

For immunostaining, mouse tissue samples were embedded in OCT compound (Life Technologies) prior to sectioning. For thin section stains, cryosections of 14 µm thickness were fixed with 4% paraformaldehyde/PBS (10 min at room temperature), permeabilised with 0.1% Triton X-100/PBS (10 min at room temperature), blocked with 5% BSA/PBS (1 hr at room temperature), and stained with the following primary antibodies to VM (1:500; Cell Signaling, #5741), Ki67 (1:500; Abcam, ab16667, and Invitrogen, clone SolA15), αSma (1:500; Abcam, ab5694), yH2AX (1:500; Abcam, ab81299), COX-2 (1:500; Abcam, ab15191), EP4 (1:200 Bioss, BS-8538R), YAP (1:500; Cell Signaling, #14074), cCasp3 (1:500; Cell Signaling, #9661), CD45 (1:200; eBioscience, clone 30-F11), CD31 (1:200; eBioscience, clone 390), CD49f (1:500; BioLegend, clone GoH3), CD3 (1:200; BioLegend, clone 17A2), CD8 (1:200; BioLegend, clone 53-6.7), FoxP3 (1:200; eBioscience, clone FJK-16s), and Ly6G (1:200; eBioscience, clone 1A8). Samples were stained overnight at 4°C, washed in PBS, labelled with secondary antibodies (all 1:500; AlexaFluor488, A-21208; AlexaFluor555, A-31572; AlexaFluor555, A-21434; AlexaFluor647, A-21247; Thermo Fisher) for 1 hr at room temperature and stained for 10 min with 4,6-diamidino-2-phenylindole (DAPI; 1 mg/ml stock solution diluted 1:50,000 in PBS; D1306, Thermo Fisher) at room temperature with at least four PBS washes in-between. For horizontal wholemounts, 60 µm sections were immunostained as described previously (Rognoni et al., 2016). Thin sections were mounted with ProLong Gold Antifade Mountant (Thermo Fisher), while horizontal wholemounts were mounted with glycerol.

For human tissue fibroblast staining, cryosections of 7 µm thickness were fixed with 4% paraformaldehyde/PBS (20 min at room temperature), blocked with 2.5% normal horse serum/TBS (20 min at room temperature), and then incubated overnight with the following primary antibodies: CD39 (eBioscience, clone eBioA1 [A1], in blocking solution; 1:200) and VM (Cell Signaling, #5741; 1:500) . After three TBS washes, sections were incubated for 30 min with anti-mouse A488 and anti-rabbit A594 secondary antibodies (VectorFluor Dylight Duet kit; DK-8828). Thereafter sections were incubated with DAPI, washed, and mounted. Counting of papillary fibroblasts (CD39+, VM+ cells) was performed in three skin sections per biopsy with three images per section and averages were calculated. Due to large variations in fibroblast density between donors, the data were normalised to the non-UVR-exposed skin sample of each donor.

For the EP4 immunostaining in human skin, paraffin sections of 5 μm thickness were rehydrated, permeabilised with 0.5% Triton X-100/TBS (10 min), and endogenous hydrogen peroxide activity was blocked using 0.3% hydrogen peroxide/PBS (10 min). After blocking with 2.5% normal horse serum/TBS, tissue sections were incubated with rabbit polyclonal EP4 (1:50; Cat# 101775, Cayman) for 1 hr at room temperature. Primary antibody binding was visualised using a anti-rabbit Vector ImmPress kit (MP-5401, Vector Labs) according to the manufacturer’s instructions, and sections counterstained with nuclear fast red (Vector Labs). Images were acquired using the 3D Histech Pannoramic 250 Flash II slide scanner with a ×20/0.80 Plan Apo objective. EP4 expression was analysed in three skin sections (three fields of view per section) per time point using ImageJ software (NIH, UK); thresholding was used to mask positively stained areas, and the percentage area of epidermis or dermis was calculated.

For collagen hybridising peptide (CHP) staining (Hwang et al., 2017), 14 µm cryosections of back skin were fixed with 4% paraformaldehyde/PBS (10 min at room temperature), permeabilised with 0.1% Triton X-100/PBS (10 min at room temperature), blocked with 5% BSA/PBS (1 hr at room temperature), and stained with the indicated primary antibodies and 5 µM B-CHP (BIO300, 3Helix) overnight at 4°C. According to the manufacturer’s instructions, the B-CHP probe was heated for 5 min at 80°C before adding it to the primary antibody mixture, which was immediately applied to the tissue sections. Sections were washed four times with PBS and incubated with appropriate secondary antibody and streptavidin–AlexaFluor647 (S32357, Thermo Fisher) for 1 hr at room temperature. After an additional four washes and DAPI staining slides were mounted as described above.

Confocal microscopy was performed with a Nikon A1 confocal microscope using a ×20 objective, and brightfield images of H&E and Herovici staining were acquired using a Hamamatsu digital slide scanner with a ×40 objective.

In vivo live imaging and analysis

Request a detailed protocol

In vivo live imaging of dermal fibroblasts was performed after 1 and 4 days of acUVB exposure (see experimental design in Figure 4A). Briefly, prior to skin imaging hair follicles were removed with depilation cream (Veet hair removal cream for dry skin) which was applied to the sham and UVR-exposed skin area of the lower back and massaged into the skin for approximately 2 min. The area was then washed thoroughly with water, removing hair and cream from the imaging site. Throughout imaging, mice were anaesthetised by inhalation of vaporised 1.5% isoflurane (Cp-Pharma) and placed in the prone position in a chamber with body temperature maintained at 37°C via a homeothermic monitoring system (Harvard Apparatus). Additionally, oxygen levels were monitored with the MouseOx Plus (Starr Life Sciences Corp) throughout the imaging sessions using an adult mouse pinch attached to the thigh. Oxygen saturation remained at approximately 99%.

The back skin was stabilised between a cover glass and a thermal conductive soft silicon sheet as previously described (Hiratsuka et al., 2015). Two-photon excitation microscopy was performed with a Zeiss LSM 7MP upright microscope, equipped with a W Plan-APOCHROMAT ×20/1.0 water-immersion objective lens (Zeiss) and a Ti:Sapphire laser (0.95 W at 900 nm; Coherent Chameleon II laser). The laser power used for observation was 2–10%. Scan speed was 4 ls/pixel. The nuclear GFP expression of dermal fibroblasts can be readily detected in PDGFRαH2BEGFP transgenic mice, and the autofluorescence of fibrillar collagen can be visualised by the second harmonic generation (SHG) using an excitation wavelength of 770 nm. For time-lapse images, z-stacks were acquired every 10 min with a view field of 0.257 mm2 in 5 µm steps. A total of 3–6 mice per time point were examined, and the duration of time-lapse imaging was 70–90 min per mouse. Optimisation of image acquisition was performed to avoid fluorescence bleaching and tissue damage and to obtain the best spatiotemporal resolution. Acquired images were analysed with Fiji imaging software (ImageJ, NIH) and Imaris (BitPlane).

