Revisiting the role of Dcc in visual system development with a novel eye clearing method

  1. Robin J Vigouroux
  2. Quénol Cesar
  3. Alain Chédotal  Is a corresponding author
  4. Kim Tuyen Nguyen-Ba-Charvet  Is a corresponding author
  1. Institut de la Vision, Sorbonne Université, INSERM, CNRS, France
https://doi.org/10.7554/eLife.51275
Share this article
Cite this article
  1. Robin J Vigouroux
  2. Quénol Cesar
  3. Alain Chédotal
  4. Kim Tuyen Nguyen-Ba-Charvet
(2020)
Revisiting the role of Dcc in visual system development with a novel eye clearing method
eLife 9:e51275.
https://doi.org/10.7554/eLife.51275
  2. Download BibTeX
  3. Download .RIS

Abstract

The Deleted in Colorectal Carcinoma (Dcc) receptor plays a critical role in optic nerve development. Whilst Dcc is expressed postnatally in the eye, its function remains unknown as Dcc knockouts die at birth. To circumvent this drawback, we generated an eye-specific Dcc mutant. To study the organization of the retina and visual projections in these mice, we also established EyeDISCO, a novel tissue clearing protocol that removes melanin allowing 3D imaging of whole eyes and visual pathways. We show that in the absence of Dcc, some ganglion cell axons stalled at the optic disc, whereas others perforated the retina, separating photoreceptors from the retinal pigment epithelium. A subset of visual axons entered the CNS, but these projections are perturbed. Moreover, Dcc-deficient retinas displayed a massive postnatal loss of retinal ganglion cells and a large fraction of photoreceptors. Thus, Dcc is essential for the development and maintenance of the retina.

Introduction

Deleted in Colorectal Carcinoma (Dcc) is a transmembrane receptor discovered as a potential tumor suppressor (Pierceall et al., 1994). Dcc binds the extracellular matrix protein Netrin-1 (Keino-Masu et al., 1996; Serafini et al., 1994). When bound to Netrin-1, Dcc activates downstream signaling partners such as MAP kinase, focal adhesion kinase (FAK) or Src kinases which ultimately influence cytoskeleton dynamics and cell motility (Mehlen et al., 2011; Ren et al., 2004). However, Dcc is also a dependence receptor (Mehlen et al., 2011; Mehlen et al., 1998) which triggers cell death in absence of Netrin-1 (Llambi et al., 2005; Mehlen et al., 2011). Although direct evidence linking Dcc to tumorigenesis was obtained in mice (Castets et al., 2012; Krimpenfort et al., 2012), mutations in DCC were also identified in patients suffering from rare neurodevelopmental disorders including congenital mirror movements (Depienne et al., 2011; Srour et al., 2010) and corpus callosum dysgenesis (Jamuar et al., 2017; Marsh et al., 2017).

Dcc is present in the developing central nervous system (CNS) and controls axon guidance and cell migration in the spinal cord, as well as in multiple brain areas (Belle et al., 2014; Fazeli et al., 1997; Fothergill et al., 2014; Laumonnerie et al., 2014; Schmidt et al., 2014; Srivatsa et al., 2014; Yee et al., 1999). Dcc expression persists in the postnatal and adult CNS where it is involved in synaptogenesis (Horn et al., 2013; Manitt et al., 2013) and myelination (Jarjour et al., 2008). In vivo evidence supporting Dcc function in CNS development was primarily obtained using Dcc knockout (KO) mice (a null allele) which lack Dcc in all cells (Fazeli et al., 1997). One of the most striking phenotype, a hypoplasia of the optic nerve, was reported in the visual system (Deiner et al., 1997; Shi et al., 2010). In Dcc KO embryos, a large fraction of the retinal ganglion cell (RGC) axons which connects the eye to the brain via the optic nerve is unable to exit the retina (Deiner et al., 1997). The presence of its ligand Netrin-1 at the optic disc, the exit point of the retina, together with the presence of hypoplasic optic nerves in Ntn1 hypomorph mutant embryos suggested that Netrin-1 acts as a long range cue attracting Dcc-expressing RGC axons towards the optic nerve head (Deiner et al., 1997; Shi et al., 2010).

Dcc expression persists in RGC axons after they exit the retina and even postnatally (Shi et al., 2010) but as Dcc null mice die at birth (Fazeli et al., 1997), its function at later stages of visual system development is unknown. In Xenopus laevis tadpoles, Netrin-1 attracts RGC axons toward the optic disc (Shewan et al., 2002) and promotes RGC axon arborization and synapse formation within the tectum (Manitt et al., 2009). Importantly, recent studies using conditional knockout strategies have revisited the role of Netrin-1 in axon guidance at the CNS midline and suggested that Netrin-1 does not act as a long-range attractive cue for axons (Dominici et al., 2017; Moreno-Bravo et al., 2019; Varadarajan et al., 2017; Wu et al., 2019). Although the conditional ablation of Dcc in specific neuronal classes recapitulates the axon guidance defects found in Dcc KO embryos in some systems (da Silva et al., 2018; Peng et al., 2018; Zelina et al., 2014), there is also evidence for a non-cell autonomous role in cortical projection neurons (Welniarz et al., 2017). Here, we have generated eye-specific Dcc mutants which are fully viable. We found that these mutant mice display severe optic nerve hypoplasia as well as axon pathfinding defects in visual centers that persist postnatally. These defects are accompanied by a massive elimination of RGCs and the death of a large subset of photoreceptors. We also describe EyeDISCO, a novel tissue-clearing method allowing whole-eye immunostaining that could open novel perspectives in vision research.

Results

Dcc is broadly expressed in the developing retina

The presence of Dcc in RGCs had been previously shown (Deiner et al., 1997; Shi et al., 2010). Here, we first studied the temporal and spatial expression pattern of Dcc in the developing mouse retina using an antibody recognizing the C-terminal region of Dcc (Mazelin et al., 2004). The first Dcc-immunoreactive cells were detected at embryonic day 11 (E11) in the dorsal half of the retina and co-localized with the early RGC marker, Islet1 (Figure 1A–B; n = 3)(Austin et al., 1995). The specificity of the antibody was supported by the absence of staining in retinas from Dcc KO embryos (Figure 1—figure supplement 1A–D; n = 3). To get a better understanding of the spatial distribution of Dcc-expressing cells, we carried out whole-mount immunohistochemistry of Dcc and Islet1 at E11 followed by iDISCO+ clearing (Renier et al., 2016) and confocal microscopy for three-dimensional (3D) rendering. This confirmed that the early expression of Dcc at E11 is restricted to the medio-dorsal retina (Figure 1C–D; n = 4). By E12, Dcc expression expanded and still co-localized with Islet1-positive cells (Figure 1E–H; n = 3) but not with the transcription factor Sox2 (Figure 1—figure supplement 1E–G; n = 3), a retinal progenitor cell (RPC) marker (Kamachi et al., 1998). Thus, Dcc is only present in post-mitotic cells in the early retina. By E15, Dcc expression was broader and spanned both the apical and basal retina. Dcc-positive cells were either immunoreactive for Islet1 (Figure 1I–L; n = 3), or for Cone-rod homeobox protein Crx (Crx; Figure 1—figure supplement 1H–J; n = 3), which is expressed by post-mitotic photoreceptor cells.

Figure 1 with 1 supplement see all
Download asset Open asset
Dcc is broadly expressed in the mouse retina.

(A) Immunohistochemistry (IHC) of Dcc (arrow, green) and the retinal ganglion cell marker Islet1 (magenta), at E11. Non-specific Dcc signal is seen in mesenchymal cells (arrowhead) (B) is a high magnification image. (C,D) Whole-mount IHC of an E11 eye for Dcc (white, arrow) and Islet1 (green) counterstained with the nuclear marker TO-PRO-3 (blue). (E) Dcc (green) and Islet1 (magenta) IHC at E12. (F–H) are high magnification images. (I–L) Dcc (green) and Islet1 (magenta) IHC at E15. Scale bars: (A–H) 50 μm, (I,K) 30 μm, (J,L) 10 μm. ON, Optic Nerve.

A novel eye-specific Dcc mutant

Eyelid opening and retinal maturation in the mouse occur around the second postnatal week. As Dcc full knockout mice (Dcc-/-) die a few hours following birth, whether Dcc could be involved in later stages of visual system development is unknown. To address this issue, we used mice driving the Cre-recombinase under the promoter of Dickkopf-3 (Dkk3), a gene specifically expressed by RPCs (Sato et al., 2007). Crossing these Cre driver mice with mice carrying a tdTomato reporter, we found that the Cre was successfully driven in the retina (and not in other parts of the CNS) as early as E9 (n = 3) and with a complete retinal recombination by E10 (a time which precedes the onset of Dcc expression) (Figure 2A–C; n = 3). To ensure that Dcc protein was completely removed in the Dkk3:cre;Dccfl/fl mice prior to optic nerve exit, we carried out a Dcc immunolabeling on E11 retinas. Dcc+ cells were found in Dccfl/fl retinas, but not in Dkk3:cre;Dccfl/fl retina (Figure 2—figure supplement 1A–D; n = 3 for each genotype).

Figure 2 with 1 supplement see all
Download asset Open asset
Retina-specific inactivation of Dcc.

(A) Schematic representation of an E10 embryo (upper left) showing the neural retina (red) and the optic vesicle (gray). (B,C) Lateral views of the eye from Dkk3:cre;RosaTom E9 and E10 embryos after whole-mount labeling for dsRed (Rosa tomato) and Pax2 (optic vesicle). (C) Represents the whole-mount lateral visualization, whereas (D–O) shows the orientation of the sagittal cryosections. (D–O) Cryosections of E12 Dccfl/fl and Dkk3:cre;Dccfl/fl embryos labeled for Chx10 (magenta) and Islet1 (green). Scale bars: (B,C) 30 μm, (D–O) 50 μm. D, dorsal; V, ventral; O. Ves, optic vesicle.

Figure 2—source data 1

Eye-specific loss of Dcc does not impact the proliferation of retinal progenitor cells.

https://cdn.elifesciences.org/articles/51275/elife-51275-fig2-data1-v2.xlsx

We next questioned whether the retinal progenitor pool (expressing Ceh-10 homeodomain-containing homolog, Chx10, also known as visual system homeobox2, Vsx2) (Liu et al., 1994) as well as the generation of RGCs (Islet1) were maintained in Dcc mutants. At E12, no obvious defects were seen in mutants (n = 3) compared to Dccfl/fl littermates (Figure 2D–O; n = 3). Furthermore, EdU incorporation showed no proliferation rate defects in progenitor cells (Figure 2—figure supplement 1E–L, Figure 2—source data 1; n = 3).

Complexity of RGC guidance defects in Dcc KO revealed by a novel eye clearing method

Abnormal RGC projections towards the optic nerve head were previously reported in Dcc-/- embryos (Deiner et al., 1997) however, the long-term consequence of these defects on the retina are unknown and the exact spectrum of RGC projection defects have not been precisely studied. This is primarily due to the difficulty of inferring complex axon trajectories from simple retinal sections or retinal flat-mounts. In recent years, several tissue clearing protocols have been implemented to study the 3D cellular organization of complex organs such as the brain (Klingberg et al., 2017; Renier et al., 2016; Richardson and Lichtman, 2015; Tainaka et al., 2018; Tomer et al., 2014; Vigouroux et al., 2017). However, these methods do not remove melanin from the layer of retinal pigment epithelium (RPE) cells which cover the retina (as early as E12), thereby blocking light. Therefore, successful eye clearing remains a burning issue in the field (Susaki and Ueda, 2016). The current solution to this problem is to dissect out the RPE but this does not maintain eye integrity. To solve this problem, we devised a novel tissue clearing protocol (see methods), EyeDISCO, that completely clears embryonic and adult mouse eyes (Figure 3A–B’).

Figure 3
Download asset Open asset
EyeDISCO, a novel tissue clearing protocol for embryonic eye visualization.

(A) Schematic representation of the EyeDISCO protocol. The embryo is dehydrated in methanol and incubated in an 11% H2O2 solution irradiated with a 3000 °K warm white light. The sample is then included in a homemade chamber for confocal microscopy and 3D rendering. (B,B’) Images of an E12 embryo before and after EyeDISCO clearing. (C–H) Lateral view of whole-mount E12 eyes immunolabeled for the RGC axon marker, Tag1 (white) and the RGC nuclear marker (Islet1) counterstained with the nuclear marker TO-PRO-3 (blue). Several axons misproject in the Dkk3:cre;Dccfl/fl mutants (red arrowheads) or are stalled at the optic disc. Scale bars: (C–H) 50 μm. D, dorsal ; V, ventral.

Pioneer RGC axons, born at E11, extend their projections ventrally along the choroid fissure and into the presumptive optic disc (Goldberg, 1977; Silver, 1984). To investigate whether Dcc deletion induced a defect in pioneer axon pathfinding, we carried out whole-mount immunostaining of Tag1 (Transient axonal glycoprotein 1, also known as Contactin 2) on E12 embryos followed by EyeDISCO clearing (Figure 3A–B). Tag1 is expressed by all sensory axons including RGC axons (Chatzopoulou et al., 2008). In Dccfl/fl mice, Tag1+ RGC projections extended ventrally towards the optic disc and into the optic nerve where they fasciculated (Figure 3C–E; n = 3). However, in Dcc cKO mice some RGC projections extended ventrally to the optic disc and stalled, forming thick RGC axon bundles (Figure 3F–H; n = 4). In addition, several RGCs misprojected and extended dorsally through the retina and into the sub-retinal space. Therefore, eye-specific deletion of Dcc leads to pioneer RGC projection defects.

To further assess RGC projections in Dkk3:cre;Dccfl/fl mutant embryos, we carried out Tag1 immunostaining on whole E16 embryonic heads followed by EyeDISCO clearing (Figure 4A–C). Using manual segmentation (see methods) of the visual pathways (retina, optic nerve, optic chiasm, and optic tracts), we specifically isolated these structures from the rest of the head (Figure 4D). We next questioned whether RGC axon guidance defects in Dcc-/- embryos were phenocopied in Dkk3:cre;Dccfl/fl embryos. In both Dcc-/- (n = 8 nerves) and Dkk3:cre;Dccfl/fl mice (n = 6 nerves) there was a significant reduction in optic nerve volume compared to Wildtype mice (Figure 4E–H, Figure 4—source data 1; n = 8 nerves). Heterozygous deletion of Dcc (Dkk3:cre;Dcclox/+) had no effect on optic nerve volume (n = 4 nerves).

Figure 4 with 2 supplements see all
Download asset Open asset
Early Dcc deletion leads to major intra-retinal axonal misprojections.

(A–A’) Illustrates the clearing efficiency of the EyeDISCO protocol of an E16 mouse head. (B) Schematic representation of a top view of an E16 head, OB: olfactory bulb, Hb: hindbrain, R: rostral, C: caudal. (C–G) IHC whole-mount of E16 heads labeled for Tag1 (green). (D) E16 embryo head labeled with Tag1 in (C) with the visual projections manually segmented (white). (E–G) Segmented visual projections in E16 Wildtype, Dcc-/-, and Dkk3:cre;Dccfl/fl embryos. R: retina, ON: optic nerve, OC: optic chiasm, OT: optic tract, N: nasal, T: temporal. (H) Quantification of optic nerve volumes (μm3) represented as a box plot, whiskers represent min to max values. Dcc-/- (0.165 ± 0.022 μm3; n = 8 nerves) and Dkk3:cre;Dccfl/fl embryos (0.140 ± 0.23 μm3; n = 6 nerves) displayed a significant reduction in optic nerve volume compared to Wildtype embryos (0.858 ± 0.07 μm3; n = 8 nerves) (p=0.0002 and p=0.0007 respectively, Mann-Whitney test). Heterozygous deletion of Dcc (Dkk3:cre;Dcclox/+) had no effect on optic nerve volume (0.97 ± 0.02 μm3; p=0.2828; n = 4 nerves, Mann-Whitney test). Results were considered non-significant (ns) when p>0.05. ***=p < 0.001. (I,J,K,L) Cryosections of E15 Dccfl/fl and Dkk3:cre;Dccfl/fl eyes immunolabeled for Laminin (green) and Tag1 (magenta). (I) In controls, RGC projections (magenta) grow circumferentially and enter the optic nerve. (K) In Dkk3:cre;Dccfl/fl embryos, RGC projections perforate the retina and stall at the optic disc, some projections manage to exit into the ON. (J,L) High magnification images. (L) In Dkk3:cre;Dccfl/fl embryos, RGC projections extend apically and invade the sub-retinal space (arrow), separating the RPE and the apical retina (future photoreceptor outer segments). (M–P) Individual masks of aberrantly projecting RGCs across different mutants. Asterisks show the optic nerve. D, Dorsal; V, Ventral; N, Nasal; T, Temporal. Scale bars: (C,D) 1000 μm, (E–G) 300 μm, (I–P) 150 μm.