Briefly, raw image files (czi) were imported into Fiji where they were subjected to the Correct 3D Drift plugin using channel 1 (collagen) for registration and selection for sub-pixel drift correction (Parslow et al., 2014). The sample drift correction was then manually checked via orthogonal view whereby three hair follicles in each sample were selected in the xz and yz planes and their relative positions measured at time 0 and 80 min and an average taken. The final 3D drift-corrected time-lapse movies were then inputted into Imaris (BitPlane). Within Imaris, tracking spots over time were selected using channel 2 (GFP) to follow fibroblast movement over time. Only fibroblasts with a signal quality above 80%, diameter above 8 µm, and max distance 15 µm were selected using the autoregressive motion algorithm. This created an animation with spots corresponding to fibroblasts. All spots which corresponded to epidermal noise or hair follicle signal were removed manually from each image. Statistics, including cell displacement, position, and mean velocity, were exported into Excel for further analysis. For calculation of the cell displacement in x-, y-, and z-directions, the position of each cell at the start and imaging endpoint was compared and the percentage of cells displaced ≥5 µm (z-stack imaging step size) was quantified.

Prostaglandin E2 measurement

Request a detailed protocol

The prostaglandin E2 (PGE-2) content of skin samples was determined by using a Prostaglandin E2 ELISA Kit (Cayman Chemicals). Briefly, a tissue piece (<80 mg, preserved in OCT at –80°C) was homogenised in 1 ml of lysis buffer (ELISA Buffer supplemented with 10 µM indomethacin) with a gentleMACS dissociator (Miltenyi Biotec). After a centrifugation step (8000 × g, 10 min), PGE-2 was assayed in the supernatant (1:120 dilution with ELISA Buffer) by following the manufacturer’s protocol. The concentrations were calculated using a standard curve of PGE-2 between 15 and 500 pg/ml.

Single-cell RNA-seq analysis of neonatal and adult fibroblast populations and human transcriptomic data

Request a detailed protocol

Single-cell RNA-seq data from neonatal (P2) and adult (P21) mouse skin were obtained from GEO dataset GSE153596 (Phan et al., 2020). Pre-processing and initial data analysis were performed with Scanpy (Wolf et al., 2018) according to the tutorial provided (https://scanpy-tutorials.readthedocs.io/en/latest/pbmc3k.html). Briefly, data were imported, cells expressing less than 200 genes and genes expressed in less than 3 cells were filtered out, counts were normalised, logarithmised, and scaled, a PCA and UMAP were computed, and cells were clustered using the Leiden algorithm. The fibroblast subset was selected and clustered and annotated using marker genes as previously described (Phan et al., 2020). Finally, GO term enrichment using g:Profiler (Raudvere et al., 2019) was performed on differentially increased genes (p<0.05, Log2 fold change > 1) for each cluster.

Human single-cell RNA-seq data from eyelid skin was visualised using the single-cell ageing atlas (Zou et al., 2021; Liu et al., 2021), and GO term enrichment of significant genes (Log2 fold change > 0.5, p<0.05) in each identified fibroblast cluster was performed with g:Profiler (Raudvere et al., 2019). In addition, human RNA-seq data for upper and lower breast dermis from three donors were obtained from GSE109822 (Philippeos et al., 2018), and differentially expressed genes were determined with edgeR (Robinson et al., 2009). GO term enrichment was performed on differentially increased genes (Log2 fold change > 0.5, p<0.05) using g:Profiler (Raudvere et al., 2019).

Quantitation and statistical analysis

Request a detailed protocol

Statistical analysis was performed with GraphPad Prism 9 software. Unless stated otherwise, data are means ± standard deviation (SD) and statistical significance was determined by unpaired t-test, ordinary one-way or two-way ANOVA for biological effects with an assumed normal distribution. For unbiased cell identification with DAPI, Ki67, YAP, yH2AX, cCasp3, TOPGFP, or PDGFRαH2BEGFP labelling, nuclear staining was quantified using the Spot detector plugin of Icy software (version 2.1.0.1). Similarly, cells labelled with tdTomato in the lineage-tracing experiments or stained with COX-2, Ly6G (neutrophils), CD3 (CD3+ T cells), CD8 (cytotoxic T cells), and FoxP3+ (Tregs) were counted per area with the Spot detector plugin of Icy software. To quantify CD45, EP4, and CHP staining in tissue sections, mean fluorescence was determined with Icy software and normalised to background. Cell elongation was determined by measuring the maximal tdTomato+ cytoplasm diameter of individual cells in the papillary dermis of Lrig1-CreER × Rosa26-tdTomato lineage-traced transgenics. Figures were prepared with Adobe Photoshop and Adobe Illustrator (CC2021).