Figure 4—source data 1

Retina-specific deletion of Dcc leads to a significant reduction in optic nerve volume.

https://cdn.elifesciences.org/articles/51275/elife-51275-fig4-data1-v2.xlsx
Figure 4—source data 2

Early Netrin-1 deletion in the retina leads to a significant reduction in optic nerve volume.

https://cdn.elifesciences.org/articles/51275/elife-51275-fig4-data2-v2.xlsx

We then investigated whether the optic nerve (ON) hypoplasia observed in Dcc mutant mice was a result of fewer RGCs projecting into the optic nerve head. Analysis of E16 Dkk3:cre;Dccfl/fl mutant retinas immunolabeled for Tag1 showed that RGC projections exhibited multiple patterns. A subset of RGCs projected basally along the retinal lamina and into the optic nerve (Figure 4G; Figure 4—video 1). Another subset extended apically into the sub-retinal space at many sites all along the eye (Figure 4G; Figure 4—video 1). Interestingly, these projections separated the future photoreceptor cell outer segments from contacting with the RPE which is critical for their survival (Figure 4I–L; Strauss, 2005). Analysis of retinal cryosections at P7 showed that aberrant RGC axons, expressing ßIII-tubulin, separated the photoreceptor outer segments from the RPE (Figure 4—figure supplement 1A–D). Of note, these abnormal projections either stalled in the sub-retinal space or joined the optic nerve. Importantly, manual segmentation showed that although these projections exited at multiple sites, they fasciculated and formed major bundles that spanned the medial and ventral retina (Figure 4M–P; n = 4).

To determine whether the RGC axon phenotype observed in Dcc cKO mice was dependent on Netrin-1 signaling, we generated an eye-specific conditional deletion of Netrin-1 (Dkk3;cre;Ntn1fl/fl). At E16, we observed a significant reduction in optic nerve volume in Ntn1 null mice (Ntn1-/-) (Moreno-Bravo et al., 2018) (n = 9; Figure 4—figure supplement 1F,H; Figure 4—source data 2). Likewise, E16, Dkk3;cre;Ntn1flfl embryos displayed a major reduction in optic nerve volume (n = 5) (Figure 4—figure supplement 1G,H; Figure 4—source data 2).

Altogether, eye-specific deletion of Dcc prompted early RGCs to misproject apically through the retina. Furthermore, eye-specific deletion of Netrin-1 phenocopied the defect observed in Dcc cKO mice.

Retinal projections in the brain are altered in eye-specific Dcc mutants

The observation that a significant proportion of RGCs were still able to project their axons into the optic nerve in the absence of Dcc prompted us to study their projections within the brain. Mouse RGCs connect to at least 40 different brain nuclei (Morin and Studholme, 2014). To get the most comprehensive and faithful image of visual projections we used axonal tracers and iDISCO+ whole-brain clearing (Renier et al., 2016). Mice were injected intravitreally with AlexaFluor-555 or AlexaFluor-647-conjugated cholera toxin β-subunit (CTB) (see methods) allowing to distinguish ipsi- and contra-laterally projecting RGCs. iDISCO+ cleared brains were imaged using light sheet fluorescence microscopy (LSFM) (Figure 5A,B, Figure 5—video 1).

Figure 5 with 1 supplement see all
Download asset Open asset
Retinal projections in the brain are altered in eye-specific Dcc mutants.

(A,B) Frontal view of 3D-rendered brains using after anterograde axon tracing of visual projections with AlexaFluor-555 and/or AlexaFluor-647-conjugated cholera toxin β subunit (CTB). RE: right eye, LE: left eye, OC: optic chiasm, SCN: supra chiasmatic nucleus, MTN: medial terminal nucleus, LGN: lateral geniculate nucleus, NOT: nucleus of the optic tract, OPT: olivary pretectal nucleus, SC: superior colliculus. (A) Control brain, and (B) a Dkk3:cre;Dccfl/fl brain. (C) Surfaces of manual and automatic segmentation of visual projections using Imaris software in a control brain. Superior colliculus (cyan), dorsal lateral geniculate nucleus (green), ventral lateral geniculate nucleus (red), medial terminal nucleus (magenta), optic nerve and optic tract (yellow). (D,E) Top view of the optic nerve, optic chiasm, and optic tract. (F) Quantification of optic nerve volumes at P15 (6.36 × 106 ± 1.92 × 106 μm3; n = 4; compared to 3.12 × 107 ± 1.92 × 106 μm3; n = 5; p=0.0159) and 1 month (9.67 × 106 ± 2.48 × 106 μm3; n = 4; compared to 5.32 × 107 ± 2.51 × 106 μm3; n = 5; p=0.0159). A Mann-Whitney test was used to measure the significance. (G) Quantification of optic tract volumes (μm3) at P15 (1.73 × 107 ± 3.13 × 106 μm3; n = 4; compared to 5.97 × 107 ± 3.42 × 106 μm3; n = 5; p=0,0159) and 1 month (4.76 × 107 ± 8.37 × 106 μm3; n = 5; compared to 1.86 × 108 ± 9.11 × 106 μm3; n = 7; p=0.0025). A Mann-Whitney test was used to measure the significance. (H,I) Top view of the superior colliculus. Dcc cKO mice display a defasciculated NOT and OPT (yellow arrowhead), as well as an aberrant segregation of ipsilateral RGC projections (yellow asterisk). (J) Percentage of ipsilateral projections normalized to the contralateral projections (volume, μm3) of the superior colliculus. At 1 month, ipsilateral superior colliculus volume represented 4.565 ± 0.1424% (n = 5) in Dccfl/fl mice compared to 16.39 ± 2.091% in Dkk3:cre;Dccfl/fl mice (p=0.0079, n = 5). A Mann-Whitney test was used to measure the significance. (K–N) Frontal view of the contra- and ipsi-lateral geniculate nucleus. dLGN: dorsal lateral geniculate nucleus, vLGN: ventral lateral geniculate nucleus, IGL: inner geniculate leaflet. (F,K) Ipsilateral lateral geniculate nucleus. (O) Percentage of ipsilateral projections normalized to the contralateral projections (volume, μm3) of the lateral geniculate nucleus were not altered in Dcc cKO mice (37.89 ± 3.751%; n = 4) compared to control littermates (46.36 ± 3.795%; n = 6; p=0.352) A Mann-Whitney test was used to measure the significance. (P,Q) Frontal view of the medial terminal nucleus, dMTN: dorsal medial terminal nucleus, vMTN: ventral medial terminal nucleus. Dcc cKO mice show disturbed projections between the dMTN and the vMTN (yellow arrowhead). (R) Quantification of medial terminal nucleus volumes (ventral and dorsal, μm3). At P15, Dcc cKO mice display a reduction (5.51 × 106 ± 1.44 × 106 μm3; n = 4) compared to control (1.23 × 107 ± 1.79 × 105 μm3; n = 5; p=0.0159). At 1 month, this loss was maintained (7.89 × 106 ± 2.55 × 106 μm3; n = 5; compared to 2.24 × 107 ± 5.95 × 105 μm3; n = 6; p=0.0043). A Mann-Whitney test was used to measure the significance. Whiskers represent min to max values. *=p < 0.05, **=p < 0.01. Scale bars: (A,B) 1000 μm, (H,I) 500 μm, (D,E,K,L,M,N, P,Q) 300 μm.

Figure 5—source data 1

Dcc cKO mice show a significant reduction of RGC projection volumes in multiple brain visual nuclei.

https://cdn.elifesciences.org/articles/51275/elife-51275-fig5-data1-v2.xlsx

We first focused on the primary visual system which consists of the optic nerve, optic chiasm, optic tract, lateral geniculate nuclei, and the superior colliculus. In order to quantify differences, we carried out automatic segmentation of CTB-stained nuclei using Imaris software (see materials and methods). From this segmentation we generated surfaces with Imaris that retraced RGC projections in each visual system nuclei (Figure 5C). Volume of each surfaces were extracted in μm3 and quantified to analyze main differences. Analysis of Dkk3:cre;Dccfl/fl mutant brains showed that despite some heterogeneity between the amount of reduction between eyes, optic nerve volumes were dramatically reduced by about half at P15 and 1 month (Figure 5D,E,F; Figure 5—source data 1; n = 4 for Dcc cKO; n = 5 for Dccfl/fl). In addition, optic tract volumes were significantly reduced at P15 (n = 5) and 1 month (Figure 5G; Figure 5—source data 1; n = 5 for Dcc cKO; n = 7 for Dccfl/fl). Thus, early RGC projection defects and RGC death translate to a major reduction in fiber volume projecting into the visual nuclei postnatally.

During RGC projections refinement, which occurs between P5 and P15 in mice, ipsilaterally projecting RGCs segregate to form a robustly stereotypic L-shaped rostral patch in the superior colliculus (Godement et al., 1984). We found that at 1 month, the ipsilateral patch represented ~5% (n = 5) of each superior colliculus in Dccfl/fl mice. Interestingly, there was a significant expansion of this ipsilateral territory to ~16% in Dkk3:cre;Dccfl/fl mice (Figure 5H,I,J; Figure 5—source data 1; n = 5). On the other hand, analysis of projections within the lateral geniculate nucleus (ventral and dorsal) did not show an expansion in ipsilateral territory (Figure 5K–O; Figure 5—source data 1).

To date, very little is known about the development of the Accessory Optic System (AOS) (Osterhout et al., 2015; Sun et al., 2015). We therefore wondered whether deletion of Dcc in RGCs could also lead to AOS defects. The most striking effect in Dcc cKO mice was observed in the medial terminal nucleus (MTN), which can be subdivided into a ventral (vMTN) and dorsal (dMTN) nucleus (Lilley et al., 2019). In Dcc mutant mice, RGCs targeted appropriately the vMTN and some RGCs also projected to the dMTN. Projections connecting the vMTN to dMTN were completely absent (Figure 5P,Q). In P15 Dcc cKO mice, MTN volume was significantly reduced (n = 4) compared to Dccfl/fl mice (Figure 5R; Figure 5—source data 1; n = 5). This effect was maintained at 1 month in Dcc cKO mice (n = 5) compared to control littermates (Figure 5R; Figure 5—source data 1; n = 6). Dkk3:cre;Dccfl/fl mice also displayed defects in other AOS nuclei such as the nucleus of the optic tract (NOT) and the olivary pretectal tract (OPT). Their projections appeared defasciculated (Figure 5H,I). Taken together, eye-specific Dcc deletion perturbs RGC axon targeting in the main and accessory visual systems.

Dcc intracellular signaling is required for retinal projection targeting in the brain

Dcc has been shown to act as a co-receptor to other guidance receptors (Corset et al., 2000; Hong et al., 1999; Ly et al., 2008) suggesting that the observed defect might not directly, or solely, involve Netrin-1/Dcc signaling. To address this question, we studied the visual system of DccKanga mice, which bear a mutation in the exon encoding for the intracellular P3 domain of Dcc (Finger et al., 2002). This domain is critical for Dcc signaling downstream of Netrin-1 (Zhang et al., 2018). As previously described, we were unable to obtain viable Dcckanga/kanga mice (Welniarz et al., 2017). Thus, heterozygous Dcc kanga mutants (Dcckanga/+) were crossed with Dcc knockout animals (Dcc+/-) to generate Dcckanga/- mutants that possess one Dcc allele with the Kanga mutation and one null allele.

Dcckanga mice were injected with the CTB tracer and adult brains were cleared and imaged using LSFM for 3D rendering (Figure 6; Figure 6—video 1). In Dcckangakanga/- mice (n = 9), the optic nerve volume was significantly reduced compared to Dcckanga/+ mice (Figure 6A–C; Figure 6—source data 1; n = 5). The optic tract volume was also significantly reduced (n = 9) in Dcckangakanga/- mice compared to Dcckanga/+ mice (Figure 6D; Figure 6—source data 1; n = 5). Of note, no significant differences in optic nerve or optic tract volumes were observed between Dcc+/+, Dcc+/-, and Dcckanga/+ (Figure 6C,D; Figure 6—source data 1). Interestingly, comparisons between DccKanga mice and Dcc cKO mice showed no significant differences in optic nerve and optic tract volume (Figure 6—figure supplement 1A,B; Figure 6—source data 2). We next assessed whether projections within the superior colliculus were disturbed in Dcckangakanga/- mice. Unlike in Dkk3:cre;Dccfl/fl mice, no major defect was observed in the segregation of ipsilateral projections in Dcckangakanga/- mutants compared to Dcckanga/+ control mice (Figure 6E,F). Furthermore, no major defects were observed in both thalamic nuclei of the ventral and dorsal lateral geniculate nucleus (Figure 6G–J).

Figure 6 with 2 supplements see all
Download asset Open asset
Dcc signaling is required for RGC projection targeting.

(A–M) Whole-brain 3D rendering of RGC projections traced using AlexaFluor555-CTB or AlexaFluor647-CTB. (A,B) Top view of the optic nerve, optic chiasm, and optic tract of 1 month-old Dcckanga/+ and Dcckanga/- mice. OC, optic chiasm; SCN, suprachiasmatic nucleus; OT, optic tract. (C) Quantification of optic nerve volume (μm3) in Dcckangakanga/- mice (1.67 × 107 ± 1.97 × 106 μm3; n = 9) were significantly reduced compared to Dcckanga/+ mice (5.89 × 107 ± 3.98 × 106 μm3; n = 5; p=0.0010, Mann-Whitney test). (D) Optic tract volume (μm3) of Dcckangakanga/- mice were also significantly reduced (0.624 × 108 ± 7.09 × 106 μm3; n = 9) compared to Dcckanga/+ mice (1.50 × 108 ± 1.99 × 106 μm3; n = 5; p=0.0020, Mann-Whitney test). (E, F) Top view of the superior colliculus. NOT, nucleus of the optic tract; OPT, olivary pretectal nucleus; SC, superior colliculus. (G,H,I,J) Frontal view of the contra-lateral LGN. dLGN, dorsal lateral geniculate nucleus; vLGN, ventral lateral geniculate nucleus; IGL, inner geniculate leaflet. (K,L) Frontal view of the MTN. dMTN, dorsal medial terminal nucleus; vMTN, ventral medial terminal nucleus. (M) Quantification of MTN volume (μm3) of Dcckangakanga/- mice (0.788 × 107 ± 1.43 × 106 μm3; n = 9) compared to Dcckanga/+ littermate controls (1.66 × 107 ± 2.09 × 106 μm3; n = 5; p=0.0190, Mann-Whitney test). Results were considered non-significant (ns) if p>0.05. *=p < 0.05; **=p < 0.01; ***=p < 0.001. Scale bars: (A,B) 150 μm (E,F) 300 μm, (G,H,I,J, K, L) 200 μm.

Figure 6—source data 1

Dcc Kanga mice display a major reduction of RGC projections in multiple brain visual nuclei.

https://cdn.elifesciences.org/articles/51275/elife-51275-fig6-data1-v2.xlsx
Figure 6—source data 2

Dcc kanga mice show a similar reduction in visual nuclei volumes compared to Dcc cKO mice.

https://cdn.elifesciences.org/articles/51275/elife-51275-fig6-data2-v2.xlsx

The AOS was also affected in Dcckangakanga/- mice, as shown by a significant reduction of the volume of the MTN (n = 9) compared to Dcckanga/+ littermate controls (Figure 6K–M; Figure 6—source data 1; n = 5). This reduction in MTN volume was comparable to that observed in Dcc cKO mice (Figure 6—figure supplement 1C; Figure 6—source data 2). RGC projections to the MTN in Dcckangakanga/- mutants displayed multiple projection defects (Figure 6—figure supplement 1D,E). No defects were observed in other AOS nuclei.

Eye-specific deletion of Dcc alters retinal layer thickness

To determine whether Dcc could play a role beyond optic nerve formation, we first immunostained postnatal retinas to observe whether Dcc protein was still present. At P0 (n = 3) and P7 (n = 3), Dcc protein was absent from the cell bodies but was still heavily expressed in the postnatal retina (Figure 7A–F). It was localized to the neuropil layers of the retina, the inner and outer plexiform layers (Figure 7A–F).

Figure 7 with 3 supplements see all
Download asset Open asset
Eye-specific deletion of Dcc leads to reductions in retinal layers thickness.

(A–F) IHC of postnatal retinas labeled for Dcc (green) and the horizontal and amacrine cell marker, Calbindin (CaBP, magenta). (A–C) P0 retinas. (D–F) P7 retinas. (G–R) Cryosections of 1 month-old retinas of Dccfl/fl and Dkk3:cre;Dccfl/fl mice. (G,H,M,N) CaBP IHC (green) that labels amacrine cells that stratify in the IPL strata S2, S3, and S4. (I,J,O,P) IHC for choline O-acetyltransferase (Chat) that labels starburst amacrine cells which arborize in the IPL strata S2 and S4. (K,L,Q,R) show merge images. Yellow dashed lines delineate the retinal contours. Scale bars: (A–F,H,J,L,N, P,R) 25 μm; (G,I,K,M,O,Q) 50 μm. NBL, Neuroblastic Layer; ONL, Outer Nuclear Layer; OPL, Outer Plexiform Layer; INL, Inner Nuclear Layer; IPL, Inner Plexiform Layer; GCL, Ganglion Cell Layer.

Figure 7—source data 1

Early loss of Dcc leads to a significant and progressive degeneration of RGCs.

https://cdn.elifesciences.org/articles/51275/elife-51275-fig7-data1-v2.xlsx
Figure 7—source data 2

Eye-specific loss of Dcc does not induce a loss of SACs but impacts retinal thickness.

https://cdn.elifesciences.org/articles/51275/elife-51275-fig7-data2-v2.xlsx
Figure 7—source data 3

RGC loss is dependent on Dcc signaling.

https://cdn.elifesciences.org/articles/51275/elife-51275-fig7-data3-v2.xlsx

Since early RGCs misproject in Dcc cKO mice we questioned whether RGCs were affected in postnatal and adult mice. P0, P15, and 1 month-old retinas were flat-mounted and labeled for a pan-RGC marker (Kwong et al., 2010), RNA-binding protein with multiple splicing (Rbpms; Figure 7—figure supplement 1A–F). Whole-eye immunostaining with Rbpms confirmed the gradual loss of RGCs from P15 to 1 month (Figure 7—figure supplement 1G–J; Figure 7—source data 1). Of note, RGC loss was homogeneously distributed in mutant retinas. Strikingly, the number of RGCs was dramatically reduced by ~60% in Dkk3:cre;Dccfl/fl mice at P0 (n = 4 retinas) when compared to Dccfl/fl mice (Figure 7—figure supplement 1K; Figure 7—source data 1; n = 6 retinas). The number of Rbpms-positive cells decreased to ~82% in P15, Dkk3:cre;Dccfl/fl mice (n = 4 retinas) and even further to ~91% at 1 month (Figure 7—figure supplement 1K; Figure 7—source data 1; n = 6 retinas). Displaced RGCs were not included in our analysis. Thus, eye-specific loss of Dcc leads to a dramatic degeneration of RGCs.

Unlike Dcc-/- mice, Dkk3:cre;Dccfl/fl conditional mutants are viable allowing us to investigate the role of Dcc in retinal lamination, which is established postnatally. The inner plexiform layer (IPL) is subdivided into 5 specific lamina named stratum 1 to 5 (S1-S5, S5 being closest to the RGC layer) (Wässle, 2004). Since Dcc deletion led to early retinal defects, we wondered whether the earliest born amacrine cells, starburst amacrine cells (SACs) (Voinescu et al., 2009) displayed defects. In control mice, both ON- and OFF- SACs express choline O-acetyltransferase (Chat) and their dendrites stratify in S2 and S4 of the IPL (Figure 7I,K,L). Whole-mount immunostaining of flat-mounted retinas with Chat revealed the mosaic distribution of SACs (Figure 7—figure supplement 2A–F). The number of SACs in the GCL was unchanged at P15 (n = 4) and 1 month (n = 6) in Dcc cKO mice compared to Dccfl/fl mice (Figure 7—figure supplement 2G; Figure 7—source data 2). Furthermore, no significant difference was observed in the number of SACs soma in the inner nuclear layer in Dcc cKO mice at P15 (n = 4) and 1 month compared to Dccfl/fl controls (Figure 7—figure supplement 2H, Figure 7—source data 2; n = 6). However, sagittal cryosections of 1 month-old Dcc cKO retinas labeled for Chat showed that the relative thickness of the S2-S4 was significantly reduced in Dcc cKO mice (Figure 7O,P,R; n = 3) compared to Dccfl/fl mice (Figure 7I,K,L; Figure 7—figure supplement 2I,J; Figure 7—source data 2; n = 3). There were no aberrant dendrite projections of Chat+ SACs in Dkk3:cre;Dccfl/fl mice compared to Dccfl/fl littermates (n = 3 for each genotype).

This observation led us to question whether the overall thickness of the IPL was also affected. Horizontal cells as well as displaced amacrine cells were visualized using the calcium-binding protein Calbindin (CaBP) (Wässle, 2004). At 1 month, Dccfl/fl retinas showed that displaced amacrine cell dendrites stratified at the border of S1-2, S2-3, and S3-4 (Figure 7G,H,K,L; Wässle, 2004). Dkk3:cre;Dccfl/fl displayed a significant reduction in the IPL (n = 3) compared to Dccfl/fl mice (Figure 7—figure supplement 2J; Figure 7—source data 2; n = 3). We nonetheless found that CaBP+ amacrine cells exhibited normal lamina-specific neurite stratification in the IPL (Figure 7M,N,Q,R). We analyzed the overall thickness of the retina from the outer segments of photoreceptors to the soma of RGCs. At 1 month, mutant retinas displayed a dramatic reduction in thickness compared to Dccfl/fl retinas (Figure 7—figure supplement 2J; Figure 7—source data 2; n = 3). Of note, this reduction was homogeneous across the entire retina.

To determine whether loss of RGCs was dependent on Dcc signaling, we carried out a Rbpms whole-mount immunostaining of DccKanga eyes (Figure 7—figure supplement 3A,B). At 1 month, RGC numbers were dramatically reduced by ~72% in Dcckangakanga/- mutants (n = 4) compared to the Dcckanga/+ control littermates (Figure 7—figure supplement 3C; Figure 7—source data 3; n = 4). We next investigated whether the number of SACs were affected in Dcckanga mutants. In the RGC layer, SACs was not affected in Dcckangakanga/- mice (n = 4) compared to DccKanga/+ mice (Figure 7—figure supplement 3D,E; n = 4). The total number of SACs in the inner nuclear layer was also unchanged in Dcckangakanga/- retinas (n = 4) compared to Dcckanga/+ littermates (Figure 7—figure supplement 3F; Figure 7—source data 3; n = 4).

Dcc deletion leads to major retinal dysplasia and visual deficits

In order to assess the overall eye phenotype in Dkk3:cre;Dccfl/fl conditional knockout mice, we adapted the EyeDISCO protocol for adult mouse eyes (see Materials and methods; Figure 8A–B’). This led to a modest and isotropic (rostro-caudal/medio-lateral/dorso-ventral) shrinkage of the tissue of ~11% (Figure 8—figure supplement 1A–D, Figure 8—source data 2, n = 8 eyes). By eye fundoscopy, large lesions were observed in Dcc cKO mutant retinas (Figure 8C,D). To analyze the precise localization and density of these lesions, we carried out whole-mount nuclear staining (TO-PRO-3) followed by EyeDISCO clearing and LSFM. 3D rendering showed that eye-specific Dcc mutants displayed abnormal conformation of photoreceptors that resembled rosette-like structures, reminiscent of photoreceptor degeneration (Figure 8E,F, Figure 8—video 1; Chang et al., 2002; Flynn et al., 2014). Rosette-like structures were specifically located in the outer nuclear layer of the retina (photoreceptor layer) and the area they covered was manually segmented (Figure 8G,H, Figure 8—video 2). This showed that unlike RGC loss, which was homogeneous in the retina, rosette structures were specifically localized as a band that spanned naso-temporally with a ventral bias (Figure 8I–N; n = 8). To confirm that rosettes were composed of photoreceptors, we carried out whole-mount immunolabeling for short-wavelength opsin (Opn1sw), which is known to be present in the ventral half of the retina (Applebury et al., 2000; Ortín-Martínez et al., 2014). At 1 month, Opn1sw was expressed in high-ventral and low-dorsal gradient in the Dccfl/fl eyes (Figure 8O; Figure 8—video 2; n = 6 eyes). In Dcc mutants, Opn1sw gradient was conserved, but rosette-like structures were observed in Opn1sw+ photoreceptor cells (Figure 8P; Figure 8—video 2; n = 6 eyes). We next questioned whether specific types of photoreceptors would cluster in rosettes. To do so, we labeled retinas with short- and mid-wavelength opsins as well as Rod-specific opsin (Rhodopsin). All types of photoreceptors were present within rosettes (Figure 8—figure supplement 2A–P).

Figure 8 with 6 supplements see all
Download asset Open asset
EyeDISCO, a novel tissue clearing protocol for whole eye visualization.

(A) Is a representation of the EyeDISCO clearing pipeline. Adult eyes are dehydrated in methanol and immersed in an 11% H2O2 solution irradiated with a 3000°K warm white light (red arrow). After immuno-labeling the eyes are cleared and imaged using light sheet microscopy. (B, B’) Side view image of an adult eye (1 month) before and after EyeDISCO clearing. (C,D) Eye fundoscopy of a 1 month-old Dccfl/fl and a Dkk3:cre;Dccfl/fl eye. Dkk3:cre;Dccfl/fl fundoscopy shows a severe dysplasia (yellow arrows). Eye coordinates are highlighted, D, dorsal, V, ventral,N, nasal, T, temporal. (E,F) Whole eye of Dccfl/fl and Dkk3:cre;Dccfl/fl mice after EyeDISCO treatment labeled with a nuclear marker (TO-PRO-3, white). Major dysplasia can still be observed in Dkk3:cre;Dccfl/fl eyes (yellow arrows). (G) Represents a slice of the 3D stack from a Dkk3:cre;Dccfl/fl eye. The dysplasia can be isolated by manual segmentation with Imaris (magenta, yellow arrow). (H) The affected area visualized in 3D (magenta) following manual segmentation. (I–N) 3D surfaces of rosette masks in 3 separate Dkk3:cre;Dccfl/fl mice showing both the left and right eye. (O, P) Whole-mount IHC of eyes of Dccfl/fl and Dkk3:cre;Dccfl/fl 1 month-old eyes labeled for short-wavelength Opsin (Opn1sw, white). (Q) A merge of 3 separate masks using Imaris from Dkk3:cre;Dccfl/fl mice showing rosette area coverage and retina circumference. (R) Quantification of rosette area coverage in retinas. No differences in rosette coverage were seen between Dcc cKO and control littermates at P15 (21.85 ± 2.48%; n = 5 eyes), 1 month (20.11 ± 1.67%; n = 5 eyes; p>0.999) and 6 months (17.68 ± 3.76%; n = 5 eyes; p=0.6176). A Kruskal-Wallis test was used to measure significance. Data are represented as a box plot; whiskers represent min to max values. Results were considered non-significant (ns) if p>0.05. Scale bars: (E–H, I–N) 300 μm, (O, P) 500 μm, (O, P) high magnification) 150 μm, (Q) 400 μm.

Figure 8—source data 1

Rosette volume in Dcc cKO mice does not progress overtime.

https://cdn.elifesciences.org/articles/51275/elife-51275-fig8-data1-v2.xlsx
Figure 8—source data 2

EyeDISCO leads to a mild and isotropic shrinkage of the adult mouse eye.

https://cdn.elifesciences.org/articles/51275/elife-51275-fig8-data2-v2.xlsx
Figure 8—source data 3

Outer nuclear layer thickness is reduced in Dcc cKo mice.

https://cdn.elifesciences.org/articles/51275/elife-51275-fig8-data3-v2.xlsx
Figure 8—source data 4

Retinal-specific deletion of Dcc leads to a significant reduction in retinal physiology.

https://cdn.elifesciences.org/articles/51275/elife-51275-fig8-data4-v2.xlsx

To determine whether loss of Dcc in early retinal development led to progressive photoreceptor degeneration, Dkk3:cre;Dccfl/fl mutant eyes were cleared at P15, 1 month, and 6 months (n = 5). The eyes were then manually segmented for rosette-like structures and the percentage of rosette territory covered in each retina was quantified (Figure 8Q). No significant differences were observed in retinas between P15, 1 month, and 6 months (Figure 8R; Figure 8—source data 1; n = 5 eyes). Thus, rosette structures in mutant mice do not progress over time. We then investigated whether photoreceptors outside of rosettes were also affected. To address this, we carried out an immunolabeling on 1-month-old retinas with the pan-photoreceptor marker, Recoverin. We observed that in Dcc cKO retinas (n = 3) photoreceptors were dramatically reduced compared to Dccfl/fl controls (n = 3) (Figure 8—figure supplement 2Q–U; Figure 8—source data 3).

Finally, we also observed that rosettes induce a significant loss in physiological visual response. Electroretinogram (ERG) at 1 month showed that the scotopic response of Dcc cKO mice was significantly reduced in a-wave but not b-wave complexes (Figure 8—figure supplement 3A; Figure 8—source data 4). This reduction persisted at 6 months in a-wave but not b-wave complexes (Figure 8—figure supplement 3A). To assess cone function, we also analyzed the photopic response in Dcc cKO mice and found a dramatic loss of photopic response at 1 and 6 months (Figure 8—figure supplement 3B; Figure 8—source data 4). Altogether, eye-specific deletion of Dcc leads to rosette formation in the photoreceptor layer of the retina. These rosettes are localized to the naso-temporal retina and do not progress overtime.

Strikingly, as was observed in our Dcc cKO mice, rosettes were present in Dcc Kanga mutants as early as P15 suggesting a developmental defect (Figure 8—figure supplement 4E–F; n = 4 eyes). These rosettes were still present at 1 month (Figure 8—figure supplement 4F–G; n = 9 Dcckanga/- and n = 10 Dcckanga/+). Both short- and mid-wavelength cones were present within the rosettes (Figure 8—figure supplement 4E–G). Therefore, altered Dcc signaling leads to the formation of rosettes in the outer nuclear layer of the retina.