Appendix 1

Appendix 1—key resources table
Reagent type (species) or resourceDesignationSource or referenceIdentifiersAdditional information
Strain, strain background
(Mus musculus)		PDGFRα
H2BEGFP, C57Bl6/BalbC		PMID:12748302RRID:MGI:2663656
Strain, strain background
(M. musculus)		Lrig1-CreERt2-IRES-GFP, C57Bl6/BalbCPMID:23954751RRID:MGI:5520983
Strain, strain background
(M. musculus)		Dlk1-CreERt2, C57Bl6/BalbCPMID:24336287RRID:MGI:5555961
Strain, strain background
(M. musculus)		ROSAfl-stopfl-tdTomato, C57Bl6/BalbCJackson LaboratoriesStock no.:007905
Strain, strain background
(M. musculus)		Krt14ΔNβ-cateninER, C57Bl6/BalbCPMID:15084463RRID:MGI:6315261
Strain, strain background
(M. musculus)		TCF/Lef:H2B-GFP, C57Bl6/BalbCPMID:21176145RRID:MGI:4881498
AntibodyAnti-vimentin (rabbit polyclonal)Cell SignalingCat# 5741IF (1:500)
AntibodyAnti-Ly6G (rat monoclonal)eBioscienceClone 1A8IF (1:200)
AntibodyAnti-FoxP3 (rat monoclonal)eBioscienceClone FJK-16sIF (1:200)
AntibodyAnti-CD8 (rat monoclonal)BioLegendClone 53-6.7IF (1:200)
AntibodyAnti-CD3 (rat monoclonal)BioLegendClone 17A2IF (1:200)
AntibodyAnti-CD49f (rat monoclonal)BioLegendClone GoH3IF (1:500)
AntibodyAnti-CD45 (rat monoclonal)eBioscienceClone 30-F11IF: (1:200)
AntibodyAnti-CD31 (rat monoclonal)eBioscienceClone 390IF: (1:200)
AntibodyAnti-COX-2 (rabbit polyclonal)AbcamCat# ab15191IF (1:500)
AntibodyAnti-cCasp3 (rabbit polyclonal)Cell SignalingCat# 9661IF (1:500)
AntibodyAnti-YAP (rabbit polyclonal)Cell SignalingCat# 14074IF (1:500)
AntibodyAnti-EP4 (rabbit polyclonal)BiossCat# BS-8538RIF (1:200)
AntibodyAnti-EP4 (rabbit polyclonal)CaymanCat# 101775IF (1:50)
AntibodyAnti-Ki67 (rabbit polyclonal)AbcamCat# ab16667IF (1:500)
AntibodyAnti-Ki67 (rat monoclonal)InvitrogenClone SolA15IF (1:500)
AntibodyAnti-yH2AX (rabbit polyclonal)AbcamCat# ab81299IF (1:500)
AntibodyAnti-αSma (rabbit polyclonal)AbcamCat# ab5694IF (1:500)
AntibodyAnti-human
CD39 (mouse monoclonal)		eBioscienceClone eBioA1 (A1)IF (1:200)
AntibodyAnti-mouse CD4 (rat monoclonal)BioXCellClone GK1.5For immune
cell depletion
AntibodyAnti-mouse CD8 (rat monoclonal)BioXCellClone 2.43For immune
cell depletion
AntibodyAnti-IgG (rat monoclonal)BioXCellClone LTF-2For immune cell depletion
AntibodyAnti-rat AlexaFluor488 (donkey
polyclonal)		Thermo FisherCat# A-21208IF (1:1000)
AntibodyAnti-rabbit AlexaFluor555 (donkey
polyclonal)		Thermo FisherCat# A-31572IF (1:1000)
AntibodyAnti-rat AlexaFluor555
(goat polyclonal)		Thermo FisherCat# A-21434IF (1:1000)
AntibodyAnti-rat AlexaFluor647
(goat polyclonal)		Thermo FisherCat# A-21247IF (1:1000)
AntibodyAnti-mouse/rat Foxp3 eFluor450 (rat monoclonal)eBioscienceClone FJK-16sFACS (1:100)
AntibodyAnti-mouse CD152 (CTLA4), PE (rat
monoclonal)		BDClone UC10-4F10-11FACS (1:100)
AntibodyAnti-human Ki67, PE-Cy7 (mouse monoclonal)BDClone B56FACS (1:100)
AntibodyAnti-mouse TCR gd, PerCP-Cy 5.5 (rat monoclonal)BioLegendClone GL3FACS (1:300)
AntibodyAnti-mouse CD45, Alexa Fluor700 (rat monoclonal)eBioscienceClone 30-F11FACS (1:200)
AntibodyAnti-mouse CD25, APC-eFluor780 (rat monoclonal)eBioscienceClone PC61.5FACS (1:150)
AntibodyAnti-mouse CD8a, Brilliant
Violet 605 (rat monoclonal)		BioLegendClone 53-6.7FACS (1:200)
AntibodyAnti-mouse CD4 Antibody, Brilliant Violet 650
(rat monoclonal)		BioLegendClone RM4-5FACS (1:200)
AntibodyAnti-mouse CD3, Brilliant Violet 711 (rat monoclonal)BioLegendClone 17A2FACS (1:150)
AntibodyAnti-mouse CD11b, AlexaFluor647
(rat monoclonal)		BioLegendClone M1/70FACS (1:400)
AntibodyAnti-F4/80, PE-Cy5 (rat monoclonal)eBioscienceClone BM8FACS (1:400)
AntibodyAnti-MHC Class
II (I-A) (NIMR-4),
PE (rat
monoclonal)		eBioscienceClone M5/114.15.2FACS (1:500)
AntibodyAnti-mouse Ly-6A/E (Sca-1), APC/Cy7 (rat monoclonal)BioLegendClone D7FACS (1:400)
AntibodyAnti-mouse CD11c, AlexaFluor488 (hamster monoclonal)BioLegendClone N418FACS (1:400)
Peptide, recombinant proteinB-CHP3HelixCat# BIO300IF (1:100)
Peptide, recombinant proteinStreptavidin–AlexaFluor647Thermo FisherCat# S32357IF (1:500)
Peptide, recombinant proteinCollagenase XISigma-AldrichCat# C7657
Peptide, recombinant proteinHyaluronidaseSigma-AldrichCat# H4272
Peptide, recombinant proteinDNase ISigma-AldrichCat# DN-25
Other4,6-Diamidino-2-phenylindole (DAPI)Thermo FisherCat# D1306IF (1 mg/ml
stock solution
diluted 1:50,000)
OtherGhost Dye Violet 510 Live/
Dead Stain		Tonbo BiosciencesCat# 13-0870T100FACS (1:500)
OtherUVR system (Tyler Research UV-2)Tyler ResearchCat# UV-2
Commercial
assay or kit		VectorFluor Dylight Duet kitVector LabsCat# DK-8828
Commercial
assay or kit		Anti-rabbit
Vector
ImmPress
kit		Vector LabsCat# MP-5401
Commercial
assay or kit		Prostaglandin
E2 ELISA Kit		Cayman ChemicalsCat# 500141
Commercial
assay or kit		CelecoxibSelleckchemCat# S1261
Commercial
assay or kit		UltraComp eBeadsThermo FisherCat# 01-2222-42
Commercial
assay or kit		ArC Amine Reactive Compensation
Bead Kit		Thermo FisherCat# A10346
Commercial
assay or kit		4-Hydroxyt
amoxifen (4OHT)		Sigma-AldrichCat# H7904
Commercial
assay or kit		TamoxifenSigma-AldrichCat# T5648
Software,
algorithm		ICYInstitut Pasteur and France-BioImagingRRID:SCR_010587
Software,
algorithm		Fiji imaging software (ImageJ)NIHRRID:SCR_002285
Software,
algorithm		ImarisBitPlaneRRID:SCR_007370
Software,
algorithm		ScanpyScanpyRRID:SCR_018139
Software,
algorithm		g:Profilerg:ProfilerRRID:SCR_006809
Software,
algorithm		FlowJoFlowJoRRID:SCR_008520
Software,
algorithm		GraphPad
Prism		GraphPad
Prism		RRID:SCR_002798

Data availability

All data generated or analysed during this study are included in the manuscript and supporting files. Source data files containing the numerical data used to generate the figures have been provided for all figures.

The following previously published data sets were used
    1. Phan QM
    2. Fine G
    3. Salz L
    4. Herrera GG
    5. Wildman B
    6. Driskell IM
    7. Driskell RR
    (2020) NCBI Gene Expression Omnibus
    ID GSE153596. Lef1 expression in fibroblasts maintains developmental potential in adult skin to regenerate wounds.
    http://www.ncbi.nlm.nih.gov/geo/query/acc.cgi?acc=GSE153596
    1. Philippeos C
    2. Telerman SB
    3. Oulès B
    4. Pisco AO
    5. Shaw TJ
    6. Elgueta R
    7. Lombardi G
    8. Driskell RR
    9. Soldin M
    10. Lynch MD
    11. Watt FM
    (2018) NCBI Gene Expression Omnibus
    ID GSE109822. Spatial and single-cell transcriptional profiling identifies functionally distinct human dermal fibroblast subpopulations.
    https://www.ncbi.nlm.nih.gov/geo/query/acc.cgi?acc=GSE109822

References

Decision letter

  1. Edward E Morrisey
    Senior and Reviewing Editor; University of Pennsylvania, United States

In the interests of transparency, eLife publishes the most substantive revision requests and the accompanying author responses.

[Editors' note: this paper was reviewed by Review Commons.]

https://doi.org/10.7554/eLife.71052.sa1

Author response

Reviewer #1 (Evidence, reproducibility and clarity (Required)):

Summary:

In this paper, Rognoni et al. showed that distinct fibroblast population (papillary fibroblast in the upper dermis vs reticular fibroblast in the lower dermis) in the skin have different response to UV radiation and tissue remodeling. Taking advantage of specific CreER tools that they have established in previous work, they nicely demonstrated that papillary fibroblasts are the cell type, which is responsible for the contribution of tissue repair after acute UV radiation. In contrast, chronic UV-induced damage is not easily repaired in part due to more severe loss of papillary fibroblasts, which is also seen in aging skin. In the last part, the authors tried to addressed further the molecular mechanisms and showed that the CD4 and CD8 T cells have a supportive role in UV-induced tissue repair by maintaining the papillary fibroblasts.

Major comments:

I think minimal work is required for the submission before publication in a peer reviewed journal.

We thank the reviewer for this positive evaluation of our manuscript.

I recommend authors to explain a bit more about the possible factors to explain the cell response differences between papillary vs reticular fibroblasts. For me, first part (fibroblast heterogeneity) and second part (Wnt, interaction with immune cells) do not connect so well.

To explore potential intrinsic differences between papillary and reticular fibroblasts, we have included an analysis of GO terms associated with the cellular response to UV, cell stress and DNA damage/repair in publicly available transcriptomic datasets and how these map to differences in the gene expression profiles of different fibroblasts subpopulations in undamaged neonatal and adult mouse skin (Phan et al., 2020, eLife), sun exposed human eyelid skin (Zou et al., 2021, Dev Cell) as well as microdissected human skin (Philippeos et al., 2018, J Invest Dermatol.) (Figure 1—figure supplement 2). Our new data analysis indicates that dermal fibroblast subpopulations do not differ in their response or susceptibility to UV damage.

We have improved the connection between the two parts of the manuscript by re-writing the text and by expanding our analysis of Wnt signalling (Figure 5) and immune cell distribution (Figure 6 and Figure 6—figure supplement 1) in the upper and lower dermis.

Are there any differences in immune cell distribution (or EP4 expression) between upper and lower dermis? Or not, what makes differences between papillary vs reticular fibroblasts in their response to UV? The CD4 and CD8 T cells seem to act mainly on papillary fibroblasts based on the blocking antibody effects as shown in Figure 6C. Are CD4 and CD8 T cells predominantly recruited and located in the upper dermis? The authors should provide quantification of CD8 T cell distribution in upper vs lower dermis (Supplementary Figure 6), like they did in other figures.

We have now quantified the distribution of different T cell populations in the upper and lower dermis and included the data in Figure 6A-C and Figure 6—figure supplement 1C. While CD3+ T cells were depleted in the epidermis, they were increased in the upper and lower dermis. Cytotoxic T cells (CD8+), which are enriched in the lower dermis in control skin, were significantly increased in the upper dermis after UVR exposure while Tregs (FoxP3+) significantly expanded throughout the dermis.

In addition, we have now measured prostaglandin E2 (PGE-2) concentration after UVR exposure with and without T cell depletion (Figure 7A and B) and expanded our analysis of EP4 and COX-2 expression in the upper and lower dermis (Figure 7C and K). Acute UVR exposure induced the release of PGE-2 in the skin, which was further increased after CD4+ and CD8+ cell depletion. COX-2 and EP4 expression are highly increased 1 day after UVR exposure in the epidermis and dermis, coinciding with the fibroblast loss.

Minor comments:

The Figure overall is presented very well, and writing is clear. I am a bit confused with different time points presented in each panel of figures. Most of places in their figures, they labeled clearly e.g., “acUVB π 1 day”, but not all. For example, Figure 2A is 8 weeks post UVB, Figure 2B, chUVB is 1 or 3 day. Figure 2E is 24 hours. How about Figure 2C, D? I appreciate if authors could use the same labeling across all figures, which really help readers to understand the time course of cellular events upon UVR.

We apologize for the inconsistency, and we have now made the figure labels clearer and more consistent throughout the manuscript.

In Figure 6D, aCD4 and aCD8, "a" (alpha) is not written in symbol.

We have corrected this.

Reviewer #1 (Significance (Required)):

Significance:

The significance of this paper is to describe a distinct cellular response of heterogeneous dermal fibroblasts in the context of UV-induced tissue damage. They used unique mouse models to address this point, which has not been shown in the field. This study is relevant for broad area of skin researchers including the field of aging, wound healing, tissue remodeling, cancer and immune-dermal interaction. I am expertise in skin stem cell biology and particularly interested in the heterogeneity of stem cells.

We thank the reviewer for acknowledging the novelty and significance of our work.

Referee Cross-commenting:

I have read the comments from referees 2 and 3. I agree with their suggestions. Especially, some additional clarification and experiments on the UVB radiation, live imaging, immune cell response will improve the clarity of the manuscript.

Please see responses to the other reviewers.

Reviewer #2 (Evidence, reproducibility and clarity (Required)):

In this manuscript, Rognoni and coworkers analyze the response of dermal fibroblasts to acute and chronic UV exposure. They show that both in human and mouse skin, acute UV leads to transient depletion of papillary fibroblasts characterized by increased gH2AX signal and apoptosis, followed by a wave of increased proliferation, whereas no substantial ECM remodeling is seen. They further show that chronic UV leads to a more stable decrease in papillary fibroblasts, but less apoptosis and compensatory proliferation are observed. In contrast substantial ECM remodeling is seen. In addition chronic UV-exposed fibroblasts appear elongated. The authors then show that acute UV is able to trigger some fibroblast motility, whereas boosting proliferation is not sufficient to rescue fibroblast numbers. In contrast, blunting inflammation results to some degree of rescue in terms of fibroblast numbers.Overall this is an interesting manuscript that utilizes stringent approaches to address the clinically relevant question of effects of UV on skin. The manuscript is very well and clearly written, the data is of high quality and compelling. The conclusions are overall well justified by the data.

We thank the reviewer for these comments.