Discussion

Dcc is essential for RGC intraretinal axon guidance

Early eye development begins from the invagination of the optic vesicle to form the optic cup (Bernstein et al., 2018). This morphogenetic event gives rise to the neural retina and forms an opening along the ventral midline that will become the future optic disc, also known as the choroid fissure (Bernstein et al., 2018). Early RGCs are polarized and extend within the basal retina, constituting the optic fiber layer (OFL). RGC axons further extend circumferentially towards the presumptive optic disc where they exit the retina (Bao, 2008). Therefore, two mechanisms are at play during the intraretinal navigation of RGC axons.

The first process involves the basal lamina at the vitreal side which provides a growth-promoting substrate for RGC axons. Several guidance cues such as Slits and Semaphorin3E restrict RGC axons to the OFL (Jin et al., 2003; Steinbach et al., 2002; Thompson et al., 2006). However, the basal lamina does not provide directionality (Halfter et al., 1987; Halfter and Fua, 1987) and other guidance cues such Sfrp1, Sfrp2, EphB2, EphB3, Netrin-1 present in the retina (Birgbauer et al., 2000; Deiner et al., 1997; Marcos et al., 2015), and Slit2 present in the lens (Thompson et al., 2006) orient RGC axons towards the optic disc.

Interestingly, pioneer RGC axons extend into the optic vesicle during choroid fissure closure (Deiner et al., 1997; Kuwabara and Weidman, 1974). Perturbations of this event have been associated with optic nerve defects (Cai et al., 2013; Dakubo et al., 2003; Morcillo et al., 2006; Otteson et al., 1998; Silver and Robb, 1979). It was recently shown that Netrin-1 is required for choroid fissure closure, and that Ntn1-/- mice display highly penetrant colobomas (Hardy et al., 2019). We observe that our Ntn1 cKO also exhibit colobomas (80% penetrance, n = 5), suggesting that Netrin-1 at the optic disc is required for proper choroid fissure closure. We could not detect any choroid fissure defects in either Dcc cKO or Dcc null mutant mice suggesting that Netrin-1 may mediate choroid fissure fusion in a Dcc-independent manner.

The first born RGCs arise in the dorso-central retina in close proximity to the pax2-positive optic disc cells (Drager, 1985) expressing Netrin-1 (Deiner et al., 1997). Interestingly, we observe no significant differences between the optic nerve hypoplasia displayed in Netrin-1 null mice and Ntn1 cKO mice. Thus, as it was described in the hindbrain and the spinal cord (Dominici et al., 2017; Moreno-Bravo et al., 2019; Varadarajan et al., 2017; Wu et al., 2019), it is likely that Netrin-1 acts intraretinally in a short-range manner.

Dcc is necessary for retinal ganglion cell projections in the primary and accessory optic systems

RGC projections initially reach the thalamus and the superior colliculus during embryonic development (Godement et al., 1984). Different axon guidance molecules are critical for the proper targeting of RGC projections to the thalamus and to the superior colliculus. In the absence of reelin, RGC axons fail to target the vLGN and the IGL correctly (Su et al., 2011). Once RGC axons have reached their target they then refine between ipsi- and contra-lateral territories. During this process, EphB or ephrinBs are required for RGCs to dictate their final position in the superior colliculus (Hindges et al., 2002; Thakar et al., 2011). In the Dcc cKO, RGCs target the LGN and superior colliculus normally but we observe an expansion of the ipsilateral territory, thus hinting at a possible refinement defect. Netrin-1 and Dcc have been shown to play a role in RGC axon arborization and synapse formation within the optic tectum of Xenopus tadpoles (Manitt et al., 2009). Here, we show for the first time that intra-retinal loss of Dcc leads to an expansion in ipsilateral territory in the murine SC. Nevertheless, we cannot rule out that the expansion in ipsilateral projections within the SC may be a result of the significant death of RGCs observed in Dcc cKO retinas.

The organization of the accessory optic system (AOS) projections to the MTN, the NOT, and the OPT is altered in Dcc mutants. These defects were constant and reproducible. Moreover, AlexaFluor-CTB is fluorescent enough to label isolated axons (Li et al., 2015) and therefore it is unlikely that a significant fraction of visual axons could not be traced. Although the major input to the AOS is constituted of ON Direction Selective Ganglion Cells (DSGC) (Dhande et al., 2013), ON-OFF DSGCs also project to AOS nuclei (Kay et al., 2011). The MTN is innervated by ON-OFF DSGCs which control eye movement and give information for upward motion (dMTN) or downward motion (vMTN) (Borst and Euler, 2011; Yonehara et al., 2009). However, RGCs projecting to the MTN are homogeneously spread across the retina (Sun et al., 2015). Little is known about the cues guiding DSGC axons to the MTN besides the transmembrane semaphorin Sema6A and its receptors PlexinA2/A4 (Sun et al., 2015). Contactin-4 and the amyloid precursor protein are necessary for DSGC’s axons to project in the NOT, but not the MTN (Osterhout et al., 2015). As Dcc protein is homogeneously expressed in embryonic RGCs, one could wonder why we observe a specific guidance defect in the MTN. One hypothesis could be that co-receptors of Dcc, such as Unc5d could potentiate the MTN defect observed in our Dcc mutants (Murcia-Belmonte et al., 2019). Furthermore, the differential distribution of Netrin-1 protein within the visual nuclei could be another area of study to explain the heterogeneous defects observed in our Dcc mutants. Still, we cannot rule out that the loss of RGCs in our Dcc mutants could impact axonal arborization due to a reduced competition between neighboring RGC axons. Further investigations should be performed to test whether DSGCs may be specifically impacted by Dcc perturbation using MTN-specific mouse lines such as the SPIG1:GFP (Yonehara et al., 2008) and Hoxd10:GFP (Dhande et al., 2013) knock-in mouse lines. Overall, we uncover a new role for Dcc in the innervation of the MTN, the NOT and the OPT.

Why do RGCs die in eye-specific Dcc mutants?

Although the overall death of RGCs is homogeneous, only a portion aberrantly invade the subretinal space. This suggests that the death of RGCs is not merely correlated to the misprojection phenotype. To survive, RGCs require trophic factors such as brain-derived neurotrophic factor (BDNF), ciliary neurotrophic factor (CNTF), neurotrophin 4 (NT4), and fibroblast growth factor (FGF) secreted by the superior colliculus (Meyer-Franke et al., 1995; Raff et al., 1993). A possibility is that too few RGC axons make it to the superior colliculus to provide sufficient trophic support. This massive RGC death could also result from the elimination of the misrouted RGCs axons as previously demonstrated in the zebrafish (Poulain and Chien, 2013). Netrin-1 through Dcc has been shown to promote synaptogenesis of cortical neurons (Goldman et al., 2013). Therefore, an abnormal synaptogenesis of Dcc-deficient RGC axons with their target neurons could also induce their degeneration.

Photoreceptor cell degeneration

In addition to RGCs death Dcc cKO mutants display major retinal dysplasia, limited to the retinal outer nuclear layer. These undulations in the ONL often referred as rosettes in the literature (Mears et al., 2001), are among the most prominent features of retinal degeneration along with photoreceptor cell death and underdeveloped outer segments (Genové et al., 2014). In Dkk3:cre;Dcclox/lox mice, the rosettes are only present in the inferior half of the retina but span from the nasal to the temporal sides. To our knowledge, localized rosettes have only been described in Crb1 mutant mice. Crb1rd8/Crb1rd8 mice display rosettes in the inferior nasal quadrant of the retina (Mehalow et al., 2003) whereas in Crb1–/– mice retinal degeneration occurs in the inferior temporal quadrant (van de Pavert et al., 2004). Importantly, Dcc cKO mice have been backcrossed into a C57BL/6J background and are negative for the rd10 mutations (Supplementary file 3). What could explain the degeneration of a subset of photoreceptors? Based on our results, it is more likely that this phenotype is related to the intra-retinal pathfinding defects. First, rosettes were observed as early as E15, concomitantly with the first misrouted axons in the retina. Therefore, misguided RGC axons invading the subretinal space could separate photoreceptors from RPE. Indeed, interactions between the RPE and presumptive photoreceptor outer segments are crucial for their proper development (Marmorstein, 2001). Early ablation (E10–11) of RPE in mouse retina also results in a disorganization of retinal layers (Raymond and Jackson, 1995). Moreover, rats with dysfunctioning RPE cells show photoreceptor death (D'Cruz et al., 2000). Second, several studies have linked rosette formation with outer limiting membrane defects (Mehalow et al., 2003; Rich et al., 1995; Stuck et al., 2012). It is thus likely that misguided RGC axons in our Dcc cKO mice alter the outer limiting membrane leading to photoreceptor degeneration. Third, we show that Dcc is expressed homogeneously in Crx+ cells at E15. Using the Dkk3 promoter leads to a complete removal of Dcc in all retinal progenitors. If Dcc played a role in proper photoreceptor development we would expect that all photoreceptor cells would degenerate. Finally, we observe that M- and S-cones as well as rods are all present within rosettes. These results support the idea that in Dcc cKO mice, photoreceptor cell death is not limited to a specific cell type but rather triggered by RGC axons. Nonetheless, retinal physiology in our Dcc mutants is globally perturbed, indicating either that rosettes (which account for ~20% of the retina) are sufficient to impact the ERG or that photoreceptor defects may not only be restricted to rosette territories. Quantification of the ONL outside of rosettes in Dcc cKO mice shows a dramatic thinning compared to control littermates. It would be of interest to investigate whether Dcc plays a cell autonomous role in photoreceptors.

Dcc’s mechanism of action

Here, we show that Dcc acts cell autonomously in RGCs to confine their axons to the retina but that the phenotype is heterogeneous. In Dkk3:cre;Dccfl/fl mice, some RGC axons exit the retina and even project to the CNS, suggesting that they are still properly guided in the absence of Dcc. On the other hand, other RGC axons aberrantly project apically into the subretinal space. These results suggest that the long-range guidance of RGC axons to the optic disc is not mediated by Dcc. It rather acts as a short range guidance receptor preventing RGC axons from escaping the neural retina and staying in the OFL, as shown for hindbrain commissural axons (Moreno-Bravo et al., 2018; Yung et al., 2018). Another in vivo example of the short-range guidance role of Dcc/Netrin-1 signaling was shown in R8 photoreceptor growth cones in Drosophila melanogaster, which could successfully project but not attach properly in their terminal zone (Akin and Zipursky, 2016). Why the phenotype is heterogeneous is unclear as the expression levels of Dcc (based on immunocytochemistry) in embryonic RGCs appear similar across the retina. This could be explained by a differential expression of co-receptors or downstream partners in different subclasses of RGCs. Evidence for this phenotypic heterogeneity is also found at a later stage and further suggests that specific populations of RGCs are differentially affected by the loss of Dcc.

Most of Dcc’s known functions such as growth cone attraction are mediated by its P3 intracellular domain (Finger et al., 2002). The DccKanga mice lacking the exon encoding the P3 intracellular domain present the same phenotype as the Dcc KO mice, with a missing corpus callosum and an aberrantly projecting corticospinal tract (Finger et al., 2002). The observation that DccKanga mice share many of the phenotypes observed in Dcc cKO mice suggests that they are indeed directly dependent on Dcc signaling and not the signaling of a Dcc co-receptor. Moreover, we show that deletion of Netrin-1 phenocopies the defects observed in the embryonic retina. Thus, we demonstrate that Dcc/Netrin-1 signaling is critical for the proper targeting of RGCs.

EyeDISCO is a powerful technique to study the eye

In the past decade, there have been significant developments in tissue clearing protocols. However, none have addressed the challenge of clearing densely pigmented tissues (Susaki and Ueda, 2016). Recent protocols allowing for whole-mouse visualization are still hindered by densely pigmented tissues such as the eyes or the skin (Cai et al., 2019; Pan et al., 2016; Tainaka et al., 2018). Efforts to remove densely pigmented tissues such as the melanophores of the RPE of the eye have almost entirely been carried out on tissue sections (Alexander et al., 1996; Orchard, 2007). For instance, using potassium permanganate and oxalic acid in aqueous conditions Iwai-Takekoshi and colleagues were able to remove RPE pigments in embryonic sections (Iwai-Takekoshi et al., 2016). This depigmentation protocol has however been shown to reduce the compatibility/efficacy of immunolabelling (Alexander et al., 1996). Recently, a de-pigmentation protocol of postnatal eyes amenable to tissue clearing has been published (Henning et al., 2019). This protocol carries out an H2O2 treatment in aqueous conditions which favors the generation of microbubbles that damage the retina and result in retinal detachment (Henning et al., 2019). In addition, the H2O2 treatment is done at 55°C, further deteriorating as well as reducing antigenicity of the tissue. Only 2 antibodies were validated using this protocol. Here, we report an amenable tissue clearing protocol for whole-embryo and whole adult eye clearing compatible with immunolabeling. The immunolabeling protocol is carried out at RT and requires passive diffusion of low titer antibodies. Thus far, 17 antibodies have been validated, encompassing transcription factors, transmembrane and cytoplasmic proteins (Supplementary file 2).

A current limitation of our method is the cellular resolution at which we are able to carry out whole-eye imaging using LSFM, as our setup is composed of a macroscope with a 2X objective coupled to a 6.3X numerical zoom (12.6X) giving a maximum x/y resolution of 5.16 μm/pixel. However, the recent development of higher magnification objectives compatible with DBE will allow for more resolved images, equivalent to confocal microscopes, that enable whole-eye cell-counting approaches (Pan et al., 2019).

Altogether, EyeDISCO provides a novel opportunity to image the visual system like never achieved before. This protocol allows the study of visual projections from the eye to the brain, thereby constituting a powerful tool for the screening of mutants. This protocol could also prove extremely useful to study the eye as a whole for better understanding eye disorders.

Materials and methods

Ethics statement

Request a detailed protocol

All experiments were designed using the 3R rule: to reduce, refine, and replace the use of animals. All animal procedures were carried out according to approved institutional guidelines (#B-75-12-02) of the Institut de la Vision. The protocol was approved by the Sorbonne Université ethic committee (Charles Darwin) (Permit Number: 9571). In cases of animal handling, experiments were performed to minimize animal stress and suffering.

Animals

Dcc knockout mice (Fazeli et al., 1997), Dcckanga mice (Dcckanga; Jackson Laboratories) (Finger et al., 2002), Dcc floxed mice (Krimpenfort et al., 2012), Ntn1 floxed mice (Moreno-Bravo et al., 2018), and Dickkopf3:cre (Dkk3:cre) mice (Sato et al., 2007) were previously described. All mice are kept in C57BL/6J background. Cre expression was monitored by crossing Dkk3:cre mice with the Ai9 RosatdTomato reporter line (RosaTom; Jackson Laboratories). The day of the vaginal plug was counted as embryonic day 0.5 (E0.5). Mice were anesthetized with ketamine (80 mg/kg) (Axience) and xylazine (8 mg/kg) (Axience). Embryos and adult mice of either sex were used.

RD gene sequencing

Request a detailed protocol

PDE6brd1 mutations were investigated by direct Sanger sequencing. Genomic DNA was extracted using 50 mM NaOH for 30 min at 95°C. The following primers were used Forward: 5’ctgcacacagacatccagtc3’ Reverse: 5’ccatgcctggctgaagttgt3’. PCR was done using a Gotaq DNA Polymerase (Promega). Next, PRC products were sequenced using Sanger sequencing (BigDyeTermv1.1 CycleSeq kit, Applied Biosystems) and analyzed on an automated 48-capillary sequencer (ABI3730 Genetic analyzer, Applied Biosystems), and the results interpreted by applying a software (Seqscape, Applied Biosystems).