The only major issue I have with the manuscript is that it is not clear how the in vivo imaging, a very elegant approach with a compelling result, integrates with the rest of the data. From the first part it seems that the authors draw the conclusion that acute UV kills the fibroblasts through DNA damage and apoptosis, which is not seen in the chronic treatment. So it would have been more logical to analyse the migration patterns in the chronic UV group as migration would be more likely to be relevant there. Also, if cells are migrating downwards, should this not result in increased levels of Lrig1+ cells in the lower dermis. Now both compartments seem to show a reduction (Figure 3d). On the other hand, if the migration would be replenishing the lost population, then one would expect the migration to be directional or at least show some biased z displacement towards the epidermis, which seems not to be the case. So all in all the reader is left wondering about the relevance of this observation. While I understand that repeating the imaging in chronic UV treated mice is a major experimental undertaking, this or additional experiments addressing the role of migration in the described phenomena would strengthen this manuscript.

We carried out in vivo live imaging of dermal fibroblasts to elucidate firstly if active cell migration contributes to fibroblast depletion in the upper dermis (which occurs in both acute and chronic UV exposed skin), and secondly, how fibroblast migration is involved in the early tissue damage repair response (repopulation of the upper dermis only occurs in after acute UV damage). Our conclusion is that after UVR exposure there is very little cell migration and that it is random, not directional. This is in contrast to fibroblast behaviour during repair of full thickness skin wounds (Rognoni et al., 2018, Mol Syst Biol; Jiang et al., 2020, Nat Commun). We conclude that following UVR (acute or chronic) fibroblasts are depleted through cell death and not through active downward migration. This is in agreement with our Lrig1CreER lineage tracing data, which shows no fibroblast density increase in the lower dermis. During the early tissue repair response (4 days post-UVB exposure) fibroblasts become more motile, which correlates with the observed reorganization of papillary lineage fibroblasts. However, the lack of directionality suggests that the replenishment of upper dermal fibroblasts is a stochastic process, similar to the reorganisation of fibroblast lineages we previously observed during skin ageing (Rognoni et al., 2018, Mol Syst Biol).

We have now revised the manuscript (Results and Discussion) to improve the description of our findings and state more clearly that fibroblast loss is not due to migration.

Another issue is that the matrix remodeling and cell elongation phenomena remain slightly isolated observations and it is not clear how they tie to the other observed changes.

We have clarified this in the text by pointing out the links between fibroblast migration, cell shape changes and ECM remodelling. We think it is particularly interesting that in chronic UVR exposed skin the reduction in fibroblast density is partly compensated by elongation of upper dermal fibroblasts. This phenomenon is also observed in aged skin (Marsh et al., 2018, Cell) and our data indicate that repeated UVB tissue damage – which occurs in photo-ageing – accelerates the process.

Minor points:

1. The images in Figure 3D for the Dlk1 Cre labeling are difficult to interpret as there are very few labeled cells to begin with. This is in stark contrast to Figure 3B where a large number of cells are visible. Yet the quantified Dlk1+ cell densities in 3D and 3B are similar. Are these images not representative or what would explain this difference?

We have replaced the image in Figure 3D with one that is a better representation of the quantification. We have also made the quantification of Dlk1Cre labelled cells in upper and lower dermis consistent.

2. Cell elongation statistical analyses in 3F would be more robustly done from means individual mice rather than pooling all cells together thus inflating the n number.

We have now included this analysis in Figure 3—figure supplement 1 C and D.

3. Overall it would be more compelling to show individual replicates than bar graphs throughout the manuscript.

We agree and have revised the Figures accordingly.

Reviewer #2 (Significance (Required)):

Overall this is an interesting, high quality manuscript that provides compelling new knowledge on the effects of UV irradiation on the skin. The results will be interesting for the fields of skin biology, DNA damage and UV.

Reviewer #3 (Evidence, reproducibility and clarity (Required)):

This reviewer has expertise in epidermal biology clinical dermatology and has worked in the context of UV irradiation and carcinogenesis.

In this work, authors explore the effect of acute and chronic UV on dermal fibroblast populations. Making use of murine reporter lines and lineage tracing they show the partial loss of a specific population of fibroblasts. Mechanistically, the role of immune cells and prostaglandins are explored. Finally, to some extent, the findings are associated with similar observations in human samples obtained from a small clinical trial.

Major comments:

This is a comprehensive study claiming many novel findings.

We thank the reviewer for this positive evaluation of our study.

1. UVA is the main component of Solar UV and is the main type of UV penetrating the dermis and acting on both the cells and the extra-cellular matrix through oxidative stress. It is unclear why radiation in these experiments was restricted to UVB.

While we are aware of the importance of UVA for skin photobiology, it is evident from the literature that UVA and UVB induce different types of photo-damage in skin and so a separate analysis of UVA and UVB provides useful mechanistic insights that could lead to design of specific interventions. In regard to environmental risk factors there is an increasing interest in the specific impact of UVB radiation on human health, as ambient UVB will decrease or increase depending on the success of the Montreal Treaty in limiting ozone destruction (see recent United Nations EEAP 2019 report: Environmental Effects and Interactions of Stratospheric Ozone Depletion, UV Radiation, and Climate Change, https://ozone.unep.org/science/assessment/eeap). We have included these points in the revised manuscript.

2. The main issue relates to the definition of upper dermis versus lower dermis fibroblasts. The anatomical separation is not clarified in this paper. Moreover, at the molecular level, there seems to be a gap between DLK1Cre labelled cells and Lrig1Cre labelled cells. This is an important conceptual point as it needs to be clarified if the depletion concerns all cells of the upper dermis lineage or alternatively it only concerns the cells (regardless of biology) that are closest to the surface and within reach of UVB radiation.

We and others have extensively characterized the development and distribution of different dermal fibroblast lineages in mouse skin (see Rognoni et al., 2016, Development; Rognoni et al., 2018, Mol Syst Bio; Driskell et al., 2013, Nature; Rinkevich et al., 2015, Science; Salzer et al., 2018, Cell). In adult mouse skin papillary fibroblasts lie in the upper dermis that extends from the basement membrane to the hair follicle infundibulum above the sebaceous glands. The lower dermis, containing reticular fibroblasts, extends from below the papillary dermis to the DWAT (dermal white adipose tissue; hypodermis). We have indicated the boundary between upper and lower dermis with a dotted line in the histology/immunofluorescence images. Our pan-fibroblast (PDGFRaH2BEGFP+) and Lrig1-CreER labeled dermal cell density quantifications show that one day after acute UVB exposure all fibroblasts close to the basement membrane in the upper dermis are depleted, which correlates with the distribution of apoptotic and DNA damaged fibroblasts and UVR induced tissue damage. GO term analysis of different dermal fibroblast subpopulations (new Figure 1—figure supplement 2) indicates that these subpopulations do not differ in their response or susceptibility to UV damage. We have stated these findings more clearly in the revised manuscript.

3. Regarding the evolution of the fibroblast depletion, authors claim that the numbers reach baseline levels at 14 days after an acute irradiation. However in the chronic irradiation model, they claim that fibroblasts never recover their initial numbers… In the latter set of experiments, experiments have only been performed for up to 10 days. It is advised to continue observing changes in fibroblast numbers up to 14 and 21 days before such conclusion.

We have now included data on fibroblast density at later time points following chronic UVB exposure (Figure 2H), which shows that upper fibroblast depletion persists for 30 days after chronic UVR. Our observations are in line with previous chronic UVB studies (now cited) reporting a reduced cell density in the papillary dermis even 200 days after the final UVB exposure (Dai et al., 2007, Am J Pathol).

The human equivalent of this experiment is also not convincing. It is not clear how many technical replicates (staining) have been performed for each patient. In any case the overall trend does not support the authors description (with the exception of 1 patient) of a depletion and a recovery. There seems to be a general trend towards increased fibroblasts over 14 days. In that sense Figure 2H may be an overrepresentation of the authors findings.

We have revised the quantitation of UVB treated human skin in Figure 1A and included the missing technical information in the Methods section. Due to the large variation in fibroblast density between donors, we have now normalized the mean fibroblast density to the non-UVR exposed skin sample for each donor and present the normalized mean fibroblast densities in a boxplot. Our data show a significant loss of dermal fibroblasts at 1 day post UVR; this is followed by a transient increase during the repair phase and a return to pre-UVR treatment levels after two weeks.

4. I question the decision by the authors to use a burning dose of UVB for the chronic irradiation experiment? Often to reflect the clinical scenario of chronic irradiation sub-erythemal doses are used and adjusted to the tanning response.

Compared to other recent studies (Bald et al., 2014, Nature; Kunisada et al., 2005, Cancer Res; Ohkumo et al., 2006, Mol Cell Biol.; Dai et al., 2007, Am J Pathol.; Mira Han et al., 2017, Sci Rep.; Meeran et al., 2009, Toxicol Appl Pharmacol), our chronic UVB treatment regime in C57BL/6 mice is rather mild with 800 J/m2 twice a week for 8 weeks. The mice develop prominent skin tanning after 8 weeks of treatment but there is no breakdown of the skin barrier, which would be a feature of severe sunburn. We have stated this more clearly in the revised manuscript.

5. The mechanism proposed in this work for the depletion and recovery of the fibroblasts is unclear. Authors show that upper dermal fibroblasts undergo DNA damage and apoptosis (staining impossible to see). They also claim through in vivo imaging that the cells largely move downwards. The latter finding cannot be recapitulated by the Lrig1Cre lineage tracing. Finally, another claim is made about the protective role of T cells (in reducing PGE2?) and the importance of PGE2. These different mechanisms are not linked to each other. Can authors deplete only Tregs? And not all CD4 cells? Can they deplete CD8 or CD4 cells and treat with celecoxib? Can they measure apoptosis levels in the T cell depletion studies?

We apologise for the lack of clarity regarding mechanism, which was also highlighted by Reviewer 2. We show that fibroblasts are lost by cell death and not by downward migration (see response to Reviewer 2). We have now elaborated more clearly the effect of UVB-induced inflammation on dermal fibroblast survival and included quantification of fibroblast apoptosis (Figure 6H) and PGE-2 levels (Figure 7, A and B), both of which increase upon T cell depletion. In addition, we have added quantification of COX-2 and EP4 expression in the upper and lower dermis after UVB exposure, and show that both are highly induced at 1 day post UVR.

We agree that it would be interesting to selectively deplete Tregs; however we show that both CD4+ and CD8+ T cells equally influence dermal fibroblast survival and proliferation (Figure 6D-I). Similarly, repeating the celecoxib treatment in combination with anti-CD8 and CD4 would, in our opinion, provide minimal further insights to the current COX-2 inhibition experiment in Figure 7D-J.

Minor comments:

1. The T cell depletion studies are not controlled properly by isotype Antbody. Similarly the effect of interventions is not tested in normal skin to ensure specificity of the effect to UV irradiation.

We thank the reviewer for this comment. The revised manuscript now shows the isotype antibody control data in Figure 6—figure supplement 1H-K and specifically highlights the interventions we have performed on non-UVB treated skin.

2. Many of the immunostaining panels are difficult to see at such a low magnification. DLK1Cre lineage tracing images are not convincing as large pockets of TdTomato can be identified that does not correspond to cells.

We have improved the clarity and the labeling of the immunostaining panels. It is worth noting that induction of Dlk1Cre during early skin development labels reticular fibroblasts that further differentiate into adipocytes. Therefore, in adults the adipocyte layer contains large number of tdTomato+ cells, a point we make in the revised manuscript. We have exchanged and increased the size of Figure 3D, to better represent the associated quantification and show the structure of the tdTomato positive adipocyte layer.

3. I cannot comment on fibroblast shapes in vivo the CHP staining and the evaluation of the dermis ECM.

Reviewer #3 (Significance (Required)):Understanding the consequences of UV radiation on the skin is essential for our knowledge on skin carcinogenesis, skin ageing but also inflammation. Very few studies have proposed a clear mechanism for the effect of UV on fibroblast behaviour. Solar UV in the context of human pathology is the main environmental exposure. It is composed in large majority by UVA which has an essential role in inducing fibroblast senescence and skin photo-ageing. Unfortunately by restricting the study to UVB radiation authors restrict its applicability to the clinical scenario.

Although I am not an expert in the dermis, there are notable deficits in relating to past studies in carcinogenesis (Paolo Dotto's group) or ageing (IGF signalling and senescence) without going through an exhaustive list.

We have revised the manuscript to cite the past studies.

https://doi.org/10.7554/eLife.71052.sa2

Article and author information

Author details

  1. Emanuel Rognoni

    1. Centre for Stem Cells and Regenerative Medicine, King's College London, Guy's Hospital, London, United Kingdom
    2. Centre for Endocrinology, William Harvey Research Institute, Barts and The London School of Medicine, Queen Mary University of London, London, United Kingdom
    Contribution
    Conceptualization, Data curation, Investigation, Methodology, Project administration, Validation, Visualization, Writing – original draft, Writing – review and editing
    For correspondence
    e.rognoni@qmul.ac.uk
    Competing interests
    No competing interests declared
    ORCID icon "This ORCID iD identifies the author of this article:" 0000-0001-6050-2860

  2. Georgina Goss

    Centre for Stem Cells and Regenerative Medicine, King's College London, Guy's Hospital, London, United Kingdom
    Contribution
    Investigation, Methodology, Writing – review and editing
    Competing interests
    No competing interests declared