Immunohistochemistry

Request a detailed protocol

Embryos were fixed by immersion in 4% paraformaldehyde in 0.12 M phosphate buffer (VWR, 28028.298 and 28015.294), pH 7.4 (PFA) o/n at 4°C. Eyes were harvested and using a 301/2G needle, a small hole was made in the cornea. The eyes were then fixed in 4%PFA for 1 hr at RT. Following three washes in 1XPBS, the samples were incubated in 10% sucrose (VWR, 27478.296) in 0.12 M phosphate buffer o/n at 4°C. The next day, samples were transferred to a 30% sucrose solution in 0.12 M phosphate buffer o/n at 4°C. Samples were then embedded in 0.12 M phosphate containing 7.5% gelatin (Sigma, 62500) and 10% sucrose, frozen in isopentane at −50°C and then cut at 20 µm with a cryostat (Leica, CM3050S). Sections were blocked in PBS containing 0.2% gelatin (VWR) and 0.25% Triton-X100 (PBS-GT) for 1 hr at RT. Sections were then incubated with primary antibodies (see Supplementary file 1) diluted in a PBS-GT solution o/n at RT. Following three washes in PBST (0.05% Triton-X100) secondary antibodies coupled to the appropriate fluorophore (see Supplementary file 1) were diluted in PBS-GT and incubated for 2 hr at RT. Sections were counterstained with Hoechst (Sigma, B2883, 1:1000). Slides were scanned with either a Nanozoomer (Hamamatsu) or laser scanning confocal microscope (Olympus, FV1000). Brightness and contrast were adjusted using ImageJ.

Retinal thickness

Request a detailed protocol

To measure the thickness of retinal layers, 1 month-old control and Dkk3:cre;Dccfl/fl retinas were harvested and fixed in 4% PFA o/n at 4°C. Retinas were processed as previously described. Calbindin (Swant, see Supplementary file 1) and Chat (Millipore, see Supplementary file 1) immunostaining were used to visualize the IPL layers and Hoechst (Sigma) to visualize all retinal layers. Using NDP viewer (version 2.2.6), 5 retinal sections from the optic nerve were analyzed (n = 3 mice per group). Using the measure tool, the thickness (µm) of each layer was measured.

EdU proliferation

Request a detailed protocol

Pregnant females were injected intraperitoneally with 5-ethynyl-2´-deoxyuridine (EdU;1 mg/10 g) and sacrificed 3 hr following injection. Proliferating cells were visualized using the Click-iT EdU Imaging kit (Invitrogen) and were co-labeled with antibodies against Chx10 (Exalpha, see Supplementary file 1), a retinal progenitor cell marker. For co-localization of EdU/Chx10, the Imaris X 64 software (Bitplane, version 9.1.2) co-localization tool was used and the percentage of ROI co-localization was measured (threshold Chx10 = 320, threshold EdU = 147).

Tracing of visual projections

View detailed protocol

Mice were anesthetized with an intra-peritoneal injection of ketamine (100 mg/kg) and xylazine (10 mg/kg) and kept warm with a thermostatically controlled platform at 37°C. Corneal analgesia was done by applying chlorhydrate oxybuprocaine (1.6 mg/0.4 ml). The eye was proposed using bulldog forceps (FST, 18039–45). A 301/2-gauge needle was used to make a pre-hole at the dorsal side of the eye. Using a Nanofil syringe (World Precision Instruments, Nanofil) with a 331/2–gauge beveled needle (World Precision Instruments, NF33-BV2), 1.2 µl 2 µg/µl of AlexaFluor-conjugated cholera toxin β subunit (Thermo Fischer, AlexaFluor555-CTB C22843 and AlexaFluor647-CTB C34778) was injected intravitreally. To avoid leakage, the needle was slowly withdrawn over the span of 3 s. 72 hr following CTB injection, mice were transcardially perfused with 4%PFA and the brains were dissected for tissue clearing.

Flat mount

Request a detailed protocol

For retinal flat mounts, eyes were harvested and the retina were dissected and fixed by gentle shaking at 50 rpm in 4%PFA for 45 min at RT. The retinas were then washed three times in 1XPBS. For immunohistochemistry, retinas were permeabilized and blocked in a solution containing 0.5% Triton-X100, 5% donkey normal serum, 1XPBS, 0.1 g/L thimerosal for 1 day at RT under agitation. Primary antibodies (see Supplementary file 1) were diluted in a solution containing 0.5% Triton-X100, 5% donkey normal serum, 10% Dimethyl Sulfoxide, 1XPBS, 0.1 g/L thimerosal for 3 days at RT under agitation. The retinas were then washed for 1 day in PBST (1XPBS, 0.5% Triton-X100). The secondary antibodies (see Supplementary file 1) were diluted in the same solution as primary antibodies and left for 2 days. After washing retinas for 1 day, they were mounted on slides and imaged using a scanning confocal microscope (Olympus, FV1000).

For quantifications of Rbpms+ (Phosphosolutions, see Supplementary file 1) and Chat+ (Millipore, see Supplementary file 1) cells, the Imaris X 64 ‘Spots’ tool was used (Bitplane, version 9.1.2). For Rbpms+ staining, automatic segmentation was done. For Chat staining, a manual segmentation was carried out to separate the inner nuclear layer from the retinal ganglion cell layer. Automatic cell counting was then carried out on each segmentation.

Electroretinogram

Request a detailed protocol

All experiments were carried out in double-blind. Following o/n adaptation, animals were prepared under red light and were anesthetized with an intraperitoneal injection of ketamine (80 mg/kg) (Axience) and xylazine (8 mg/kg) (Axience). Pupils were dilated with 0.5% tropicamide (CSP) and 5% neosynephrine (CSP, France). Corneal analgesia was performed by applying chlorhydrate oxybuprocaine (CSP). Eyes were proposed using bulldog forceps (FST, 18039–45). Recording small gold loop electrode contacting the cornea through a layer of Lubrithal (Centravet) was used to record the retinal response, with needle electrode placed in the head and back used as the reference and ground electrodes, respectively. Body temperature was maintained at 37°C with a heating pad. Electroretinograms (ERGs) were obtained simultaneously from both eyes, the light stimulus was provided by Led in a Ganzfeld stimulator (Espion, Diagnosys LLC). Scotopic responses were measured in darkness, during flash stimulation (0.003 to 10 cd.s/m2), a flash duration of 4 ms. Scotopic ERG response is the mean of five responses. Photopic cone ERGs were performed on a rod-suppressing background after 5 min of light adaptation (2 cd.s/m2); recordings were obtained at light intensities of 10 cd.s/m2. Photopic ERG response is the mean of ten responses. Responses were amplified and filtered (1 Hz-low and 300 Hz-high cutoff filters) with a one-channel DC-/AC- amplifier.

Eye fundoscopy

Request a detailed protocol

Eye fundoscopy was carried out using (MicronIV, Phoenix Research Labs, USA). Pupils were dilated with 0.5% tropicamide (CSP) and 5% neosynephrine (CSP). Next, mice were anesthetized with 5% isoflurane inhalation (Axience) and maintained at 2% Lubrithal (Centravet) was used to protect the cornea during acquisition. To visualize blood vessels in vivo, an 0.1% sodium fluorescein tracer (Serb) was injected intraperitoneal and eye fundoscopy was carried out.

Whole-mount labeling and tissue clearing

EyeDISCO

Request a detailed protocol
De-pigmentation
Request a detailed protocol

For samples E12-E16, samples were fixed o/n at 4°C in 4% PFA. The embryos were then de-hydrated in succeeding baths of methanol for 2 hr each at RT (40% 1XPBS, 80% distilled water (dH2O), 100% methanol). Samples were then placed o/n in a de-pigmentation solution of methanol containing 11% H2O2 (VWR, 216763) at 70 rpm exposed to an 11W warm white Light-Emitting Diode (LED) (3000° Kelvin).

For samples E16-P7, samples were processed as described above. However, the de-pigmentation solution was refreshed twice per day to ensure full activity. For complete de-pigmentation approximately 2 days were required.

For samples P7-Adult, samples were processed as described above. For complete de-pigmentation approximately 5 days were required.

Once completely de-pigmented, samples were gently re-hydrated in 2 hr baths at RT (100% methanol, 80% dH2O, 40% 1XPBS, 1XPBS). Samples were kept at 4°C for further processing.

Whole-mount immunostaining
Request a detailed protocol

For eyes after P15, an incision was done in the cornea (1/4 of the perimeter). Samples were then permeabilized in the blocking solution (0.5% Triton-X100, 5% donkey normal serum, 1XPBS, 0.1 g/L thimerosal) for 1 day at RT on agitation. For immunostaining, samples were incubated with the primary antibodies (see Supplementary file 1) in a solution containing: 0.5% Triton-X100, 5% donkey normal serum, 20% Dimethyl Sulfoxide, 1XPBS, 0.1 g/L thimerosal. The primary antibody solution (see Supplementary file 1) was incubated for 7 days at RT. The samples were then washed for 1 day (6 changes) in PBST (0.5% Triton-X-100, 1XPBS, 0.1 g/L thimerosal). The secondary antibody (see Supplementary file 1) was diluted in the same solution as for the primary and passed through a 0.22 µm filter and incubated for 2 days in solution at RT under agitation. In some cases, samples were counterstained with the nuclear marker TO-PRO-3 (Life Technologies, T3605, 1:300). The samples were then washed for 6 times during 1 day in PBST, and 2 washes of 1XPBS prior to storing the samples in the dark at 4°C until clearing.

Agarose embedding
View detailed protocol

Embryos (E12) and eyes were embedded in 1.5% agarose (Roth) in 1X TAE (Life Technologies) prior to tissue clearing.

Tissue clearing
Request a detailed protocol

The iDISCO+ protocol was adapted. All steps were carried out in the dark in a fume hood by agitation at 10 rpm (SB3 tube rotator, Stuart) at RT using 15 ml centrifuge tubes (TPP). Following embedding, eyes were placed in 20% methanol diluted in 1XPBS o/n. The next day, eyes were de-hydrated in succeeding baths of methanol for 2 hr (40% 1XPBS, 60% 1XPBS, 80% dH2O, 100% methanol). The eyes were then placed in a solution containing 2/3 Dichloromethane (DCM, Sigma) 1/3 methanol o/n. The next day, eyes were placed in DCM for 30 min prior to being immersed in the imaging medium, Di-benzyl Ether (DBE, Sigma). The next day, samples were stored in individual light-absorbing glass vials (Roth) at RT.

3D imaging

Light sheet microscopy

Request a detailed protocol

All imaging was carried out as previously described Belle et al. (2017); Belle et al. (2014). Acquisitions were performed by using an ultramicroscope I (LaVision BioTec, Miltenyi Biotec) with the ImspectorPro software (LaVision BioTec, Miltenyi Biotec, 5.1.328 version). The light sheet was generated by a laser (wavelength 488, 561, 64, or 780 nm, Coherent Sapphire Laser, LaVision BioTec, Miltenyi Biotec) and a cylindrical lens for large working distance. A binocular stereomicroscope (Olympus, MXV10) with a 2x objective (Olympus, MVPLAPO) was used at different magnifications (0.63x, 1x, 1.25x, 1.6x, 2x, 2.5x, 3.2x, 4x, and 5x). Samples were placed in an imaging reservoir made of 100% quartz (LaVision BioTec, Miltenyi Biotec) filled with DBE and illuminated from the side by the laser light. A Zyla SCMOS camera (Andor, Oxford Instrument, 2,048 × 2048 pixels size) was used to acquire images. The step size between each image was fixed at 1 or 2 μm (NA = 0.5, 150 ms time exposure). All tiff images are generated in 16-bit.

Confocal microscopy

Request a detailed protocol

For 3D imaging using the confocal microscope (Olympus, FV1000), homemade chambers were created. Two ¼” stainless steel washers were stacked and glued (Best Klebstoffe) on a SuperFrost slide (ThermoScientific) and left to dry o/n at RT. The next day, the washers were sealed using dental cement (Dentalon Plus, R010024) and were left to dry for 2 hr at RT. The samples were then placed in the chambers and covered with DBE, a coverslip was then placed to secure the samples and was sealed using dental cement and left to dry for 2 hr at RT prior to imaging. For imaging, a scanning upright confocal microscope (Olympus, FV1000) was used with a 25X objective (Olympus, XLPLN25XSVMP2, NA = 1.0, WD = 4 mm).

Image processing

Request a detailed protocol

3D rendering of light sheet and confocal stacks were converted to an Imaris file (.ims) using ImarisFileConverter (Bitplane, 9.1.2 version or 9.2.1 version) and then visualized using the Imaris x64 software (Bitplane, 9.1.2 version or 9.2.1 version).

To isolate the visual projections of E16 embryos labeled for Tag1 (R and D systems, see Supplementary file 1), a manual segmentation of the retina, optic nerve, optic chiasm, and optic tracts was carried out. Optic nerve volumes were calculated by creating an automatic segmentation (x = 545, y = 300, z = 200, surface detail = 3.02 µm, automatic threshold) and volumes were extracted from the surface. For analyzing aberrant RGC projections, a manual segmentation was carried out to isolate RGC projections. This mask was then extracted by adjusting the outside pixels to 0 (black). To further isolate aberrant RGC projections, normal projections (inside the retina) were manually segmented and outside pixels were set to 0. Aberrant RGC projections were isolated by excluding normal RGC projections and a mask was generated and pseudo-colored.

For P15 and 1 month CTB-traced mouse brains, visual nuclei were segmented as follows. For optic nerves the surface was extracted by creating an automatic surface in a region of x = 545, y = 300, z = 200, surface detail = 8.13 µm and automatic threshold. For optic tracts, x = 526, y = 437, z = 797, surface detail = 8.13 µm and automatic threshold. For contra-lateral superior colliculi, x = 640, y = 640, z = 640, surface detail = 8.13 µm and automatic threshold. For segmentation of the optic nerve, optic tracts and contra-lateral superior colliculi, the semi-automatic surface was used with a surface details fixed at 8.13 µm and an automatic thresholding. For the contralateral and ipsilateral lateral geniculate nuclei, an automatic segmentation was applied using a set voxel box (x = 337, y = 265, z = 761), surface detail = 2.00 µm. The medial terminal nuclei were segmented using automatic segmentation using a set voxel box (x = 262, y = 232, z = 540) with a surface detail = 2.00 µm. Ipsilateral superior colliculi were manually segmented using the ‘isoline’ tool, with a reduced density at 10%. Once the structure was segmented, a surface was generated and the volume was extracted for further analysis.

For adult retinas, rosette-like structures were manually segmented and surfaces were generated. Surfaces were then pseudo-colored and aligned to each to the appropriate dorsal/ventral/nasal/temporal coordinates. To analyze rosette evolution, rosettes and retinas were separately segmented at P15, 1 month and 6 months. A surface was generated and the volume extracted. A ratio of rosette per retinal volume was then calculated.

Movies were generated using the animation tool on Imaris x64 software (Bitplane, version 9.1.2) and movie reconstruction with. tiff series were done using ImageJ (1.50e, Java 1.8.0_60, 64-bit). All movie editing (text and transitions) was done using iMovie (Apple Inc, version 10.1.1).

Statistical analyses

Request a detailed protocol

An observer blinded to the experimental conditions performed all the quantifications. All data are represented as mean values ± SEM. Statistical significance was estimated using two-tailed unpaired tests for non-parametric tendencies (Kruskall-Wallis or Mann-Whitney), two-way ANOVA and Bonferroni’s multiple comparison test. *=p < 0.05; **=p < 0.01; ***=p < 0.001, ****=p < 0.0001. All statistical measurements were carried out using GraphPad Prism 7.

Data availability

All data generated or analysed during this study are included in the manuscript and supporting files. All source files are provided.

References

    1. Alexander RA
    2. Cree IA
    3. Foss AJ
    (1996)
    The immunoalkaline phosphatase technique in immunohistochemistry: the effect of permanganate-oxalate melanin bleaching upon four final reaction products
    British Journal of Biomedical Science 53:170–171.
    1. Austin CP
    2. Feldman DE
    3. Ida JA
    4. Cepko CL
    (1995)
    Vertebrate retinal ganglion cells are selected from competent progenitors by the action of notch
    Development 121:3637–3650.
    1. Birgbauer E
    2. Cowan CA
    3. Sretavan DW
    4. Henkemeyer M
    (2000)
    Kinase independent function of EphB receptors in retinal axon pathfinding to the optic disc from dorsal but not ventral retina
    Development 127:1231–1241.
    1. Kamachi Y
    2. Uchikawa M
    3. Collignon J
    4. Lovell-Badge R
    5. Kondoh H
    (1998)
    Involvement of Sox1, 2 and 3 in the early and subsequent molecular events of Lens induction
    Development 125:2521–2532.
    1. Kuwabara T
    2. Weidman TA
    (1974)
    Development of the prenatal rat retina
    Investigative Ophthalmology 13:725–739.

Decision letter

  1. Carol A Mason
    Reviewing Editor; Columbia University, United States
  2. Marianne E Bronner
    Senior Editor; California Institute of Technology, United States
  3. Anand Swaroop
    Reviewer; National Institutes of Health, United States

In the interests of transparency, eLife publishes the most substantive revision requests and the accompanying author responses.

Acceptance summary:

This manuscript re-assessing the function of DCC during retinal development using a new eye-specific Dcc mutant mouse (Dkk-Cre) that removes Dcc specifically in retinal progenitors, thereby bypassing lethality at birth. The authors confirm previous reports that the absence of Dcc produces severe intra-retinal misguidance of RGC axons, and in postnatal brains, that some RGCs still leave the retina and project to visual nuclei with multiple targeting defects. Postnatal loss of RGCs also ensues and the photoreceptor layer does not develop properly, with rosette-like structures forming in the outer retina and reduced photoreceptor function. Both the projection and targeting defects and the photoreceptor results are apparent with a tissue clearing protocol the authors named "EyeDISCO" that provides striking view of the entire visual system and retina in whole mount. The approach overall constitutes a powerful mutant screen for eye and visual pathway perturbations.

Decision letter after peer review:

Thank you for submitting your article "Revisiting the role of Dcc in visual system development with a novel eye clearing method" for consideration by eLife. Your article has been reviewed by Marianne Bronner as the Senior Editor, a Reviewing Editor, and three reviewers. The following individuals involved in review of your submission have agreed to reveal their identity: Anand Swaroop (Reviewer #2).

The reviewers have discussed the reviews with one another and the Reviewing Editor has drafted this decision to help you prepare a revised submission.

Summary:

The reviewers were overall enthusiastic about your study, in which you generate an eye-specific DCC mutant mouse to more completely characterize the role of DCC in visual system development, especially at postnatal stages. Given that the total knockout dies at birth, you nicely demonstrate that DCC removal not only affects the exit of axons from the eye, as assumed for years, but severe intra-retinal misguidance of RGC axons occurs, unusually, some axons extending within the retina in between the RPE and photoreceptor layers. Further, even with the ensuing optic nerve hypoplasia, a subset of RGCs innervate retinorecipient regions in apparently display normal innervation patterns. The conditional loss of DCC in the eye also results in the novel phenotype of RGC loss and photoreceptor dysplasia in adult mice.

Your paper also includes a welcome optimization of a clearing protocol, EyeDISCO, that allows total removal of RPE pigment by bleaching and therefore a better visualization of the clarified retina and the eye-to-brain. The study thus expands our view of the role of DCC during axon pathway development and maintenance, and a bonus of an important methodology. The paper is a hybrid data presentation and tools and resources, and both aspects will be of high interest to the vision community.

However, even though the reviewers thought your paper suitable for eLife, they had numerous comments on the organization of the data and narrative, and encourage you to make the text more concise and better organized to highlight the main points.

They further thought that the clearing protocol, however useful, is too long and disrupts the flow of the paper, making the Results section a bit incoherent. We suggest putting the clearing methods in the Materials and methods section. In addition, the novelty of the new clearing/bleaching methods is diluted by presenting a greater proportion of the data using traditional flatmount/sectioning techniques.

Other comments to be addressed include clarifying the RGC projection phenotype to the MTN, explanations for why only certain RGCs make it to targets, and better resolution on photoreceptor loss, i.e., rods vs cones.

Finally, while the quantitative analyses are much appreciated, presenting the numbers within the Results section is distracting; these data could be presented in the figure legends.

Essential revisions:

We have included the reviews at the end of this email so that you can better amend the text. All of the listed points are deemed essential but are in the main textual.Reviewer #1:Vigouroux et al. here generate an eye-specific DCC mutant mouse to more completely characterize the role of DCC in visual system development. First, they analyze DCC expression during early development of the eye. Using their conditional DCC strategy, they find that RGCs lacking DCC display altered axonal trajectories, with a significant percentage extending toward the apical surface of the retina. As previously appreciated, these mice also have severe hypoplasia of the optic nerve. The authors note that not every RGC axon trajectory is altered, as some retinorecipient regions apparently display normal innervation patterns. Novel findings include the observation of severe retinal thinning, RGC loss, and photoreceptor dysplasia in adult mutant mice. In addition, they also present a novel whole eye tissue clearing method which they use to draw several of the conclusions made in this paper.

This study describes in great detail a role for DCC in the developing visual system, providing important data which complements that obtained previously by others using null DCC alleles. Though it was previously known that DCC interactions with netrin-1 are required for a large percentage of RGC axons to exit the eye early in development, it was unclear how DCC functions postnatally and into adulthood. Additionally, the presentation of a novel eye clearing model that allows visualization of axon trajectories in 3D space strengthens the conclusions drawn about DCC function in this paper. This clearing method will certainly aid in future studies of this type and will become a valuable resource for the field. For all of these reasons, this paper is appears to be suitable for publication eLife, following attention to points raised below.

1) Please comment as to why one side has a higher innervation density as indicated by CTB labeling in Figure 6B? One would expect that both projection patterns would be equally affected in this genetic background. Is this just animal to animal variability?

2) The point is made that there are apparently differential degrees of retinorecipient innervation defects in the eye-specific DCC mutant, however this seems to be based on the intensity CTB labeled projections (AOS targets (not only the MTN), which are not as densely innervated, appear weaker, as one might expect). The authors should provide more explanation to rule out issues relating to saturation of signaling in more densely innervated targets as opposed to those that receive innervation from many few RGCs. If there are is no additional evidence to support RGC subtype-specific effects resulting from the loss of DCC then this conclusion must be qualified.

3) Please speculate as to why different classes of RGCs and their projection patterns are thought to be differentially affected in these mutants? MTN vs. SC vs. LGN vs. SCN?

4) Please comment on whether, and to what degree, shrinkage is observed of the tissue using this novel clearing approach?

Reviewer #2:Vigouroux et al. have re-assessed the function of DCC during retinal development using a new eye-specific Dcc mutant mouse (by Dkk-Cre) to bypass lethality and by introducing a new tissue clearing protocol called "EyeDISCO" to remove melanin. Previously reported Dcc-knockout mice die a few hrs after birth, making it difficult to study DCC function in postnatal stages of visual system development. Using the new Dcc mutant that removes Dcc specifically in retinal progenitors, the authors are able to demonstrate that the absence of DCC results in RGC guidance defects (made possible for EyeDISCO) and postnatal loss of RGCs. The authors also describe the phenotype of kanga/- mutant mouse. Finally, the eye-specific Dcc mutant also shows rosette like structures in the outer retina and reduced rod function.

Overall, the results are significant. The data justify the conclusions. A major focus appears to be on eye-clearing methodology, which seems to be better than another published recently by Hennings et al., 2019, and demonstrating its use in elucidating the mutant phenotype that was previously difficult to observe. The phenotypes being described for the Dcc eye mutant provide new clues about its function. This is an appropriate article for Tools and Resources.

However, the story seemed to lack coherence and finesse. The main points could be better highlighted/organized. The novelty of the new clearing/bleaching methods is diluted by much of the data obtained via tradition flatmount/sectioning techniques.

Overall, the text is too long. The manuscript, especially Results section, requires tightening and can be made concise. While the quantitative analyses are much appreciated, too many numbers within the Results section create distraction. Similarly, too much of background and methodological detail within Results make it incoherent. Some of these could be shifted to Introduction or Methods section. The quantification numbers could be presented in the figure legends.

It's not clear what value the Dcc(kanga) model had for the study. Even if there was more of a difference, a direct comparison with the Dcc-cKO would be more useful than comparison to control only.

The photoreceptor part is quite interesting but not much explored. The rosettes are seen in a few other retinal mutants (such as Nrl-knockout and rd7). The authors should expand more in Discussion section on DCC function in photoreceptors and on how its loss leads to rosettes and loss of rods. The authors suggest that the defect is somewhat limited to s-cones but the authors should stain for m-cones.

It's not clear why cones would be affected more than rods, as it seems based on ERG data. The authors propose in the discussion that it could be a secondary defect resulting from misguided RGCs and potentially defective OLM. Why not co-stain for RGCs or OLM markers with PR markers? This would make a better case since the RGC defect is variable and we can't be sure that there are misguided RGCs in the same regions where the rosettes are. Why PRs are reduced in number? Seems to be developmental defect, not degeneration.

Reviewer #3:

In this work the authors use cutting edge technologies to visualize all the defects produced as a consequence of removing Dcc specifically from the retina. They first confirm previous reports showing that the absence of Dcc produces severe intra-retinal misguidance of RGC axons. Then, they discover that a subset of RGCs are still able to leave the retina and reach the visual nuclei where they project showing multiple targeting defects. They further notice defects in the photoreceptors layer, a phenotype not previously reported in Dcc null mice. To perform many of these analyses they optimize a protocol that allows total removal of pigment and therefore a better visualization of the clarified retina.

There are several reasons that make this work potentially suitable for this journal. First, it reveals for the first time that the absence of retinal Dcc does not only affect the exit of visual axons from the eye, as it has been assumed for years. Second, they conclusively show that the function of Dcc in the retina is restricted to a subpopulation, not to all, RGCs and suggest that Dcc is important for the targeting of retinal axon projections to the medial terminal nucleus in the brain. They also discover that Dcc is expressed in photoreceptors and it is necessary for the proper formation of the photoreceptors layer.

There are however several aspects of the paper that need to be clarified:

1) As the authors point out, the rosettes observed in the ventral retina are likely a consequence of the intra-retinal misrouting of RGC axons. In Figure 5Q, the layer of photoreceptors looks much thinner than in the controls. Is this phenotype homogeneous across the retina or it is also only restricted to the ventral part? In Figure 1—figure supplement 1I is shown that Dcc is expressed in Crx cells (Crx is a cone-rod specific TF) and because the Dkk3-cre line also removes genes from photoreceptors, it is possible that photoreceptors are being intrinsically and homogeneously affected through the entire retina and not only in the ventral retina as a consequence of RGC misrouting.

2) Subsection “Dcc intracellular signaling is required for retinal projection targeting in the Brain”. The authors infer a novel role for Dcc signaling in RGC guidance to the MTN from the projection phenotype to the MTN in the Dcc kanga mutants. Why is this population particularly affected? From what retinal region do the RGC projecting to the MTN come from? It would be possible to perform retrograde labeling from this nucleus to answer this question. If they all come from a particular region perhaps these cells are more affected because they have higher levels of Dcc?

3) It exists also the possibility that the phenotypes observed in the visual nuclei of Dcc mutants are the consequence of having fewer RGCs. In the main visual nuclei it seems likely that rather than a role for Dcc in guidance or targeting, the remaining RGC axon terminals arborize in a different manner because there is less competition between neighboring RGC axons. As the authors state, there is not much information about the timing, guidance or targeting mechanisms of visual axons projecting to the MTN and therefore, this possibility should be at least discussed.

4) I believe is not a good idea to make such a big deal about the optimization of the protocol to remove melanin. What is described in this manuscript is basically an improvement of previous protocols. Therefore, I think that, although is a nice and important advance and it should be mentioned, the part dedicated to explain the protocol is too long and distracts from the main message of the paper. It would be better to make a detailed description of the protocol in a technical or more specialized journal.

[Editors' note: further revisions were suggested prior to acceptance, as described below.]

Thank you for resubmitting your work entitled "Revisiting the role of Dcc in visual system development with a novel eye clearing method" for further consideration by eLife. Your revised article has been evaluated by Marianne Bronner (Senior Editor) and a Reviewing Editor.

All three of the reviewers are satisfied with your attempts to clarify the text and figures and with your explanations regarding the points raised in the reviews.

Your manuscript presents important data re-assessing the function of DCC during retinal development using a new eye-specific Dcc mutant mouse (Dkk-Cre) that removes Dcc specifically in retinal progenitors, thereby bypassing lethality at birth. First, you confirm previous reports showing that the absence of Dcc produces severe intra-retinal misguidance of RGC axons, and with the ability to examine postnatal brains, you demonstrate that some RGCs are still able to leave the retina and project to visual nuclei have multiple targeting defects. Second, the absence of DCC results in postnatal loss of RGCs, and because DCC is expressed in photoreceptors, you show that in its absence, the photoreceptor layer does not develop properly, with rosette-like structures forming in the outer retina and reduced photoreceptor function. Importantly, both the projection and targeting defects and the photoreceptor results were made apparent by a tissue clearing protocol you have developed called "EyeDISCO", providing an overview of the entire visual system and retina. Overall the data on the visual projections and photoreceptors are valuable and the presentation properly detailed and quantified.

The manuscript has been improved but there are some remaining issues that need to be addressed before acceptance, as outlined below:

1) Dcc defects: One reviewer had a remaining concern on how you envision that Dcc/Netrin signaling might act intraretinally in a short-range manner. Are you proposing that Netrin1 is secreted by optic disc cells and diffuses all across the retina? This should be more clearly discussed.

2) Materials and methods section, especially EyeDISCO: you improved the manuscript by moving the methods out of the Results section into the Materials and methods section. Nonethless,

a) Reviewer 2 (comment #1) points out, "The novelty of the new clearing/bleaching methods is diluted by much of the data obtained via tradition flatmount/sectioning techniques." We understand that you do not currently have access to a higher resolution objective compatible with DBE and LSFM to allow for precise whole-eye retinal cell counting, and that you are working on this. In the Discussion section, it would be welcome if you could to comment on the current limitations of the technique/microscopy to view retinal cells.

b) From a positive angle, you could highlight the benefits of the clearing approach for future studies, especially for visualizing axon pathways, than you do currently. For example, subsection “EyeDISCO is a powerful technique to study the eye” read like you are promoting EyeDISCO resolution only for analysis of photoreceptor integrity, and do not cite the quite spectacular visualization of axon tracts and targeting. The approach overall to view entire pathways is phenomenal and used together with visualizing eye defects constitutes a powerful screen for mutants; this message should be "heard" more clearly.

c) More recent successes with pigment bleaching in the eye can be found in Iwai -Takekoshi et al., 2016 and 2018.

3) Flow of the findings, and emphasis: In the reviewer consultation session, all three reviewers thought that the flow of the narrative, and the transitions between subsections in the Results section could be improved.

a) To ameliorate this critique, you might consider changing the order of the subsections in the Results section, keeping the first three as is : subsection “Dcc is broadly expressed in the developing retina”, on Dcc expression, subsection “A novel eye-specific Dcc mutant”, on the novel mutant, subsection “Complexity of RGC guidance defects in Dcc KO revealed by a novel eye clearing method” on the novel clearing method, followed by subsection “Retinal projections in the brain, are altered in eye-specific Dcc mutants” on retinal projections in the brain and even move the last subsection “Dcc intracellular signaling is required for retinal projection targeting in the brain” after this section (thus keeping all the projection analysis together). You could end the Results section with subsection “Eye-specific deletion of Dcc alters retinal layer thickness” on retinal layer thickness and then with subsection “Dcc deletion leads to major retinal dysplasia and visual deficits” on Dcc deletion and retinal dysplasia. Admittedly you would have to alter figure numbers and citations, but you wouldn't have to change content of the figures and generally the Results section would read better.

b) In the Discussion section, subsection “EyeDISCO is a powerful technique to study the eye” on EyeDISCO as a technique to study the eye, once you have amended it as to 2) above, should come last.

c) Significance statement – currently: "An innovative tissue clearing protocol to observe the entire visual system sheds light on a novel function of the axon guidance receptor Dcc and its role in retinal development and maintenance". A suggested amendment that incorporates more aspects of the study: A new eye-specific Dcc mutant combined with an improved clearing protocol for the eye and brain (EyeDISCO) reveals the requirement of the axon guidance receptor Dcc for retinal and pathway development and maintenance.