  3. Toru Hiratsuka

    1. Centre for Stem Cells and Regenerative Medicine, King's College London, Guy's Hospital, London, United Kingdom
    2. Research Center for Dynamic Living Systems, Graduate School of Biostudies, Kyoto University, Kyoto, Japan
    Contribution
    Methodology
    Competing interests
    No competing interests declared
    ORCID icon "This ORCID iD identifies the author of this article:" 0000-0002-5359-2690

  4. Kalle H Sipilä

    Centre for Stem Cells and Regenerative Medicine, King's College London, Guy's Hospital, London, United Kingdom
    Contribution
    Investigation, Methodology, Writing – review and editing
    Competing interests
    No competing interests declared

  5. Thomas Kirk

    Centre for Endocrinology, William Harvey Research Institute, Barts and The London School of Medicine, Queen Mary University of London, London, United Kingdom
    Contribution
    Investigation, Methodology
    Competing interests
    No competing interests declared

  6. Katharina I Kober

    1. Division of Signaling and Functional Genomics, German Cancer Research Center (DKFZ), Heidelberg, Germany
    2. Department of Cell and Molecular Biology, Medical Faculty Mannheim, Heidelberg University, Heidelberg, Germany
    Contribution
    Investigation
    Competing interests
    No competing interests declared
    ORCID icon "This ORCID iD identifies the author of this article:" 0000-0002-8076-3379

  7. Prudence PokWai Lui

    Centre for Stem Cells and Regenerative Medicine, King's College London, Guy's Hospital, London, United Kingdom
    Contribution
    Investigation
    Competing interests
    No competing interests declared

  8. Victoria SK Tsang

    Centre for Endocrinology, William Harvey Research Institute, Barts and The London School of Medicine, Queen Mary University of London, London, United Kingdom
    Contribution
    Investigation
    Competing interests
    No competing interests declared

  9. Nathan J Hawkshaw

    Division of Musculoskeletal and Dermatological Sciences, Faculty of Biology, Medicine and Health, School of Biological Sciences, Manchester Academic Health Science Centre, The University of Manchester and Salford Royal NHS Foundation Trust, Manchester, United Kingdom
    Contribution
    Investigation
    Competing interests
    No competing interests declared

  10. Suzanne M Pilkington

    Division of Musculoskeletal and Dermatological Sciences, Faculty of Biology, Medicine and Health, School of Biological Sciences, Manchester Academic Health Science Centre, The University of Manchester and Salford Royal NHS Foundation Trust, Manchester, United Kingdom
    Contribution
    Investigation
    Competing interests
    No competing interests declared

  11. Inchul Cho

    Centre for Stem Cells and Regenerative Medicine, King's College London, Guy's Hospital, London, United Kingdom
    Contribution
    Investigation
    Competing interests
    No competing interests declared
    ORCID icon "This ORCID iD identifies the author of this article:" 0000-0001-5527-0962

  12. Niwa Ali

    1. Centre for Stem Cells and Regenerative Medicine, King's College London, Guy's Hospital, London, United Kingdom
    2. The Francis Crick Institute, London, United Kingdom
    Contribution
    Methodology
    Competing interests
    No competing interests declared
    ORCID icon "This ORCID iD identifies the author of this article:" 0000-0003-4473-8747

  13. Lesley E Rhodes

    Division of Musculoskeletal and Dermatological Sciences, Faculty of Biology, Medicine and Health, School of Biological Sciences, Manchester Academic Health Science Centre, The University of Manchester and Salford Royal NHS Foundation Trust, Manchester, United Kingdom
    Contribution
    Methodology, Resources, Writing – review and editing
    Competing interests
    No competing interests declared
    ORCID icon "This ORCID iD identifies the author of this article:" 0000-0002-9107-6654

  14. Fiona M Watt

    Centre for Stem Cells and Regenerative Medicine, King's College London, Guy's Hospital, London, United Kingdom
    Contribution
    Funding acquisition, Resources, Supervision, Writing – original draft, Writing – review and editing
    For correspondence
    fiona.watt@kcl.ac.uk
    Competing interests
    FW is on secondment as Executive Chair of the Medical Research Council. The author has no other competing interests to declare
    ORCID icon "This ORCID iD identifies the author of this article:" 0000-0001-9151-5154

Funding

Cancer Research UK (C219/A23522)

  • Fiona M Watt

Medical Research Council (MR/PO18823/1)

  • Fiona M Watt

Wellcome Trust (206439/Z/17/Z)

  • Fiona M Watt

Wellcome Trust (WT94028)

  • Lesley E Rhodes

NIHR Manchester Biomedical Research Centre

  • Nathan J Hawkshaw
  • Lesley E Rhodes

European Molecular Biology Organization (ALTF594-2014)

  • Emanuel Rognoni

Medical College of Saint Bartholomew’s Hospital Trust

  • Thomas Kirk

The funders had no role in study design, data collection and interpretation, or the decision to submit the work for publication.

Acknowledgements

We thank the Nikon Imaging Centre, Dylan Herzog from the Microscopy Innovation Centre here, and BSU facility at KCL for expert assistance. Further, we would like to thank Matteo Battilocchi (KCL) and Dr Monica Sen (KCL) for assistance with in vivo experiments and the lymph node isolation, respectively. We would also like to thank Prof Edel O’Toole (Queen Mary University of London) for critically reading the manuscript. FMW acknowledges financial support from the UK Medical Research Council (MR/PO18823/1), the Wellcome Trust (206439/Z/17/Z) and Cancer Research UK (C219/A23522). ER is the recipient of a European Molecular Biology Organization (EMBO) long-term fellowship (ALTF594-2014) and advanced fellowship (ALTF523-2017), and TK received funding from the Medical College of Saint Bartholomew’s Hospital Trust. This work was funded by grants to FMW. The human study was funded by the Wellcome Trust (grant WT94028, LER) and the NIHR Manchester Biomedical Research Centre (NJH, LER).

The authors acknowledge the use of core facilities provided by financial support from the Department of Health via the National Institute for Health Research (NIHR) comprehensive Biomedical Research Centre award to Guy’s & St Thomas’ NHS Foundation Trust in partnership with King’s College London and King’s College Hospital NHS Foundation Trust.

Ethics

Human subjects: Ethical approval was granted by the Greater Manchester North NHS research ethics committee (ref: 11/NW/0567) for the studies presented in Figure 1 and Figure 6. Details of the time course analysis of UVR challenged human skin have been reported previously (Hawkshaw NJ et al. 2020). All volunteers provided written informed consent in accordance with the Declaration of Helsinki principles.

All animal experiments were subject to local ethical approval and performed under the terms of a UK government Home Office license (PPL 70/8474 or PP0313918).

Senior and Reviewing Editor

  1. Edward E Morrisey, University of Pennsylvania, United States

Version history

  1. Received: June 8, 2021
  2. Accepted: December 22, 2021
  3. Accepted Manuscript published: December 23, 2021 (version 1)
  4. Version of Record published: January 10, 2022 (version 2)

Copyright

© 2021, Rognoni et al.