4) English language issues – Please ask a colleague to go over the text, for clarity, usage and grammar; such editing would better showcase. Your excellent study.

a) Singular vs plural – often not correct (Abstract).

b) Tense not consistent: Abstract: "some ganglion cell axons stalled at the optic disc, whereas others perforate….".

c) Terms: Abstract "retinal pigmented epithelium" should be retinal pigment epithelium.

d) RGC as an adjective: subsection "Dcc is essential for RGCs intraretinal…" should be RGC intraretinal.

e) Many sentences are awkward; for instance:

- Subsection “A novel eye-specific Dcc mutant”: "Dcc+ cells were present in Dcc fl/fl retinas" would sound better as: " Dcc+ cells were found in Dcc fl/fl retinas…"

- Subsection “Complexity of RGC guidance defects in Dcc KO revealed by a novel eye clearing method”: the comma should be replaced by a period.

- Subsection “Dcc intracellular signaling is required for retinal projection targeting in the brain”: The sentence "The AOS was also affected in Dcc mice with a significant reduction in of the volume of the MTN was strongly impacted compared to Dcc littermate controls" should be revised. Does not seem to be correct.

https://doi.org/10.7554/eLife.51275.sa1

Author response

Essential revisions:We have included the reviews at the end of this email so that you can better amend the text. All of the listed points are deemed essential but are in the main textual.Reviewer #1:Vigouroux et al. here generate an eye-specific DCC mutant mouse to more completely characterize the role of DCC in visual system development. First, they analyze DCC expression during early development of the eye. Using their conditional DCC strategy, they find that RGCs lacking DCC display altered axonal trajectories, with a significant percentage extending toward the apical surface of the retina. As previously appreciated, these mice also have severe hypoplasia of the optic nerve. The authors note that not every RGC axon trajectory is altered, as some retinorecipient regions apparently display normal innervation patterns. Novel findings include the observation of severe retinal thinning, RGC loss, and photoreceptor dysplasia in adult mutant mice. In addition, they also present a novel whole eye tissue clearing method which they use to draw several of the conclusions made in this paper.This study describes in great detail a role for DCC in the developing visual system, providing important data which complements that obtained previously by others using null DCC alleles. Though it was previously known that DCC interactions with netrin-1 are required for a large percentage of RGC axons to exit the eye early in development, it was unclear how DCC functions postnatally and into adulthood. Additionally, the presentation of a novel eye clearing model that allows visualization of axon trajectories in 3D space strengthens the conclusions drawn about DCC function in this paper. This clearing method will certainly aid in future studies of this type and will become a valuable resource for the field. For all of these reasons, this paper is appears to be suitable for publication eLife, following attention to relatively minor points raised below.

We thank the reviewer for his/her positive remarks on our study.

1) Please comment as to why one side has a higher innervation density as indicated by CTB labeling in figure 6B? One would expect that both projection patterns would be equally affected in this genetic background. Is this just animal to animal variability?

We agree with the reviewer that the picture in Figure 6B shows a slight asymmetry in the retinal ganglion cell projections. However, this asymmetry is not significant and just reflects eye-to-eye variability in RGC in a given mouse. Indeed, quantifications of optic nerve volumes extracted from CTB-injected mutants does not show a higher variability than in control mice. For example, optic nerve volumes at P15 (SEM ±1.92x106μm3 compared to ±1.92x106μm3) and at P30 (SEM ±2.48x106μm3 compared to ±2.51x106μm3).

However, there may be a slight difference between left and right eye projections that we did not take into account in our quantifications.

2) The point is made that there are apparently differential degrees of retinorecipient innervation defects in the eye-specific DCC mutant, however this seems to be based on the intensity CTB labeled projections (AOS targets (not only the MTN), which are not as densely innervated, appear weaker, as one might expect). The authors should provide more explanation to rule out issues relating to saturation of signaling in more densely innervated targets as opposed to those that receive innervation from many few RGCs. If there are is no additional evidence to support RGC subtype-specific effects resulting from the loss of DCC then this conclusion must be qualified.

We agree with the reviewer that there is still a slight possibility that we are missing some visual projections by injecting CTB in the eye. However, CTB tracing is currently the most common method used to study visual projections in mice and we are not aware that it only partially traces visual projections. In optic nerve regeneration experiments, single CTB+ axons could be reconstructed indicating that the tracer is fluorescent enough to label isolated axons (Li et al., 2015). Even if brightness is increased to the maximum, no additional labeling is seen. If staining was incomplete, it would also mean that there is a specific weak staining of AOS axons. However, we have added this possible point of discrepancy to the discussion in the revised text.

We agree with the reviewer that it would be interesting to further tease apart the mechanism responsible for RGC-specific guidance defects in Dcc cKO mice. A good strategy would be to cross the Dcc conditional mutants to MTN-specific knock in lines (SPIG1:GFP and Hoxd10:GFP). However, we do not currently have access to these lines in the lab and it would probably take a year to get the results.

In an attempt to begin probing at this question, we have purchased 2 commercial antibodies specific for direction-selective RGCs, Hoxd10 and SPIG1. Unfortunately, after testing multiple immunolabeling protocols, none of these antibodies worked in our hands.

3) Please speculate as to why different classes of RGCs and their projection patterns are thought to be differentially affected in these mutants? MTN vs. SC vs. LGN vs. SCN?

We observe that the intensity of Dcc immunolabelling is homogeneous across the entire retina. Thus, we do not believe that specific RGCs may express differential levels of the protein (based on immunostaining). We can only propose at this time that RGC-specific defects may either be due to co-receptors of Dcc which may be differentially expressed in RGCs of the retina (such as UNC5d)(Murcia-Belmonte et al., 2019). Another hypothesis could be that Dcc-specific ligands, in particular Netrin-1 may be differentially expressed in visual targets in the brain and that Dcc/Netrin-1 signaling does not act equally in all RGCs. This has been added to the Discussion section.

4) Please comment on whether, and to what degree, shrinkage is observed of the tissue using this novel clearing approach?

We thank the reviewer for this comment. To address this point, we have quantified the shrinkage of an adult mouse eye following EyeDISCO clearing. We observe a mild shrinkage of approximately 10%. This shrinkage was isotropic across rostro-caudal, dorso-medial, and medio-lateral axes. This was added to the results (Figure 7—figure supplement 1A-D).

Reviewer #2:Vigouroux et al. have re-assessed the function of DCC during retinal development using a new eye-specific Dcc mutant mouse (by Dkk-Cre) to bypass lethality and by introducing a new tissue clearing protocol called "EyeDISCO" to remove melanin. Previously reported Dcc-knockout mice die a few hrs after birth, making it difficult to study DCC function in postnatal stages of visual system development. Using the new Dcc mutant that removes Dcc specifically in retinal progenitors, the authors are able to demonstrate that the absence of DCC results in RGC guidance defects (made possible for EyeDISCO) and postnatal loss of RGCs. The authors also describe the phenotype of kanga/- mutant mouse. Finally, the eye-specific Dcc mutant also shows rosette like structures in the outer retina and reduced rod function.Overall, the results are significant. The data justify the conclusions. A major focus appears to be on eye-clearing methodology, which seems to be better than another published recently by Hennings et al., 2019, and demonstrating its use in elucidating the mutant phenotype that was previously difficult to observe. The phenotypes being described for the Dcc eye mutant provide new clues about its function. This is an appropriate article for Tools and Resources.

We thank the reviewer for his constructive comments on our manuscript. We also agree that we devoted too much space to the eye clearing methods in the original version. The revised manuscript is more focused on the Dcc knockout data.

However, the story seemed to lack coherence and finesse. The main points could be better highlighted/organized. The novelty of the new clearing/bleaching methods is diluted by much of the data obtained via tradition flatmount/sectioning techniques.

We agree that many of the quantifications were carried out on flat-mounted retinas. However, we do not currently have access to a well enough resolved objective compatible with DBE and LSFM to allow for precise whole-eye retinal cell counting. We are currently developing such tools to carry out this precise task. This however would not change the validity results of our quantifications performed on flat-mounted retinas.

Overall, the text is too long. The manuscript, especially Results section, requires tightening and can be made concise. While the quantitative analyses are much appreciated, too many numbers within the Results section create distraction. Similarly, too much of background and methodological detail within Results section make it incoherent. Some of these could be shifted to Introduction or Methods section. The quantification numbers could be presented in the figure legends.

To improve the readability of the paper, and as suggested by the reviewer, we have removed all quantifications from the main text and have moved them to figure legends. Furthermore, we have removed the methodological details of the clearing protocol from the Results section. Despite adding new data, the Results section has been shortened (-500 words).

It's not clear what value the Dcc(kanga) model had for the study. Even if there was more of a difference, a direct comparison with the Dcc-cKO would be more useful than comparison to control only.

We understand that we did not convey well enough the importance of the Dcc Kanga mutants. In order to better present the value of these mutants we have re-arranged the text.

Moreover, we agree with the reviewer that a direct comparison between our mutants would be more insightful. To that respect, we have added quantifications directly comparing visual nuclei volumes between Dcc Kanga mutants and Dcc cKO mice (Figure 8—figure supplement 1A-C).

The photoreceptor part is quite interesting but not much explored. The rosettes are seen in a few other retinal mutants (such as Nrl-knockout and rd7). The authors should expand more in Discussion section on DCC function in photoreceptors and on how its loss leads to rosettes and loss of rods. The authors suggest that the defect is somewhat limited to s-cones but the authors should stain for m-cones.

We agree with the reviewer. In order to better characterize the photoreceptors affected in Dcc mutant mice, we have carried out cryosections and whole-mount immunostaining for S- and M-cones as well as for Rods. We observe that both S- and M-cones are present in the vicinity and within the rosettes in both Dcc cKO (Figure 7—figure supplement 2A-L) and Dcc Kanga mice (Figure 8—figure supplement 1N-O). Furthermore, Rhodopsin is also expressed within rosette structures (Figure 7—figure supplement 2M-P).

Lastly, we have expanded on the function of Dcc in photoreceptor development/maintenance in the Discussion section.

It's not clear why cones would be affected more than rods, as it seems based on ERG data. The authors propose in the discussion that it could be a secondary defect resulting from misguided RGCs and potentially defective OLM. Why not co-stain for RGCs or OLM markers with PR markers? This would make a better case since the RGC defect is variable and we can't be sure that there are misguided RGCs in the same regions where the rosettes are. Why PRs are reduced in number? Seems to be developmental defect, not degeneration.

We agree with the reviewer. In order to emphasize the developmental defect of axon tracts separating the photoreceptors from the retinal pigment epithelium, we have carried out cryosections and labeled for RGC tracts (ßIII tubulin) and photoreceptors (Opn1sw)(Figure 4—figure supplement 1A-D).

We do not believe cones would be more affected than rods in our mutants. To target this, we have carried out immuno-labelling for cones (S and M) as well as rods (Figure 7—figure supplement 2A-P). All photoreceptors are impacted similarly. However, since the proportion of cones to rods in the murine retina is lower, it could explain why we have a stronger defect on the ERG data.

Reviewer #3:In this work the authors use cutting edge technologies to visualize all the defects produced as a consequence of removing Dcc specifically from the retina. They first confirm previous reports showing that the absence of Dcc produces severe intra-retinal misguidance of RGC axons. Then, they discover that a subset of RGCs are still able to leave the retina and reach the visual nuclei where they project showing multiple targeting defects. They further notice defects in the photoreceptors layer, a phenotype not previously reported in Dcc null mice. To perform many of these analyses they optimize a protocol that allows total removal of pigment and therefore a better visualization of the clarified retina.There are several reasons that make this work potentially suitable for this journal. First, it reveals for the first time that the absence of retinal Dcc does not only affect the exit of visual axons from the eye, as it has been assumed for years. Second, they conclusively show that the function of Dcc in the retina is restricted to a subpopulation, not to all, RGCs and suggest that Dcc is important for the targeting of retinal axon projections to the medial terminal nucleus in the brain. They also discover that Dcc is expressed in photoreceptors and it is necessary for the proper formation of the photoreceptors layer.There are however several aspects of the paper that need to be clarified:1) As the authors point out, the rosettes observed in the ventral retina are likely a consequence of the intra-retinal misrouting of RGC axons. In Figure 5Q, the layer of photoreceptors looks much thinner than in the controls. Is this phenotype homogeneous across the retina or it is also only restricted to the ventral part?

We observe that the retinal thinning is homogeneous across the retina. This information was added to the Results section.

In Figure 1—figure supplement 1I is shown that Dcc is expressed in Crx cells (Crx is a cone-rod specific TF) and because the Dkk3-cre line also removes genes from photoreceptors, it is possible that photoreceptors are being intrinsically and homogeneously affected through the entire retina and not only in the ventral retina as a consequence of RGC misrouting.

We thank the reviewer for this valuable question. Indeed, the formation of rosettes is restricted to specific regions in the retina. However, this does not mean that photoreceptor function outside of rosettes is normal. Several observations allude to the possibility that Dcc may play a role in photoreceptor maintenance retina-wide. Firstly, Dcc is transiently expressed in Crx+ cells. Furthermore, our ERG data show that the overall physiological response of the retina is altered. Therefore, it is possible that loss of Dcc may impact photoreceptor function outside of rosettes. Lastly, we have carried out quantifications in our Dcc cKO mice of the ONL thickness from regions of the retina outside of rosettes. Indeed, we visualize a dramatic thinning of the ONL (Figure 7—figure supplement 2Q-U). However, the observation that rosette formations do not progress overtime may point to the opposite hypothesis that loss of Dcc does not induce degeneration of photoreceptors. These points were added to the Discussion section.

2) Subsection “Dcc intracellular signaling is required for retinal projection targeting in the Brain”. The authors infer a novel role for Dcc signaling in RGC guidance to the MTN from the projection phenotype to the MTN in the Dcc kanga mutants. Why is this population particularly affected? From what retinal region do the RGC projecting to the MTN come from?

Indeed, we observe in the Dcc cKO and Dcc Kanga mice a specific defect in the MTN. RGCs projecting to the MTN are distributed homogeneously across the retina. However, several markers have been identified to specifically label these RGCs. Of note, SPIG1 and Hoxd10 label these cells. We have acquired these antibodies and have unfortunately not been able reveal a specific labelling. Both SPIG1:GFP and Hoxd10:GFP knock-in mouse lines exist. However, they are not available in the lab and would take us a long time to obtain. We have therefore included these points as perspectives in the Discussion section.

It would be possible to perform retrograde labeling from this nucleus to answer this question. If they all come from a particular region perhaps these cells are more affected because they have higher levels of Dcc?

We thank the reviewer for this point. However, on whole-mount retinas, we observed a homogeneous expression of Dcc retina-wide. Furthermore, RGCs projecting to the MTN are spread across the retina, therefore simply carrying out a flat-mount or EyeDISCO of Dcc cKO retinas would not help us isolate this population. Indeed, retro-labelling the MTN with a tracer would allow us to track MTN-specific RGCs. However, whilst already quite technically challenging in wild type mice, carrying out these injections in the Dcc cKO mice would be very difficult since the volume of RGC projections to this nucleus is dramatically reduced.