This article is distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use and redistribution provided that the original author and source are credited.

Metrics

  • 2,280
    Page views
  • 424
    Downloads
  • 6
    Citations

Article citation count generated by polling the highest count across the following sources: Crossref, PubMed Central, Scopus.

Download links

A two-part list of links to download the article, or parts of the article, in various formats.

Downloads (link to download the article as PDF)

Open citations (links to open the citations from this article in various online reference manager services)

Cite this article (links to download the citations from this article in formats compatible with various reference manager tools)

  1. Emanuel Rognoni
  2. Georgina Goss
  3. Toru Hiratsuka
  4. Kalle H Sipilä
  5. Thomas Kirk
  6. Katharina I Kober
  7. Prudence PokWai Lui
  8. Victoria SK Tsang
  9. Nathan J Hawkshaw
  10. Suzanne M Pilkington
  11. Inchul Cho
  12. Niwa Ali
  13. Lesley E Rhodes
  14. Fiona M Watt
(2021)
Role of distinct fibroblast lineages and immune cells in dermal repair following UV radiation-induced tissue damage
eLife 10:e71052.
https://doi.org/10.7554/eLife.71052

Categories and tags

Research organisms

Further reading

    1. Cell Biology
    2. Microbiology and Infectious Disease

    Synchronization of oscillatory growth prepares fungal hyphae for fusion

    Valentin Wernet, Marius Kriegler ... Reinhard Fischer
    Research Article Updated

    Communication is crucial for organismic interactions, from bacteria, to fungi, to humans. Humans may use the visual sense to monitor the environment before starting acoustic interactions. In comparison, fungi, lacking a visual system, rely on a cell-to-cell dialogue based on secreted signaling molecules to coordinate cell fusion and establish hyphal networks. Within this dialogue, hyphae alternate between sending and receiving signals. This pattern can be visualized via the putative signaling protein Soft (SofT), and the mitogen-activated protein kinase MAK-2 (MakB) which are recruited in an alternating oscillatory manner to the respective cytoplasmic membrane or nuclei of interacting hyphae. Here, we show that signal oscillations already occur in single hyphae of Arthrobotrys flagrans in the absence of potential fusion partners (cell monologue). They were in the same phase as growth oscillations. In contrast to the anti-phasic oscillations observed during the cell dialogue, SofT and MakB displayed synchronized oscillations in phase during the monologue. Once two fusion partners came into each other’s vicinity, their oscillation frequencies slowed down (entrainment phase) and transit into anti-phasic synchronization of the two cells’ oscillations with frequencies of 104±28 s and 117±19 s, respectively. Single-cell oscillations, transient entrainment, and anti-phasic oscillations were reproduced by a mathematical model where nearby hyphae can absorb and secrete a limited molecular signaling component into a shared extracellular space. We show that intracellular Ca2+ concentrations oscillate in two approaching hyphae, and depletion of Ca2+ from the medium affected vesicle-driven extension of the hyphal tip, abolished the cell monologue and the anti-phasic synchronization of two hyphae. Our results suggest that single hyphae engage in a ‘monologue’ that may be used for exploration of the environment and can dynamically shift their extracellular signaling systems into a ‘dialogue’ to initiate hyphal fusion.

    1. Cell Biology
    2. Microbiology and Infectious Disease

    A CRISPR-based rapid DNA repositioning strategy and the early intranuclear life of HSV-1

    Juan Xiang, Chaoyang Fan ... Pei Xu
    Research Article Updated

    The relative positions of viral DNA genomes to the host intranuclear environment play critical roles in determining virus fate. Recent advances in the application of chromosome conformation capture-based sequencing analysis (3 C technologies) have revealed valuable aspects of the spatiotemporal interplay of viral genomes with host chromosomes. However, to elucidate the causal relationship between the subnuclear localization of viral genomes and the pathogenic outcome of an infection, manipulative tools are needed. Rapid repositioning of viral DNAs to specific subnuclear compartments amid infection is a powerful approach to synchronize and interrogate this dynamically changing process in space and time. Herein, we report an inducible CRISPR-based two-component platform that relocates extrachromosomal DNA pieces (5 kb to 170 kb) to the nuclear periphery in minutes (CRISPR-nuPin). Based on this strategy, investigations of herpes simplex virus 1 (HSV-1), a prototypical member of the human herpesvirus family, revealed unprecedently reported insights into the early intranuclear life of the pathogen: (I) Viral genomes tethered to the nuclear periphery upon entry, compared with those freely infecting the nucleus, were wrapped around histones with increased suppressive modifications and subjected to stronger transcriptional silencing and prominent growth inhibition. (II) Relocating HSV-1 genomes at 1 hr post infection significantly promoted the transcription of viral genes, termed an ‘Escaping’ effect. (III) Early accumulation of ICP0 was a sufficient but not necessary condition for ‘Escaping’. (IV) Subnuclear localization was only critical during early infection. Importantly, the CRISPR-nuPin tactic, in principle, is applicable to many other DNA viruses.

    1. Cell Biology

    Mitochondrial defects caused by PARL deficiency lead to arrested spermatogenesis and ferroptosis

    Enrico Radaelli, Charles-Antoine Assenmacher ... Marco Spinazzi
    Research Article Updated

    Impaired spermatogenesis and male infertility are common manifestations associated with mitochondrial diseases, yet the underlying mechanisms linking these conditions remain elusive. In this study, we demonstrate that mice deficient for the mitochondrial intra-membrane rhomboid protease PARL, a recently reported model of the mitochondrial encephalopathy Leigh syndrome, develop early testicular atrophy caused by a complete arrest of spermatogenesis during meiotic prophase I, followed by degeneration and death of arrested spermatocytes. This process is independent of neurodegeneration. Interestingly, genetic modifications of PINK1, PGAM5, and TTC19 – three major substrates of PARL with important roles in mitochondrial homeostasis – fail to reproduce or modify this severe phenotype, indicating that the spermatogenic arrest arises from distinct molecular pathways. We further observed severe abnormalities in mitochondrial ultrastructure in PARL-deficient spermatocytes, along with prominent electron transfer chain defects, disrupted coenzyme Q (CoQ) biosynthesis, and metabolic rewiring. These mitochondrial defects are associated with a germ cell-specific decrease in GPX4 expression leading arrested spermatocytes to ferroptosis – a regulated cell death modality characterized by uncontrolled lipid peroxidation. Our results suggest that mitochondrial defects induced by PARL depletion act as an initiating trigger for ferroptosis in primary spermatocytes through simultaneous effects on GPX4 and CoQ – two major inhibitors of ferroptosis. These findings shed new light on the potential role of ferroptosis in the pathogenesis of mitochondrial diseases and male infertility warranting further investigation.