3) It exists also the possibility that the phenotypes observed in the visual nuclei of Dcc mutants are the consequence of having fewer RGCs. In the main visual nuclei it seems likely that rather than a role for Dcc in guidance or targeting, the remaining RGC axon terminals arborize in a different manner because there is less competition between neighboring RGC axons. As the authors state, there is not much information about the timing, guidance or targeting mechanisms of visual axons projecting to the MTN and therefore, this possibility should be at least discussed.

We agree with the reviewer and have added this point to the Discussion section.

4) I believe is not a good idea to make such a big deal about the optimization of the protocol to remove melanin. What is described in this manuscript is basically an improvement of previous protocols. Therefore, I think that, although is a nice and important advance and it should be mentioned, the part dedicated to explain the protocol is too long and distracts from the main message of the paper. It would be better to make a detailed description of the protocol in a technical or more specialized journal.

We thank the reviewer for this point and suggestion. We have therefore removed all the unnecessary details of the EyeDISCO protocol.

[Editors' note: further revisions were suggested prior to acceptance, as described below.]

The manuscript has been improved but there are some remaining issues that need to be addressed before acceptance, as outlined below:1) Dcc defects: One reviewer had a remaining concern on how you envision that Dcc/Netrin signaling might act intraretinally in a short-range manner. Are you proposing that Netrin1 is secreted by optic disc cells and diffuses all across the retina? This should be more clearly discussed.

We agree with the reviewer that the Dcc/Netrin-1 signaling should be more clearly discussed and therefore modified the Discussion section accordingly.

2) Materials and methods section, especially EyeDISCO: you improved the manuscript by moving the methods out of the Results section into the Materials and methods section. Nonethless,a) Reviewer 2 (comment #1) points out, "The novelty of the new clearing/bleaching methods is diluted by much of the data obtained via tradition flatmount/sectioning techniques." We understand that you do not currently have access to a higher resolution objective compatible with DBE and LSFM to allow for precise whole-eye retinal cell counting, and that you are working on this. In the Discussion section, it would be welcome if you could to comment on the current limitations of the technique/microscopy to view retinal cells.

We thank the reviewer for his constructive remark and added comment on this topic in the Discussion section.

b) From a positive angle, you could highlight the benefits of the clearing approach for future studies, especially for visualizing axon pathways, than. you do currently. For example, subsection “EyeDISCO is a powerful technique to study the eye” read like you are promoting EyeDISCO resolution only for analysis of photoreceptor integrity, and do not cite the quite spectacular visualization of axon tracts and targeting. The approach overall to view entire pathways is phenomenal and used together with visualizing eye defects constitutes a powerful screen for mutants; this message should be "heard" more clearly.

We thank the reviewer for his positive comment and changed the Discussion section correspondingly.

c) More recent successes with pigment bleaching in the eye can be found in Iwai -Takekoshi et al., 2016 and 2018.

We added this method in the Discussion section and explained why we have not considered it.

3) Flow of the findings, and emphasis: In the reviewer consultation session, all three reviewers thought that the flow of the narrative, and the transitions between subsections in the Results section could be improved.a) To ameliorate this critique, you might consider changing the order of the subsections in the Results section, keeping the first three as is : subsection “Dcc is broadly expressed in the developing retina”, on Dcc expression, subsection “A novel eye-specific Dcc mutant”, on the novel mutant, subsection “Complexity of RGC guidance defects in Dcc KO revealed by a novel eye clearing method” on the novel clearing method, followed by subsection “Retinal projections in the brain, are altered in eye-specific Dcc mutants” on retinal projections in the brain and even move the last subsection “Dcc intracellular signaling is required for retinal projection targeting in the brain” after this section (thus keeping all the projection analysis together). You could end the Results section with subsection “Eye-specific deletion of Dcc alters retinal layer thickness” on retinal layer thickness and then with subsection “Dcc deletion leads to major retinal dysplasia and visual deficits” on Dcc deletion and retinal dysplasia. Admittedly you would have to alter figure numbers and citations, but you wouldn't have to change content of the figures and generally the Results section would read better.

We thank the reviewers for this suggestion to improve the flow of the narrative. We changed the Results section accordingly. Nevertheless, these modifications introduced the retinal dysplasia phenotype in the Dcc Kanga mutants before the Dcc cKO. Therefore, we had to modify the figures in order to restore the description of the rosettes in the DKK3creDCClox/lox mice before the Dcc Kanga mutants.

Figure 6 is now Figure 5

Figure 8A-M is now Figure 6

Figure 8N-Q and Figure 8—figure supplement 1L-O are now combined in Figure 8—figure supplement 4

Figure 8—figure supplement 1 A-E are now Figure6—figure supplement 1

Figure 8—figure supplement 1 F-K are now Figure7—figure supplement 3

Figure 5 is now Figure 7

Figure 5—figure supplement 1 is now Figure 7—figure supplement 1

Figure 5—figure supplement 2 is now Figure 7—figure supplement 2

Figure 7 is now Figure 8

Figure 7—figure supplement 1 is now Figure 8—figure supplement 1

Figure 7—figure supplement 2 is now Figure 8—figure supplement 2

Figure 7—figure supplement 3 is now Figure 8—figure supplement 3

b) In the Discussion section, subsection “EyeDISCO is a powerful technique to study the eye” on EyeDISCO as a technique to study the eye, once you have amended it as to 2. above, should come last.

We have moved the referred part of the Discussion section to the end.

c) Significance statement – currently: "An innovative tissue clearing protocol to observe the entire visual system sheds light on a novel function of the axon guidance receptor Dcc and its role in retinal development and maintenance". A suggested amendment that incorporates more aspects of the study: A new eye-specific Dcc mutant combined with an improved clearing protocol for the eye and brain (EyeDISCO) reveals the requirement of the axon guidance receptor Dcc for retinal and pathway development and maintenance.

We thank the reviewer for this valuable suggestion and changed the significance statement. Yet we had to slightly modify what was suggested as it was exceeding the word limit.

4) English language issues – Please ask a colleague to go over the text, for clarity, usage and grammar; such editing would better showcase. Your excellent study.

We apologized for the English language issues. The text was edited by an English native speaker colleague for improvement.

a) Singular vs plural – often not correct (Abstract).

This was modified in the text.

b) Tense not consistent: Abstract: "some ganglion cell axons stalled at the optic disc, whereas others perforate….".

This was modified in the text.

c) Terms: Abstract "retinal pigmented epithelium" should be retinal pigment epithelium.

This was modified in the text.

d) RGC as an adjective: subsection "Dcc is essential for RGCs intraretinal…" should be RGC intraretinal.e) Many sentences are awkward; for instance:- Subsection “A novel eye-specific Dcc mutant”: "Dcc+ cells were present in Dcc fl/fl retinas" would sound better as: " Dcc+ cells were found in Dcc fl/fl retinas…"

This was modified in the text.

- Subsection “Complexity of RGC guidance defects in Dcc KO revealed by a novel eye clearing method”: the comma should be replaced by a period.

This mistake was modified in the text.

- Subsection “Dcc intracellular signaling is required for retinal projection targeting in the brain”: The sentence "The AOS was also affected in Dcc mice with a significant reduction in of the volume of the MTN was strongly impacted compared to Dcc littermate controls" should be revised. Does not seem to be correct.

This was corrected in the text.

https://doi.org/10.7554/eLife.51275.sa2

Article and author information

Author details

  1. Robin J Vigouroux

    Institut de la Vision, Sorbonne Université, INSERM, CNRS, Paris, France
    Contribution
    Data curation, Formal analysis, Investigation, Visualization, Methodology
    Competing interests
    No competing interests declared
    ORCID icon "This ORCID iD identifies the author of this article:" 0000-0002-3217-895X

  2. Quénol Cesar

    Institut de la Vision, Sorbonne Université, INSERM, CNRS, Paris, France
    Contribution
    Data curation
    Competing interests
    No competing interests declared

  3. Alain Chédotal

    Institut de la Vision, Sorbonne Université, INSERM, CNRS, Paris, France
    Contribution
    Conceptualization, Formal analysis, Supervision, Funding acquisition, Validation, Investigation, Methodology, Project administration
    For correspondence
    alain.chedotal@inserm.fr
    Competing interests
    No competing interests declared
    ORCID icon "This ORCID iD identifies the author of this article:" 0000-0001-7577-3794

  4. Kim Tuyen Nguyen-Ba-Charvet

    Institut de la Vision, Sorbonne Université, INSERM, CNRS, Paris, France
    Contribution
    Conceptualization, Data curation, Formal analysis, Supervision, Validation, Investigation, Methodology, Project administration
    For correspondence
    kim.charvet@inserm.fr
    Competing interests
    No competing interests declared
    ORCID icon "This ORCID iD identifies the author of this article:" 0000-0001-5398-0872

Funding

Fondation ARC pour la Recherche sur le Cancer (DOC20190508735)

  • Robin J Vigouroux

Agence Nationale de la Recherche (ANR-11-IDEX-0004-02)

  • Alain Chédotal

Agence Nationale de la Recherche (ANR-10-LABX-65)

  • Alain Chédotal

The funders had no role in study design, data collection and interpretation, or the decision to submit the work for publication.

Acknowledgements

We thank Dr Alexandra Rebsam for helpful discussions. We thank the phenotyping facility, in particular Julie Dégardin and Manuel Simonutti for assistance with the eye fundoscopy and electroretinograms. We are also thankful to all the dedicated staff of the Vision Institute animal house facility and to Alexis Guerin in particular. We thank Dr Stephane Fouquet (Vision Institute Imaging Facility) for technical assistance. We thank Dr Anton Berns for providing the Dcc conditional knockout line. The Dkk3:cre line was provided by the RIKEN BRC through the National Bio-Resource Project of the MEXT, Japan. This work was supported by a grant from the LABEX LIFESENSES (reference ANR-10-LABX-65) supported by French state funds managed by the Agence Nationale de la Recherche (ANR) within the Investissements d'Avenir programme under reference ANR-11-IDEX-0004–02 (AC). The funders had no role in study design, data collection and analysis, decision to publish, or preparation of the manuscript.

Ethics

Animal experimentation: All experiments were designed using the 3R rule: to reduce, refine, and replace the use of animals. All animal procedures were carried out according to approved institutional guidelines (#B-75-12-02) of the Institut de la Vision. The protocol was approved by the Sorbonne University ethic committee (Charles Darwin)(Permit Number: 9571). In cases of animal handling, experiments were performed to minimize animal stress and suffering.

Senior Editor

  1. Marianne E Bronner, California Institute of Technology, United States

Reviewing Editor

  1. Carol A Mason, Columbia University, United States

Reviewer

  1. Anand Swaroop, National Institutes of Health, United States

Publication history

  1. Received: August 22, 2019
  2. Accepted: February 24, 2020
  3. Accepted Manuscript published: February 25, 2020 (version 1)
  4. Version of Record published: March 9, 2020 (version 2)

Copyright

© 2020, Vigouroux et al.

This article is distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use and redistribution provided that the original author and source are credited.

Metrics

  • 3,394
    Page views
  • 470
    Downloads
  • 10
    Citations

Article citation count generated by polling the highest count across the following sources: PubMed Central, Crossref, Scopus.

Download links

A two-part list of links to download the article, or parts of the article, in various formats.

Downloads (link to download the article as PDF)

Open citations (links to open the citations from this article in various online reference manager services)

Cite this article (links to download the citations from this article in formats compatible with various reference manager tools)

  1. Robin J Vigouroux
  2. Quénol Cesar
  3. Alain Chédotal
  4. Kim Tuyen Nguyen-Ba-Charvet
(2020)
Revisiting the role of Dcc in visual system development with a novel eye clearing method
eLife 9:e51275.
https://doi.org/10.7554/eLife.51275

Categories and tags

Research organism

Further reading

    1. Developmental Biology
    2. Computational and Systems Biology

    Precise temporal control of neuroblast migration through combined regulation and feedback of a Wnt receptor

    Erik S Schild, Shivam Gupta ... Hendrik C Korswagen
    Research Article Updated

    Many developmental processes depend on precise temporal control of gene expression. We have previously established a theoretical framework for regulatory strategies that can govern such high temporal precision, but experimental validation of these predictions was still lacking. Here, we use the time-dependent expression of a Wnt receptor that controls neuroblast migration in Caenorhabditis elegans as a tractable system to study a robust, cell-intrinsic timing mechanism in vivo. Single-molecule mRNA quantification showed that the expression of the receptor increases non-linearly, a dynamic that is predicted to enhance timing precision over an unregulated, linear increase in timekeeper abundance. We show that this upregulation depends on transcriptional activation, providing in vivo evidence for a model in which the timing of receptor expression is regulated through an accumulating activator that triggers expression when a specific threshold is reached. This timing mechanism acts across a cell division that occurs in the neuroblast lineage and is influenced by the asymmetry of the division. Finally, we show that positive feedback of receptor expression through the canonical Wnt pathway enhances temporal precision. We conclude that robust cell-intrinsic timing can be achieved by combining regulation and feedback of the timekeeper gene.

    1. Developmental Biology
    2. Stem Cells and Regenerative Medicine

    Combined lineage tracing and scRNA-seq reveals unexpected first heart field predominance of human iPSC differentiation

    Francisco Xavier Galdos, Carissa Lee ... Sean Wu
    Research Article

    During mammalian development, the left and right ventricles arise from early populations of cardiac progenitors known as the first and second heart fields, respectively. While these populations have been extensively studied in non-human model systems, their identification and study in vivo human tissues have been limited due to the ethical and technical limitations of accessing gastrulation stage human embryos. Human induced pluripotent stem cells (hiPSCs) present an exciting alternative for modeling early human embryogenesis due to their well-established ability to differentiate into all embryonic germ layers. Here, we describe the development of a TBX5/MYL2 lineage tracing reporter system that allows for the identification of FHF- progenitors and their descendants including left ventricular cardiomyocytes. Furthermore, using single cell RNA sequencing (scRNA-seq) with oligonucleotide-based sample multiplexing, we extensively profiled differentiating hiPSCs across 12 timepoints in two independent iPSC lines. Surprisingly, our reporter system and scRNA-seq analysis revealed a predominance of FHF differentiation using the small molecule Wnt-based 2D differentiation protocol. We compared this data with existing murine and 3D cardiac organoid scRNA-seq data and confirmed the dominance of left ventricular cardiomyocytes (>90%) in our hiPSC-derived progeny. Together, our work provides the scientific community with a powerful new genetic lineage tracing approach as well as a single cell transcriptomic atlas of hiPSCs undergoing cardiac differentiation.

    1. Developmental Biology
    2. Neuroscience

    Glial-dependent clustering of voltage-gated ion channels in Drosophila precedes myelin formation

    Simone Rey, Henrike Ohm ... Christian Klämbt
    Research Article

    Neuronal information conductance often involves the transmission of action potentials. The spreading of action potentials along the axonal process of a neuron is based on three physical parameters: The axial resistance of the axon, the axonal insulation by glial membranes, and the positioning of voltage-gated ion channels. In vertebrates, myelin and channel clustering allow fast saltatory conductance. Here we show that in Drosophila melanogaster voltage-gated sodium and potassium channels, Para and Shal, co-localize and cluster in an area resembling the axon initial segment. The local enrichment of Para but not of Shal localization depends on the presence of peripheral wrapping glial cells. In larvae, relatively low levels of Para channels are needed to allow proper signal transduction and nerves are simply wrapped by glial cells. In adults, the concentration of Para increases and is prominently found at the axon initial segment of motor neurons. Concomitantly, these axon domains are covered by a mesh of glial processes forming a lacunar structure that possibly serves as an ion reservoir. Directly flanking this domain glial processes forming the lacunar area appear to collapse and closely apposed stacks of glial cell processes can be detected, resembling a myelin-like insulation. Thus, Drosophila development may reflect the evolution of myelin which forms in response to increased levels of clustered voltage-gated ion channels.
